Summary of Contents for Moffat FHC1
- Page 1 Light Duty Hotcupboards Operating & Service Manual Manual 076 Issue 001 July 2021...
- Page 2 To ensure the best results from this unit please take the time to read and follow all safety, installation and maintenance guidelines carefully before proceeding to install. Keep this manual in a safe place for future consultation. These appliances are marked in compliance with the relevant Low Voltage &...
- Page 3 Contents page Electrical Specification General Installation Operation Cleaning...
- Page 4 1: Electrical Specification This appliance must be earthed and damaged cables must be replaced by a suitably qualified person! 1 Phase Cable 3 Phase Cable Live (L1) Brown Brown Black Grey Neutral Blue Blue Earth Yellow & Green Yellow & Green (Striped) (Striped) A mains cable, type H07RN-F, conforming to code designation...
- Page 5 Dimensions Power Rating Supply L X W X H (mm) (kw) (kg) 13amp 350 x 600 x 900 FHC1 13amp FHC2 700 x 600 x 900 13amp FHC3 525 x 600 x 900 Before installation please read the following points: •...
- Page 6 3: Operation The Hot cupboard is controlled by green neon on/off switch and a energy regulating control knob. • Connect plug to 13-Amp socket and switch on at mains socket. • Power on with green illuminated Switch and turn Control Knob to position 3 •...
- Page 7 11: Cleaning 4: Cleaning Before attempting to clean the unit, please ensure that the Unit is isolated from the electric supply and allowed to cool down, with all food plates and other Dishes removed from the unit. Do not use a water jet or pressure spray to clean this appliance. Disconnect unit from mains and wait until appliance has cooled.
- Page 8 Thank you for choosing E&R Moffat! Scan the QR code below to visit the E&R Moffat website for further information: www.ermoffat.co.uk E&R Moffat Ltd. +44 (0) 1324 812272 Bonnybridge sales@ermoffat.co.uk FK4 2BS Scotland...
