- Page 1 MH9 & MHB9 Hotcupboards Operating & Service Manual Manual 036 Issue 001 July 2021...
- Page 2 To ensure the best results from this unit please take the time to read and follow all safety, installation and maintenance guidelines carefully before proceeding to install. Keep this manual in a safe place for future consultation. These appliances are marked in compliance with the relevant Low Voltage &...
- Page 3 Contents page Electrical Specification General Installation Hot Cupboard Specification & Operation 6 / 7 / 8 Cleaning...
- Page 4 1: Electrical Specification This appliance must be earthed and damaged cables must be replaced by a suitably qualified person! 1 Phase Cable 3 Phase Cable Live (L1) Brown Brown Black Grey Neutral Blue Blue Earth Yellow & Green Yellow & Green (Striped) (Striped) A mains cable, type H07RN-F, conforming to code designation...
- Page 5 2: General Installation Before installation please read the following points: • When placing the unit in position ensure there is adequate access. • These mobile units can simply be butted up together to form a food service counter. • Roll into position and apply the brakes on the operator’s side. •...
- Page 6 3: Hotcupboard Electrical Dimensions Power Rating Model Weight Supply L X W X H (mm) (kw) (kg) 13amp 1124 x 560 x 868 13amp MHB9 1124 x 560 x 868 Hot storage cupboards are designed for preheating Plates & Dishes, as well as the temporary storage of precooked food whilst service is in progress e.g.
- Page 7 3: Hotcupboard Sahara fan removal & installation Isolate appliance from power supply & allow to cool down before removal. The unit can be easily removed & replaced for cleaning or maintenance, due to a simple IEC type fastening system. • Access to the Plug &...
- Page 8 3: Hotcupboard Hot Cupboard Doors Fig 1 demonstrates the fitting of the cupboard doors; in this case, the rear door (Door A). Hold the door at a slight angle & locate the door fully into the top track. Swing the bottom of the door inwards connecting with the bottom track lower the door into the bottom track, &...
- Page 9 11: Cleaning 4: Cleaning Before attempting to clean the unit, please ensure that the Unit is isolated from the electric supply and allowed to cool down, with all food plates and other Dishes removed from the unit. Do not use a water jet or pressure spray to clean this appliance. Disconnect trolley from mains and wait until appliance has cooled.
- Page 10 Thank you for choosing E&R Moffat! Scan the QR code below to visit the E&R Moffat website for further information: www.ermoffat.co.uk E&R Moffat Ltd. +44 (0) 1324 812272 Bonnybridge sales@ermoffat.co.uk FK4 2BS Scotland...
