CNPS7700 LED
Intel Pentium 4
Socket 478 CPU
Grip (L-Type)
Inner Hole
* Please read before installation.
http://www.zalman.co.kr
(English version)
Intel
Dual Core Pentium / Pentium 4
Socket 775 CPU
Grip (S-Type)
AMD Sempron/AMD64
(Athlon 64 X2/Opteron/Athlon 64)
Socket 754/939/940 CPU
Grip (L-Type)
Outer Hole
http://www.zalmanusa.com
Advertisement
Related Manuals for ZALMAN CNPS7700 LED
Summary of Contents for ZALMAN CNPS7700 LED
- Page 1 All manuals and user guides at all-guides.com (English version) CNPS7700 LED Intel Dual Core Pentium / Pentium 4 Socket 775 CPU Grip (S-Type) Intel Pentium 4 Socket 478 CPU Grip (L-Type) Inner Hole AMD Sempron/AMD64 (Athlon 64 X2/Opteron/Athlon 64) Socket 754/939/940 CPU...
-
