User ' ' s Manual
User ' ' s Manual
AMD Duron/Athlon/Athlon XP
Socket 462 CPU
CNPS7000B
* Please read before installation
http://www.zalman.co.kr http://www.zalmanusa.com
(English Edition)
Intel Pentium 4
Socket 478 CPU
AMD Sempron/AMD64 (Athlon 64/Opteron)
Socket 754/939/940 CPU
Advertisement
Related Manuals for ZALMAN CNPS7000B Series
Summary of Contents for ZALMAN CNPS7000B Series
- Page 1 All manuals and user guides at all-guides.com User ’ ’ s Manual User ’ ’ s Manual (English Edition) Intel Pentium 4 Socket 478 CPU AMD Duron/Athlon/Athlon XP Socket 462 CPU AMD Sempron/AMD64 (Athlon 64/Opteron) Socket 754/939/940 CPU CNPS7000B * Please read before installation http://www.zalman.co.kr http://www.zalmanusa.com...
-
Page 2: Specifications
Note 1)The maximum weight for a cooler is specified as 450g for Intel Socket 478 and AMD Socket 754/939/940 and 300g for AMD Socket 462. Special care should be taken when moving a computer equipped with a cooler which exceeds the relevant weight limit. Zalman is not responsible for any damage that occurs when moving a computer. - Page 3 5) The exposed core of a Socket 462 CPU can be cracked if proper care is not taken. Read the “Installation” section thoroughly before installing. NOTICE) Zalman Tech Co., Ltd. is not responsible for any damages due to external causes, including improper use, problems with electrical power, accident, neglect, alteration, repair, improper installation, or improper testing.
- Page 4 55mm radius from the center of the CPU to install this product. ③ For more information, please visit the Zalman website (http://www.zalman.co.kr) and click on “ Compatibility between CNPS7000(A/B) and Socket 478 Pentium 4 Motherboards” link.
- Page 5 RAM, etc.) should be present within a 55mm radius from the center of the CPU to install this product. ② For more information, please visit the Zalman website (http://www.zalman.co.kr) and refer to “CNPS7000(A/B) “Compatible Socket 754/939/940 Motherboards List” link.
- Page 6 All manuals and user guides at all-guides.com 8. Installation (AMD Duron / Athlon / Athlon XP - 462) 1) Install Clip Supports for Socket 462 Install the clip supports for socket 462 on the motherboard. Make sure to place A-type (blue : installed near the lever) and B-type (white) supports at the appropriate location.
- Page 7 All manuals and user guides at all-guides.com 9. Installation (AMD Sempron / AMD64 - 754/939/940) 1) Fasten Nipples Place a big washer on the motherboard. Then, put a nipple over it and fasten the nipple until the motherboard is firmly stuck to the backplate. * Retention Guide is not needed when installing CNPS7000B on Socket 754/939/940.
- Page 8 Turned fully clockwise, it operates in Normal Mode. You can select the desired fan speed by turning the knob. Note) FAN MATE 2 has been specifically designed for the fan of this product. Zalman Tech Co., Ltd. is not responsible for any damage to systems or CPUs caused by using it with other types of fans.
- Page 9 All manuals and user guides at all-guides.com 12. Zalman Noise Prevention System When building a noiseless computer, use Zalman’s Noiseless Power Supply, Noiseless Case Fan, Fanless Northbridge Cooler, Heatpipe HDD Cooler, Heatpipe VGA Cooler, and Fan Controller to achieve stable performance and maintain a noiseless environment.
