Taking a Closer Look

Vertical ruler
Horizontal ruler
(U-shaped ruler)
Power switch
Power connector
Scanner lid (or TMA 1600-III)
Glass surface
READY indicator (Green)
POWER indicator (Orange)
Smart-Touch button (Scan)
Accessory port (or with TMA
1600-III's connector securely
connected)
Hi-Speed USB port (1)
ScanMaker 9800XL Plus User Guide 3
