Taking a Closer Look
Front/Top View
No.
Names of Parts
1
Scanner Cover
2
Document Output Tray
3
Output Tray Extender
4
Paper Stopper (1)
5
Paper Stopper (2)
6
Paper Stabilizer
7
Button Panel
• Power Button
• Select Button
• Scan/Stop Button
• Favorite Button
• LED Display
8
Guide Arms
9
Document Feed Tray
10
ArtixScan DI 7200S/7280S User's Manual
Functions of Parts
Used to cover the inner parts of the scanner.
Stores the stacked documents which have been scanned.
Used to extend the length of the Document Output Tray.
Stops a stack of the output documents.
Stops a stack of the output documents.
Used to keep a stack of the output documents with
dfferent sizes neatly in the Document Output Tray.
Turns the scanner on or off.
Toggles through the numbers of predefined function buttons.
Starts scan immediately or cancel a ongoing scan job.
Activates the function associated with the Favorite button
that was defined in the "Save Settings to Function Button"
dialog box.
Displays the selected function button number.
Slides to hold a stack of documents.
Holds the documents to be fed into the feeder.
