- Page 1 DUST COLLECTOR MODEL G1030 INSTRUCTION MANUAL COPYRIGHT © 1991 BY GRIZZLY INDUSTRIAL, INC. REG # 3 176 555 WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
-
Page 3: Table Of Contents
SET UP ...14 MOBILE ...15 STATIONARY ...15 SYSTEM GROUNDING ...16 MAINTENANCE GENERAL ...17 IMPELLER TIGHTENING...17 LUBRICATION ...17 CLOSURE...18 MACHINE DATA ...19 PARTS BREAKDOWN AND PARTS LISTS ...20-21 WARRANTY AND RETURNS...22 WARRANTY CARD ...22-23 G1030 Dust Collector Table Of Contents PAGE... -
Page 4: Safety
Your extension cord must also contain a ground wire and plug pin. Always repair or replace extension cords if they become damaged. Minimum Gage for extension cord: 16 A.W.G. 50ft 16 A.W.G. 100ft 14 A.W.G. 200ft 12 A.W.G. 300ft G1030 Dust Collector... -
Page 5: Safety Instructions For Power Tools
15. DISCONNECT TOOLS before servicing and changing accessories, such as blades, bits, cutters, and the like. G1030 Dust Collector 16. REDUCE THE RISK OF UNINTENTION- AL STARTING. Make sure switch is in off position before plugging in. -
Page 6: Additional Safety Instructions For The Dust Collector
Additional Safety Instructions For The Dust 1. This dust collector is to be used for wood dust collection only. DO NOT use this dust collector to pick up liquids and metal scrap including, but not limited to, nails and filings. -
Page 7: Circuit Requirements
G1030 Dust Collector The motor supplied with the G1030 requires 220V service and cannot be rewired for 110V. Under normal use, the motor draws approxi- mately 18 amps @ 220V. We recommend using a 20 amp circuit breaker or a 30 amp slow-blow fuse for 220V operation. - Page 8 Dust Collector. These requirements are not necessarily comprehensive. You must be sure that your particular electrical configura- tion complies with local and state codes. Ensure compliance by checking with your local municipality or a licensed electrician. G1030 Dust Collector...
-
Page 9: General Information
All accessories are offered through the cur- rent Grizzly catalog. We are also pleased to provide this manual for the Model G1030. It was written to guide you through assembly, review safety considerations, and cover general operating procedures. It repre- sents our latest effort to produce the best docu- mentation possible. -
Page 10: Unpacking
Unpacking The Model G1030 Dust Collector is shipped from the manufacturer in a carefully packed carton. If you discover the machine is damaged after you’ve signed for delivery, please call Customer Service immediately for advice. Save the containers and all packing materials for possible inspection by the carrier or its agent. -
Page 11: Site Considerations
Site Considerations When placing the G1030 Dust Collector in your shop, two major considerations should be addressed: working clearances and electrical access and loading. Working Clearances: Be sure to allow your- self sufficient room to safely operate your machines in any foreseeable operation. -
Page 12: Assembly
SECTION 4: ASSEMBLY Beginning Assembly Assembly of the G1030 is straightforward and can be accomplished quite easily. We have orga- nized the assembly process into logical steps. Please follow them in sequence. You will find that some pre-assembly has been done at the factory. -
Page 13: Collector Body
18 x ⁄ " bolts provided. Figure 3. Mounting collector to base. G1030 Dust Collector The outlet can now be attached to the main col- lector body. Insert the rubber gasket between the collector and lower outlet flange and secure using eight (8) "... -
Page 14: Collectors
Repeat this procedure for the brackets on the opposite side. Figure 7. Support Brackets ⁄ "-18 x ⁄ " bolts provided. Figure Figure 6. Mounting brackets to base. Figure 7. Mounting collector to brackets. G1030 Dust Collector ⁄ "-18 x ⁄ "... -
Page 15: Collection/Filter Bags
Thread the long Figure 9.Securing the bag clamps G1030 Dust Collector bolt through one side of the clamp, then the lock nut, then thread the bolt through the other clamp. -
Page 16: Operations
Unusual or strange sounds or symptoms must be investigated and the problem corrected before proceeding further. Make sure the G1030 is unplugged or dis- connected from the power source and moving parts have come to a complete stop before investigating any problems or performing any maintenance or adjustments. -
Page 17: Mobile
Requirements. G1030 Dust Collector Stationary The G1030 can be set up as a stationary unit with the addition of a fixed duct system to service more than one machine at a time. The primary advantage of a stationary system is it eliminates... -
Page 18: System Grounding
If you connect the dust collector to more than one machine by way of a non-conducting branching duct system and blast gates, the system must still be grounded as mentioned above. -
Page 19: Maintenance
SECTION 7: MAINTENANCE General Impeller Tightening Periodic maintenance will ensure safe operation, long dust collector life, and low overall cost of operation. Lubrication t s . G1030 Dust Collector -17- S h i e l d e d a n d p r e - l u b r i c a t e d b a l l b e a r i n g s . r e q u i r e... -
Page 20: Closure
Washington location using the address in the Section 3 General Information section. The spec- ifications, drawings, and photographs illustrated in this manual represent the Model G1030 as supplied when the manual was prepared. However, due to Grizzly’s policy of continuous improvement, changes may be made at any time with no obligation on the part of Grizzly. -
Page 21: Machine Data
Customer Service #: (570) 326-3806 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901 GRIZZLY MODEL G1030 DUST COLLECTOR Design Type ... Floor Model Specifications: Intake Hole Size ...6" Intake Adapter Hole Size (1)...4" x 3" Holes Bag Size (4) ...19" x 33"... -
Page 22: Parts Breakdown And Parts Lists
68" BAND CLAMP PS06 PHLP HD SCREW 10-24 x PWRCRD220S POWER CORD, 220V, SHORT ⁄ "-18 x ⁄ " " "-18 x ⁄ " ⁄ " ⁄ "-18 x ⁄ " "-18 x 1" "-18 ⁄ " G1030 Dust Collector... - Page 23 21 24 10232323 4 2 729A 2 1 4...
-
Page 24: Warranty And Returns
WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance. -
