Y - SUS P101 to Control P111 Plug Information
Y - SUS P101 to Control P111 Plug Information
Diode Mode Readings taken with all connectors Disconnected. DVM in Diode Mode.
Pin Label
1
Gnd
3
CTRL_OE
5
Dummy 4
7
Dummy 3
9
CLK
11
STB
13
BLK
15
Data
17
OC2
19
Dummy 2
21
Gnd
23
Gnd
25
5V
27
5V
29
15V
"Y-SUS" P101 CONNECTOR to "Control PWB" P111
STBY Run Diode Mode
Gnd 0V Gnd
0V 0.1V 0.65V
0V 1.28V 0.65V
0V 0V 0.65V
0V 0.6V 0.65V
0V 2.96V 0.65V
0V 1.4V 0.65V
0V 0V 0.65V
0V 1.89V 0.65V
0V 2.16V 0.65V
Gnd Gnd Gnd
Gnd Gnd Gnd
0V 5V 0.44V
0V 5V 0.44V
0V 15V Open
Pin 1 on Y-SUS is Pin 30 on Control
Pin Label STBY
2
SET_DN
4
SUS_UP
6
ER_UP
8
Dummy 1
10
Dummy 5
12
Set_Up
14
ER_DN
16
SUS-DN
18
OE
20
Gnd
22
Gnd
24
5V
26
5V
28
5V
30
15V
63 January 2009 Plasma
Run Diode Mode
0V 0.12V 0.65V
0V 0.13V 0.65V
0V 0.2V 0.65V
0V 1.05V 0.65V
0V 0.17V 0.65V
0V 2.5V 0.65V
0V 0V 0.65V
0V 0V 0.65V
0V 0V Open
Gnd Gnd Gnd
Gnd Gnd Gnd
0V 5V 0.44V
0V 5V 0.44V
0V 5V 0.44V
0V 15V Open
