16. How to Connectorize Cables
This procedure describes how to connectorize cables of various sizes and types,
when the preset lengths of cable are not appropriate. There are two types of cable
connectorization described here, each requiring its own tool:
•
•
TOOLS FOR 25-PAIR CABLES:
1
1
TOOLS FOR DS1 CABLES:
1
APPARATUS FOR DS1 CABLES:
1
Connectorization Using the MI-1 Tool
This procedure describes how to connectorize a 25-pair cable, such as those used
with the LANlink SRU. (Refer to Fig. 16-1 for details of the tool parts.)
(1) Position the tool on a workbench or the step of a ladder. Secure the base plate of
The AMP CHAMP MI-1 tool is used for 25-pair cable connectorization.,
The CERTI-CRIMP tool is used for DS1 cables, connected to the Digital Trunk
Link (DTL) SRU.
AMP CHAMP MI-1 Crimping Tool
AMP CHAMP T-Handle Insertion Tool, AMP 229384-1.
CERTI-CRIMP Crimping Tool, AMP 90312-1.
Receptacle (15-pin) for DTL SRU female connector (AMP 205205-1 with
metal shell)
Socket Pins (female) for 20/24 AWG Wire (AMP 66504-9)
Cable Housing with screws (AMP 206471-1).
the MI-1 with C-clamps or a similar device. Make certain that nothing interferes
with the opening of the tool handles.
Installing the Alarm System 133
Practice 450-1011-201
