MODEL 463250108 • PRODUCT GUIDE
THIS GRILL IS FOR OUTDOOR USE ONLY.
CAUTION:
Read and follow all safety statements, assembly
instructions, and use and care directions before
attempting to assemble and cook.
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
If you have questions or need assistance during assembly, please call
To insure your satisfaction and for follow-up service, register your grill online at www.grillregistration.com
WARNING:
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
CAUTION:
Some parts may contain sharp edges – especially as
noted in the manual! Wear protective gloves if
necessary.
1-888-430-7870
.
463250108 • 80015551 • 03-20-08

Advertisement

Table of Contents
loading

Related Manuals for Char-Broil RED 463250108

Summary of Contents for Char-Broil RED 463250108

  • Page 1 MODEL 463250108 • PRODUCT GUIDE THIS GRILL IS FOR OUTDOOR USE ONLY. CAUTION: Read and follow all safety statements, assembly instructions, and use and care directions before attempting to assemble and cook. INSTALLER/ASSEMBLER: Leave this manual with consumer. CONSUMER: Keep this manual for future reference. If you have questions or need assistance during assembly, please call To insure your satisfaction and for follow-up service, register your grill online at www.grillregistration.com WARNING:...
  • Page 2 DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Open lid. 4. If odor continues, keep away from the appliance and immediately call your gas supplier or your fire department. WARNING 1.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS For Your Safety ........2 To insure your satisfaction Grill Service Center.
  • Page 4 USE AND CARE DANGER • NEVER store a spare LP cylinder under or near the appliance or in an enclosed area. • Never fill a cylinder beyond 80% full. • An over filled or improperly stored cylinder is a hazard due to possible gas release from the safety relief valve.

  • Page 5: For Your Safety

    LP Cylinder Exchange • Many retailers that sell grills offer you the option of replacing your empty LP cylinder through an exchange service. Use only those reputable exchange companies that inspect, precision fill, test and certify their cylinders. Exchange your cylinder only for an OPD safety feature-equipped cylinder as described in the "LP Cylinder"...

  • Page 6: Grill Service Center

    Hold coupling nut and regulator as shown for proper connection to LP cylinder valve. 6. Turn the coupling nut clockwise and tighten to a full stop. The regulator will seal on the back-check feature in the LP cylinder valve, resulting in some resistance. An additional one-half to three-quarters turn is required to complete the connection.
  • Page 7 WARNING For Safe Use of Your Grill and to Avoid Serious Injury: • Do not let children operate or play near grill. • Keep grill area clear and free from materials that burn. • Do not block holes in sides or back of grill. •...
  • Page 8 WARNING Turn controls and gas source or tank OFF when not in use. CAUTION If ignition does NOT occur in 5 seconds, turn the burner controls OFF, wait 5 minutes and repeat the lighting procedure. If the burner does not ignite with the valve open, gas will continue to flow out of the burner and could accidently ignite with risk of injury.

  • Page 9: Spider Alert

    CAUTION SPIDER ALERT! SPIDER AND WEBS INSIDE BURNER TUBE If you notice that your grill is getting hard to light or that the flame isn’t as strong as it should be, take the time to check and clean the venturi’s. CONTROL PANEL VALVE In some areas of the country, spiders or small insects have been...
  • Page 10 Food Safety Food safety is a very important part of enjoying the outdoor cooking experience. To keep food safe from harmful bacteria, follow these four basic steps: Clean: Wash hands, utensils, and surfaces with hot soapy water before and after handling raw meat and poultry.
  • Page 11 The methods below are suggestions for cleaning stainless steel surfaces. Choose a cleaning method appropriate for your needs. It is recommended that you use a Char-Broil® grill cover to help prolong the life and prevent discoloration of your grill.

  • Page 12: Parts List

    Bradley Company. Thermos® is a registered trademark of the Thermos Company and its affiliates. Artisan Collection by Char-Broil ™, C3 and Design™, Char-Broil and Design™, Flame Design™, FlavorTents™, Grill 2 Go™, Grillin’ Stick™, Keeper of the Flame™, Keepers of the Flame™, Natural Grip™, Outdoor Cooking Collection and Design™, Patio Bistro™, PrecisionFlame™, Pro-Check™, QuickSet Grills and Design™, SmokerTents™, The Big Easy™, The Minute Grill™, The Edge™, The Tuscan Collection™, and The Urban Grill™...

  • Page 13: Parts Diagram

    PARTS DIAGRAM – Model No. 463250108 463250108 • 13...

  • Page 14: Assembly

    ASSEMBLY – Model No. 463250108 Right and Left Shelf Assembly Attach two 1/4-20x3/4” screws, 1/4” flat washers and 1/4” lock washers through side shelf holes (right shelf ONLY) into towel bar shown A. Insert side shelf over screws and washers through bracket shown B.
  • Page 15 Sideburner Assembly Insert the sideburner valve into the sideburner and secture it to the bracket using two #5-40x1/5” screws shown A. Make sure burner tube aligns correctly onto sideburner valve underneath left shelf shown B. Insert the side burner into the cut-out shown C, place the side burner on support bracket, align and insert these stud into installation holes of bracket.
  • Page 16 Sideburner Control Knob Assembly Position sideburner valve bracket beneath sideburner shelf fascia so that valve stem comes through larger center hole in fascia shown A. Attach sideburner bezel to fascia using two #8-32x3/8” screws shown A. Press sideburner control knob onto valve stem shown A. Note: Make sure set the Bezel with longer slot at the top.
  • Page 17 Sideburner Wind Diverter, Sideburner Cap and Clip, Sideburner Grate Place sideburner wind diverter over sideburner aligning cut- out in diverter to fit around electrode shown A. Place burner cap onto sideburner and attach sideburner cap clip shown B. Place sideburner cooking grate onto sideburner shelf, aligning grate legs with holes in shelf shown A.
  • Page 18 Trough Install First, place Trough Middle onto Firebox shown A. Second, Place Trough A and Trough B onto Firebox. Make sure this is put in the right direction as show in B. 18 • 463250108 Trough Middle Trough A Trough B Trough Middle...
  • Page 19 Cooking Grate and Warming Rack Place cooking grates onto the firebox as shown. Place the Warming Rack onto the the firebox.Make sure insert the Warming Rack ends into the holes properly shown as below. Warming Rack Cooking Grate 463250108 • 19...
  • Page 20 Condiment Basket Assembly 　 Open the door and place the Condiment Basket on the left door inside, make sure the insert the pivots of the Condiment Backet into the bracket which riveted together the door inside shown as below. 20 • 463250108...
  • Page 21 Electronic Ignition 　 Unscrew electronic ignition button left side panel of cart. Insert AA battery into ignitor, negative (—) end first. Replace button. Battery Cap Battery Positive(+) side up towards Cap 463250108 • 21...
  • Page 22 LP Tank LP TANK IS SOLD SEPARATELY. Fill and leak check the tank before attaching to grill and regulator (see Use & Care section). Once tank has been filled and leak checked, place cylinder into cut-out in bottom shelf. Make sure tank valve is facing front of grill.

  • Page 23: Troubleshooting

    EMERGENCIES: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Emergencies Possible Cause Gas leaking from • Damaged hose. cracked/cut/burned hose. Gas leaking from LP • Mechanical failure due to rusting or cylinder.
  • Page 24 Troubleshooting (continued) Problem Possible Cause ELECTRONIC IGNITION: Burner(s) will not light using ignitor. • No spark, no ignition noise. (See Electronic Ignition Troubleshooting also) • No spark, some ignition noise. • Sparks, but not at electrode or at full strength. •...

  • Page 25: Troubleshooting

    Troubleshooting - Electronic Ignition Problem (Ignition) Possible Cause SECTION I No sparks appear at • Battery not installed properly. any electrodes when control knob turned ; no noise can be heard from spark module. • Dead battery. • Faulty spark module. SECTION II No sparks appear at •...

  • Page 26: Warranty

    Consumer returns will not be accepted unless a valid Return Authorization is first acquired by calling 1-888-430-7870 and then clearly marked on the outside of the package and the package is shipped freight/postage pre-paid to the address above. 26 • 463250108 Char-Broil Consumer Relations P. O. Box 1240 Columbus, GA 31902-1240...

  • Page 27: Registration Card

    ¿Qué producto está registrando? Quel produit enregistrez-vous? Gas Grill/Parrilla a gas/Gril au gaz Electric Grill/Parrilla eléctrica/Gril électrique Smoker/Ahumador/Fumoir Charcoal Grill/Parrilla a carbón/Barbecue au charbon Charcoal Smoker/Ahumador a carbón/Fumoir au charbon Outdoor Fireplace/Chimenea para exteriores/Foyer extérieur Cooker/Fryer / Cocina/freidora / Cuiseur/Friteuse Other/Otro/Autre Thank you for completing this questionnaire.
  • Page 28 Always ensure control knobs are in OFF position and regulator is attached to tank BEFORE opening tank valve to avoid low flames. Perform leak test regularly. Thank You for Your Purchase! Char-Broil, LLC • Columbus, GA 31902 • Printed in China...
