MC-DX40/MC-DX40DAB
NOTES
PC boards shown are viewed from parts side.
The parts with no reference number or no parts number
in the exploded views are not supplied.
As regards the resistors and capacitors, refer to the circuit
diagrams supplied pripor to this manual.
!
Parts marked with this sign are safety critical components.
They must be replaced with designated components.
Destination of product is expressed by [ ] mark and ensure
exact replacement:
[EUR] - Europe; [UK] - UK
Micro Hi-Fi System
CONTENTS
1 SPECIFICATIONS
................. ................................... ................. ...
2 MICROCONTROLLER PIN FUNCTIONS
3 EXPLODED VIEW AND PARTS LIST
4 PC BOARDS AND PARTS LISTS
5 INCLUDED ACCESSORIES
2
3
. .................
6
. ...... ............ ........
9
................................... .
18
. .......................... ... .................
Advertisement
Table of Contents
Related Manuals for Teac MC-DX40
Summary of Contents for Teac MC-DX40
- Page 1 MC-DX40/MC-DX40DAB Micro Hi-Fi System NOTES CONTENTS 1 SPECIFICATIONS PC boards shown are viewed from parts side................. 2 MICROCONTROLLER PIN FUNCTIONS The parts with no reference number or no parts number ....in the exploded views are not supplied.
-
Page 2: Specifications
L & R Speakers 0.6 kg each Subwoofer 4.8 kg Standard Accessories Remote control unit (RC-1195) x 1 MC-DX40 only (RC-1200) x 1 MC-DX40DAB only Battery for remote control unit (CR2025) x 1 Subwoofer cable x 1 Speaker cable x 2... - Page 3 MC-DX40/MC-DX40DAB 2 MICROCONTROLLER PIN FUNCTIONS T5CC1, MAIN PCBA IC 21 2-1 Pin Assignment T5CC1...
- Page 4 MC-DX40/MC-DX40DAB Pin Functions Status Description Note Pull-up NoUse init stby Act. ADC Reference LOW( GND ) 1 VREF VREFL 4 P70/TA0IN OPEN 5 P71/TA1OUT OPEN 6 P72/TA3OUT OPEN 7 P73/TA4IN OPEN 8 P74/TA5OUT OPEN 9 P75/TA7OUT OPEN 10 P80/TB0IN0/INT5 OPEN...
- Page 5 MC-DX40/MC-DX40DAB Status Description Note Pull-up NoUse init stby Act. 71 P30/RD OPEN 72 P31/WR OPEN 73 P32/HWR EEPROM_DATA EEPROM DATA 74 P33/WAIT EEPROM_CLK EEPROM CLOCK DAB system reset(Does not use) 75 P34/BUSRQ DAB_SYS_RST 76 P35/BUSAK 77 P36/R/W OPEN 78 P37/BOOT...
-
Page 6: Exploded Views And Parts List
MC-DX40/MC-DX40DAB 3 EXPLODED VIEWS AND PARTS LIST EXPLODE VIEW... -
Page 7: Exploded View
MC-DX40/MC-DX40DAB EXPLODED VIEW REF. NO. PARTS NO. DESCRIPTION REMARKS ORNAMENT , DOOR A (40B) ORNAMENT , DOOR A (40S) ORNAMENT , DOOR B (40B) ORNAMENT , DOOR B (40S) WINDOW , DOOR (40HB/40DABB) WINDOW , DOOR (40B/40S) CGR1A458ZA CD DOOR ASSY (40B) - Page 8 MC-DX40/MC-DX40DAB EXPLODED VIEW REF. NO. PARTS NO. DESCRIPTION REMARKS Not in use CHG1A417 RUBBER , SHAFT CHG1A415Y ABSORBER , MECH (B) CHG1A416Z ABSORBER , MECH (A) CHG1A418 FOOT , SET CASDX40NXTBK NXT SPEAKER (40B/40HB) CASDX40NXTSL NXT SPEAKER (40S) CASDX450NXTBK NXT SPEAKER (40DABB)
-
Page 9: Pc Boards And Parts List
MC-DX40/MC-DX40DAB 4 PC BOARDS AND PARTS LIST MAIN PCB , TOP CUP12113Z-1 MAIN PCB CUP12113Z-3 VIDEO PCB No mount CUP12113Z-2 IPOD PCB No mount CUP12113Z- 4 USB PCB (40B/40S/40HB only) -
Page 10: Main Pcb , Bottom
MC-DX40/MC-DX40DAB MAIN PCB , BOTTOM CUP12113Z-1 MAIN PCB CUP12113Z-3 VIDEO PCB No mount CUP12113Z-2 IPOD PCB No mount CUP12113Z- 4 USB PCB (40B/40S/40HB only) -
Page 11: Main Pcb Assy
I.C , REGULATOR, KIA1117S33 IC14 CVIKIA1117S15 I.C , REGULATOR, KIA1117S15 IC15 CVIKIA7808AF I.C , REGULATOR, KIA7808AF IC21 CVIANAM1426CR I.C , U-COM MC-DX40(CVIT5CC1/TOSHIBA) ┗ CVIT5CC1 I.C , FLASH U-COM, T5CC1 IC22 CVIAT24C02NSU18 I.C , EEPROM (2K), AT24C02NSU18 IC24 HVIRH5VT18C I.C , RESET, RH5VT18C... - Page 12 MC-DX40/MC-DX40DAB REF. NO. PARTS NO. DESCRIPTION REMARKS X101 HOX16934A120C CRYSTAL X201 HOX27000E180S CRYSTAL , CHIP(27MHZ,SMD) X202 HOX00032K120I CRYSTAL , 32.768KHZ X301 HOX12000E200C 12MHz CRYSTAL CUP12113Z-2 iPOD PCB IC44 I.C, OP AMP, BA4560RF No mount S401, S402 SW , TACT No mount...
- Page 13 MC-DX40/MC-DX40DAB AMP PCB CUP12110-1 POWER PCB CUP12110-2 AMP PCB...
- Page 14 MC-DX40/MC-DX40DAB AMP PCB ASSY REF. NO. PARTS NO. DESCRIPTION REMARKS COP12110C AMP PCB ASSY (40B/40S/40HB) Equivalent to COP12110B AMP PCB ASSY (40DABB) on MP CUP12110Z PCB , POWER(AMP) CUP12110-1 POWER PCB BD78,79 KLZ9H001Z BEAD , CORE C702 CCEA1CH102E CAP , ELECT, 100uF/50V C705 CCEA1CH471T CAP , ELECT, 470uF/16V C717 CCEA1CH682E CAP , ELECT, 6800uF/50V C719 CCEA1EH101T CAP , ELECT, 100uF/25V C751 CCEA1EH332E CAP , ELECT, 3300uF/25V C752,754,762 CCEA1EH102E CAP , ELECT, 100uF/25V C753...
- Page 15 MC-DX40/MC-DX40DAB AMP PCB ASSY REF. NO. PARTS NO. DESCRIPTION REMARKS Q705 HVTKRC107MT T.R, C107M RY72 CSL3A018ZE RELAY , L/R NXT SPK RY73 CSL3A018ZE RELAY , SUBWOOFER JK72 CJJ4N083Z JACK , 2P RCA(W/R, SILVER PLATE)
-
Page 16: Front Pcb
MC-DX40/MC-DX40DAB FRONT PCB CUP12112Z-1 FRONT(KEY PAD) PCB CUP12112Y-3 CUP12112Y-2 CLOSE SWITCH PCB OPEN SWITCH PCB... -
Page 17: Front Pcb Assy
MC-DX40/MC-DX40DAB FRONT PCB ASSY REF. NO. PARTS NO. DESCRIPTION REMARKS COP12112C FRONT PCB ASSY CUP12112Z PCB , FRONT CUP12112Z-1 FRONT (KEY PAD) PCB S301,302,601~612 CST1A012ZT SW , TACT CUP12112Y-2 OPEN SW PCB SW62 CSH1A011Z SW , DETECTOR(1C1P, SNAP IN, 5.2MM PITCH) -
Page 18: Included Accessories
MC-DX40/MC-DX40DAB 5 INCLUDED ACCESSORIES INCLUDED ACCESSORIES PARTS NO. DESCRIPTION REMARKS CARTMCDX40 REMOTE CONTROL UNIT RC-1195 (40B/40S/40HB) CARTMCDX40DAB REMOTE CONTROL UNIT RC-1200 (40DABB) ┗ BATTERY CR2025 (Supplied with Remote control units) CQX1A1384Z MANUAL , INSTRUCTION - EGNS (40B/40S) CQX1A1419Z MANUAL , INSTRUCTION - FI (40S/40HB) - Page 19 7733 Telegraph Road, Montebello, California 90640 Phone: (323) 726-0303 TEAC CANADA LTD. 5939 Wallace Street, Mississauga, Ontario L4Z 1Z8, Canada Phone: (905) 890-8008 TEAC MEXICO, S.A. De C.V Río Churubusco 364, Colonia Del Carmen, Delegación Coyoacán, CP 04100, México DF, México Phone:(5255)5010-6000 TEAC UK LIMITED Unit 19 &...
- Page 20 MC-DX40/MC-DX40DAB MAIN PCB c i f < > . MC-DX40/MC-DX40DAB Micro Hi-Fi System...
- Page 21 MC-DX40/MC-DX40DAB MAIN PCB CD DSP PART MOTOR DRIVE POWER SHEET 02 +M8V SHEET 04 +MD8V IC15 M+12V M+12V CVIKIA7808AF MOTOR DRIVE +MD8V BN31 BN31 OUT IN TA2125 R135 IC12 MOTOR MGND CN13 LOADING+ LOADING+ MGND MGND MGND MGND LOADING- LOADING-...
- Page 22 MC-DX40/MC-DX40DAB MAIN PCB FUNCTION / POWER PART +ST5V Q503 A107ST FUNCTION IC Q504 C551 MAIN OUTPUT AUX_L F_MUTE 1/50V NJU7391V -12V C552 C107ST USB/IPOD_L L_OUT 1/50V C565 R511 C568 R514 R518 L_OUT C553 DAB_L 4.7/50V 10/50V 1/50V TUNER_L +12V C510...
- Page 23 MC-DX40 MAIN PCB USB PART MC-DX40 only +USB3.3V USB/IPOD_L R318 C354 R314 +USB1.8V +USB3.3V 100/16V SHEET 04 C353 R311 USB/IPOD_R C355 R319 R315 100/16V C315 OSCVDDR PRGAGND 0.1uF PROGAVDD PRG_VDDH C313 C314 OSCVSSR PRG_VDD C301 0.1uF 0.1uF VSS33 PROG_GND C312 0.1uF...
- Page 24 MC-DX40/MC-DX40DAB FRONT PCB OPEN SWITCH B'D (CUP12112Y-2) OPEN_SW SW62 M_GND SHEET 02 CD OPEN SW CN17 C602 0.01uF BN17 USB B'D M_GND OPEN_SW 3 GND SENSOR B'D KEY PAD B'D (CUP12112Y-1) (CUP12112Y-3) CD CLOSE-SW S601 KEY0 STANDBY/ON MGND KEY1 S602...
-
Page 25: Power Part
MC-DX40/MC-DX40DAB SUB WOOFER UNIT AMP Part BD72 TDA7265 1.-VS 7.L IN IC71 2.R OUT 8.L -IN D709 CN76 9.GND GBJ1006 3.+VS 4.L OUT 10.R-IN 5.MUTE/STBY 11.R IN 6.-VS AGND AGND AGND AGND 12V DC BD73 SPK Rel ay CN79 CN71...
