MICRO Hi-Fi SYSTEM MC-DX10
PC board shown are viewed from parts side.
The parts with no reference number or no parts number
in the exploded views are not supplied.
As regards the resistors and capacitors, refer to the
circuit diagrams contained in this manual.
!
Parts marked with this sign are safety critical
components. they must be replaced with identical
components - refer to the appropriate parts list and
ensure exact replacement.
All manuals and user guides at all-guides.com
FPGM/SET
FM/AM
OPEN
POWER
MC-DX10
MICRO Hi-Fi SYSTEM
2
3
5
10
18
20
