Chapter 1
1-1 Preface.....................................................................................................1
1-2 Key Feature..............................................................................................1
Chapter 2
2-1 Unpacking.................................................................................................3
2-2 The Diagram of 610BF/612BF.................................................................4
2-4 Installation Steps......................................................................................6
2-5 Jumper Settings........................................................................................6
2-6 System Memory (DRAM)..........................................................................8
2-7 Central Processing Unit (CPU).................................................................8
2-8 Expansion Cards......................................................................................9
2-9 External Connectors.................................................................................10
3-1 STANDARD CMOS SETUP.....................................................................17
3-2 BIOS FEATURES SETUP........................................................................20
3-3 Advanced Chipset Features Setup..........................................................22
3-4 Integrated Periperals................................................................................24
3-5 POWER MANAGE MENT SETUP ...........................................................27
3-6 PNP/PCI CONFIGURATION SETUP........................................................29
3-7 PC Health Status.......................................................................................31
3-8 Frequency/Voltage Control........................................................................31
3-9 Defaults Menu............................................................................................32
3-10 Supervisor/User Password Setting...........................................................32
3-11 EXIT Selecting.........................................................................................33
3-12 POST Messages.....................................................................................33
3-13 POST Codes............................................................................................37
Chapter 4
4-1 Software Installation ....................................................................................43
4-2 Keyboard Password/Hot-Key/PS/2 Mouse Power On..................................44
TABLE OF CONTENT
....................................................................................3
...................................................................................16
i
.............................................................43
Advertisement
Table of Contents
Related Manuals for MSI 610BF
Summary of Contents for MSI 610BF
-
Page 1: Table Of Contents
1-1 Preface.....................1 1-2 Key Feature....................1 Chapter 2 Hardware Installation ..................3 2-1 Unpacking....................3 2-2 The Diagram of 610BF/612BF..............4 2-3 Quick Reference for Jumpers, Connectors & Expansion Socket.....5 2-4 Installation Steps..................6 2-5 Jumper Settings..................6 2-6 System Memory (DRAM)................8 2-7 Central Processing Unit (CPU)..............8 2-8 Expansion Cards..................9... -
Page 2: Preface
Multi-Speed Support : Provide 66/75/83/95/100/112/117/124/133MHz Front Side Bus Frequency to support Intel Celeron PPGA on a ZIF socket 370 interface. Chipset: Intel 810L Chiset for 610BF; Intel 810 DC-100 Chipset for 612BF. DRAM Memory Support: support two 168-pin DIMMS(3.3V)from a memory size between 8MB to 256MB using 16Mb/64Mb technology ( 512MB using 128Mb technology ). -
Page 3: Hardware Installation
PCI Bus Master IDE Controller and ULTR DMA 33, 33/66 (for 612BF only) : On-board PCI Bus Master IDE controller with two connectors that supports four IDE devices in two channels, provides faster data transfer rates, and supports Enhanced IDE devices such as Tape Backup, CD-ROM 、ZIP、... -
Page 4: Unpacking
It is assumed that the chassis is designed for a standard IBM XT/AT main board mounting. Place the chassis on the anti-static mat and remove the cover. Take the plastic clips, Nylon stand-off and screws for mounting the system board, and keep them separate. 2-2 610BF/612BF Motherboard Diagram... -
Page 5: Quick Reference For Jumpers, Connectors & Expansion Socket
Figure 2-1 2.3 Quick Reference for Jumpers, Connectors & Expansion Socket... -
Page 6: Installation Steps
Jumpers Jumper Name Description Page CPU Bus Frequency Selection 1-2 :100MHZ , 2-3:66MHz p. 6 V I/O Voltage 1- 2 :For V I/O 3.45V (Default) 3-4 :For V I/O 3.52V Keyboard Power on Function (K.B.Voltage) 1-2 : 5VSB for ATX Power Supply p. -
Page 7: Jumper Settings
3. Install DRAM Modules 4. Install Expansion card 5. Connect Cables, Wires, and Power Supply 2-5 Jumper Settings CPU Bus Frequency Selection : JP1 ※ Users also can setting the CPU Bus frequency and CPU ratio in the “Frequency / Voltage Control “of BIOS SETUP. - Page 8 Note: You need clear keyboard Power On Password setting(JP9) before you clear CMOS data if you do not remember your password. 3. Codec Master / Slave Mode Control: JP12 4. Case cover open detection: JP7 5. Clear Keyboard Power On Password setting: JP9 6.
-
Page 9: System Memory (Dram)
2-6 System Memory (DRAM) This main board supports two 168-pins DIMM modules, the Max Memory Size is 256MB(512MB using 128Mb technology). System can be DIMM 1 DIMM 2 Accept or Not Accept 168-pin DIMM Accept 168-pin DIMM 168-pin DIMM ... -
Page 10: External Connectors
Installation Procedure: 1. Read the documentation from your expansion card. 2. Set any necessary jumpers on your expansion card. 3. Remove your computer’s cover. 4. Remove the bracket on the slot you intend to use. 5. Carefully align the card’s connectors and press firmly. 6. - Page 11 provide two plugs (P8 and P9), each containing six wires, two of which are black. Orient the connectors so that the black wires are located in the middle. Using a slight angle, align the plastic guide pins on the lead to their receptacles on the connector.
- Page 12 5. Parallel Printer Connector (26-pin Block): LPT1 Connection for the enclosed parallel port ribbon cable with mounting bracket. Connect the ribbon cable to this connection and mount the bracket to the case on an open slot. It will then be available for a parallel printer cable. NOTE: Serial printers must be connected to the serial port.
- Page 13 8. Primary IDE Connector (40-pin block): IDE1 This connector supports the provided IDE hard disk ribbon cable. After connecting the single plug end to motherboard, connect the two plugs at other end to your hard disk(s). If you install two hard disks, you must configure the second drive to Slave mode by setting its jumpers accordingly.
- Page 14 This 5-pin connector connects to the case-mounted key switch for locking the keyboard for security purposes and Power LED together. D. Speaker connector: SPKR This 4-pin connector connects to the case-mounted speaker. See the figure below. 12. IR infrared module connector: IR1 This connector supports the optional wireless transmitting and receiving infrared module.
- Page 15 When using ATX power, the system power can be controlled by a momentary switch connected to PS-ON Pushing the button once will switch ON/OFF the system. The system Power LED will shows the status of the system’s power. Selections One touch Power ON/OFF 16.
-
Page 16: Chapter 3 Award Bios Setup
20. Wake On Lan connector: WOL1 ※ Wake On Lan function worked only when power supply support 5VSB more than 750mA current. Chapter 3 AWARD BIOS SETUP Once you enter the AwardBIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions and two exit choices. - Page 17 Advanced BIOS Feature Load Optimal Defaults Advanced Chipset Feature Load Standard Defaults Integrated Peripherals Set Supervisor Password Power Management Setup Set User Password PnP/PCI Configurations Save & Exit Setup PC Health Status Exit Without Saving Esc : QUIT ↑↓→← : Select Item F10 : Save &...
-
Page 18: Standard Cmos Setup
section 3-10 for the details. Save & Exit Setup: Save CMOS value changes to CMOS and exit setup. See section 3- 11 for the details. Exit Without Save: Abandon all CMOS value changes and exit setup. See section 3-11 for the details. - Page 19 options (described in Table 3) Press <Enter> to enter the IDE Secondary Master Options are in its sub menu sub menu of detailed (described in Table 3) options Drive A None Select the type of floppy disk drive installed in your Drive B 360K, 5.25 in system...
-
Page 20: Bios Features Setup
F5:Previous Values F6:Optimal defaults F7:Standard Defaults Figure3-1-1 IDE Primary Master sub menu Use the legend keys to navigate through this menu and exit to the main menu. Use Table 3 to configure the hard disk. Item Options Description IDE HDD Auto- Press Enter Press Enter to auto-detect the HDD on this channel. - Page 21 Virus Warning Enabled Item Help CPU Internal Cache Enabled _____________________ External Cache Enabled CPU L2 Cache ECC Checking Enabled Menu Level Quick Power On Self Test Disabled First Boot device Floppy Allows you to choose the Second Boot device HDD-0 VIRUS warning feature for Third Boot device...
- Page 22 The Choice: Floppy, LS/ZIP, HDD, SCSI, CDROM, Disabled. Swap Floppy Drive: If the system has two floppy drives, you can swap the logical drive name assignments. The choice: Enabled/Disabled. Boot Up Floppy Seek: Seeks disk drives during boot up. Disabling speeds boot up. The choice: Enabled/Disabled.
-
Page 23: Advanced Chipset Features Setup
3-3 Advanced CHIPSET FEATURES SETUP CMOS Setup Utility – Copyright © 1984 – 1998 Award Software Advanced Chipset Features SDRAM CAS Latency Time Item Help SDRAM Cycle Time Tras/Trc ______________________ SDRAM RAS-to-CAS Delay Menu Level SDRAM RAS Precharge Time System BIOS Cacheable Enabled Video BIOS Cacheable... -
Page 24: Integrated Periperals
SDRAM RAS Precharge Time: If an insufficient number of cycles is allowed for the RAS to accumulate its charge before DRAM refresh, the refresh may be incomplete and the DRAM may fail to retain data. Fast gives faster performance; and Slow gives more stable performance. - Page 25 CMOS Setup Utility – Copyright © 1984 – 1998 Award Software Integrated Peripherals OnChip Primary PCI IDE Enabled Item Help OnChip Secondary PCI IDE Enabled ______________________ IDE Primary Master PIO Auto Menu Level IDE Primary Slave Auto If your IDE hard drive IDE Secondary Master Auto supports block mode...
- Page 26 The choice: PCI Slot, Onboard . AC97 Audio/Modem: This item allows you to decide to enable/disable the 810 chipset family to support AC97 Audio/Modem. The choice: Enabled, Disabled. IDE HDD Block Mode: Block mode is also called block transfer, multiple commands, or multiple sector read/write.
-
Page 27: Power Management Setup
EPP+ECP: ECP Mode & EPP Mode. PWRON AFTER PWR-Fail: AC Power Recovery ON/OFF system control. Off : Always turn OFF system power when AC recovery On : Always turn ON system power when AC recovery Former-Sts : Turn ON/OFF system depend on the last status of system if the system is on before Power-Loss , then will auto power on after power recovery. - Page 28 ACPI function Enabled Item Help Power Management User Define _________________ Video Off Method V/H SYNC_Blank Menu Level Video Off In Suspend Suspend -> Off Suspend Type Stop Grant MODEM Use IRQ Soft-Off by PWRBTN Delay 4 Sec CPU THRM-Throttling 25.0% ** Reload Global Timer Events ** Primary IDE 0...
-
Page 29: Pnp/Pci Configuration Setup
Suspend Type: Select the Suspend Type. The choice: PWRON Suspend, Stop Grant. MODEM Use IRQ: This determines the IRQ in which the MODEM can use. The choice: 3, 4, 5, 7, 9, 10, 11, NA. Suspend Mode: When enabled and after the set time of system inactivity, all devices except the CPU will be shut off. - Page 30 PnP OS Installed Item Help Reset Configuration Data Disabled Menu Level Resources Controlled By Manual IRQ Resources Press Enter Default is Disabled. DMA Resources Select Enabled to Press Enter reset Extended System Memory Resources Press Enter Configuration Data(ESCD) when you PCI/VGA Palette Snoop...
-
Page 31: Pc Health Status
DMA Resources: When resources are controlled manually, assign each system DMA channel a type, depending on the type of device using the DM channel. DMA 0/1/3/5/6/7 assigned to: Legacy ISA for devices compliant with the original PC AT bus specification, PCI/ISA PnP for devices compliant with the Plug and Play standard whether designed for PCI or ISA bus architecture. -
Page 32: Frequency/Voltage Control
CPU Warning Temperature Disabled Item Help 。 。 F Current System Temp. C/ 77 _________________ 。 。 F Current CPU Temp. C/120 Menu Level Current FAN1 Speed. 4172 Current FAN2 Speed. 4358 Current FAN3 Speed. 4041 Vcore Vtt(V) 1.55 V Vcc3.3 3.36 V 4.94 V... -
Page 33: Defaults Menu
83MHz/off , 95MHz/off , 100MHz/off , 100MHz/on , 112MHz/off , 117MHz/on , 124MHz/off, 133MHz/off , 133MHz/on. CPU Ratio: This item allows you to select the CPU ratio. From X3 to X8 3-9 Defaults Menu Selecting “Defaults” from the main menu shows you two options which are described below ... -
Page 34: Exit Selecting
When a password has been enabled, you will be prompted to enter it every time you try to enter Setup. This prevents an unauthorized person from changing any part of your system configuration. Additionally, when a password is enabled, you can also require the BIOS to request a password every time your system is rebooted. - Page 35 Checksum of CMOS is incorrect. This can indicate that CMOS has become corrupt. This error may have been caused by a weak battery. Check the battery and replace if necessary. DISK BOOT FAILURE, INSERT SYSTEM DISK AND PRESS ENTER No boot device was found.
- Page 36 Cannot find or initialize the floppy drive controller. make sure the controller is installed correctly and firmly. If there are no floppy drives installed, be sure the Diskette Drive selection in Setup is set to NONE. Invalid EISA Configuration PLEASE RUN EISA CONFIGURATION UTILITY The non-volatile memory containing EISA configuration information was programmed incorrectly or has become corrupt.
- Page 37 PRESS F1 TO DISABLE NMI, F2 TO REBOOT When BIOS detects a Non-maskable Interrupt condition during boot, this will allow you to disable the NMI and continue to boot, or you can reboot the system with the NMI enabled. RAM PARITY ERROR - CHECKING FOR SEGMENT ... Indicates a parity error in Random Access Memory.
-
Page 38: Post Codes
Sector Verify failed. Hard Disk(s) fail (08) Keyboard is locked out - Unlock the key. BIOS detect the keyboard is locked. P17 of keyboard controller is pulled low. Keyboard error or no keyboard present. Cannot initialize the keyboard. Make sure the keyboard is attached correctly and no keys are being pressed during the boot. - Page 39 POST (hex) Description fails, keep beeping the speaker. Reserved Auto detect flash type to load appropriate flash R/W codes into the run time area in F000 for ESCD & DMI support. Reserved Use walking 1’s algorithm to check out interface in CMOS circuitry. Also set real-time clock power status, and then check for override.
- Page 40 POST (hex) Description Reserved Reserved Reserved 1. Initialize multi-language 2. Put information on screen display, including Award title, CPU type, CPU speed …. Reserved Reserved Reserved Reserved Reserved Reset keyboard except Winbond 977 series Super I/O chips. Reserved Reserved Reserved Reserved Reserved Reserved...
- Page 41 POST (hex) Description Reserved Reserved Display number of processors (multi-processor platform) Reserved 1. Display PnP logo 2. Early ISA PnP initialization -Assign CSN to every ISA PnP device. Reserved Initialize the combined Trend Anti-Virus code. Reserved (Optional Feature) Show message for entering AWDFLASH.EXE from FDD (optional) Reserved 1.
- Page 42 POST (hex) Description Reserved Reserved Detect & install co-processor Reserved Reserved Reserved Reserved 1. Switch back to text mode if full screen logo is supported. -If errors occur, report errors & wait for keys -If no errors occur or F1 key is pressed to continue: Clear EPA or customization logo.
-
Page 43: 610Bf/612Bf Driver Installation
Chapter 4 610BF/612BF Driver Installation Preparation 1. You must have more than 33MB memory on your system in order to install VGA driver. 2. If you are using Windows 95, you must update to Windows 95 OSR2.1 or later version. -
Page 44: Keyboard Password/Hot-Key/Ps/2 Mouse Power On
Windows 95： 1. Install USB Supportment Driver From win95 CD Driver (OSR2.1 Support USB Need). 2. Run X：\INTEL810\INF\INF\SETUP.EXE and choose “Windows 95 OSR2.1”. 3. Install X：\INTEL810\INF\INFINST\SETUP.EXE and follow on screen instruction. 4. After re-start your computer; just simply click NEXT to choose Windows default driver. Windows 98：... - Page 45 or “Hot-key” “PS/2 Mouse” in “Power On Function” item under “INTEGRATED PERIPHERAL SETUP”. A: When choose “Password”, then user can setting your password in “KB Power On Password” item. After save CMOS SETUP, the next time want to power on, you have to key in your password to power on, otherwise the system will not power on.
