WebCAM
User Manual
Version 4.0
For models:
iCV-01a / iCV-03a / iCV-08

Advertisement

Table of Contents
loading

Summary of Contents for 3Com iCV-01a

  • Page 1 WebCAM User Manual Version 4.0 For models: iCV-01a / iCV-03a / iCV-08...
  • Page 2: Table Of Contents

    CONTENTS Chapter 1: Introduction ________________________________________ 1 Section 1. Features___________________________________________ 1 Section 2. WebCAM as a Remote Surveillance System ______________ 1 Section 3. Package Contents ___________________________________ 2 Chapter 2: Hardware Installation ________________________________ 4 Chapter 3: Web Interface _______________________________________ 5 Section 1. Introduction ________________________________________ 5 Section 2.
  • Page 3 2.3.2 Advanced (for password and HTTP configuration) ____________ 56 2.5 About__________________________________________________ 58 2.6 Refresh ________________________________________________ 58 Chapter 6: MultiMonitor _______________________________________ 60 Section 1. Installing MultiMonitor _______________________________ 60 Section 2. Using MultiMonitor __________________________________ 60 2.1 Device _________________________________________________ 63 2.2 View __________________________________________________ 74 2.3 System ________________________________________________ 74 2.4 User __________________________________________________ 75 2.5 Help___________________________________________________ 76...
  • Page 4: Chapter 1: Introduction

    Chapter 1: Introduction Section 1. Features WebCAM is a compact stand-alone web-server capable of remote video surveillance. It can be accessed from anywhere in the world via a standard browser by entering the IP Address, account and password. Each system can support two types of USB PC cameras.
  • Page 5: Section 3. Package Contents

    Section 3. Package Contents WebCAM package contain the following items; 1. WebCAM server. 2. USB Camera. 3. Quick Installation Guide. 4. Utility CD containing; a. Utility: to configure IP address, update the firmware, etc. b. MultiMonitor: to monitor multiple WebCAM cameras. c.
  • Page 6 Fig.2 WebCAM Front and Back view LED Status Indicators on WebCAM Light color Signal definition Green Power state Error Condition Orange Logon state Yellow USB data activity Fig.3 WebCAM Status LED Indicator Light indicators on WebCAM LAN Port LED Light color When On: Internet speed is at 100M Green When flashing: Data transmitting/receiving...
  • Page 7: Chapter 2: Hardware Installation

    Chapter 2: Hardware Installation The following details the hardware installation procedure for WebCAM IP camera. Step 1: Connect the PC camera into the USB port of WebCAM. Step 2: Connect the WebCAM to LAN by using the Ethernet UTP port. Step 3: Connect DC power adapter output into WebCAM socket, and plug the DC...
  • Page 8: Chapter 3: Web Interface

    Chapter 3: Web Interface Section 1. Introduction WebCAM is designed to work without having to install any software. necessary functions are built-into the unit. 1. Once you have finished the hardware setup shown in Chapter 2, note down the IP address shown on the LCD 2.
  • Page 9: Section 2. Using The Web Interface

    Section 2. Using the Web Interface The WebCAM webpage main menu is divided into two sections. The selection menu on the left and display menu on the right. following options: 2.1 View Video 2.2 Information 2.3 Basic Settings 2.4 Advanced Settings When using WebCAM for the first time, check the following settings;...
  • Page 10: To View Video

    2.1 To View Video To view video from the connected camera, click on either ActiveX or Sun Java. Choose either Camera A or B to view the video. By default the first USB camera connected to WebCAM will be Camera A Note: ActiveX can only function in Windows platform and a plug-in has to be installed on the client's computer.
  • Page 11 Once installed, the video will stream. Show current date & time Note: Make sure to adjust the USB camera lens for best picture quality. Click the record button to start video recording. The default directory is; C:\Windows\Temp\ video CMV20060710123058.avi To change the saved location and filename. Click window will pop up.
  • Page 12 To change Video Codec, click Note: The availability of Codec depends on weather the individual user has it installed on the PC or not. Download and install Windows Media Player 10 to enable MPEG4 codec. Digital Zoom In, Digital Zoom Out Rotate Left, Rotate Right Flip the image vertically.
  • Page 13 Using Sun Java Controls: Once you click on Sun Java the following pop-up window will appear. Show current time & date Show zoom level (in %) Shows the number of viewers for this camera.. Show location as set in Advanced System SNMP settings Click this to Marquee an area and zoom into that area.
  • Page 14 Chapter 3: Web Interface This indicates the full pan-tilt range of the USB Camera. This is the area and position the camera is currently showing. WebCAM - user manual -11-...
  • Page 15: Information

    2.2 Information The Information tab contains the following subsections; 2.2.1 System Status, 2.2.2 Current Connections, and 2.2.3 Event Log. 2.2.1 System Status This webpage displays all the information relating to WebCAM. viewable by viewers of all permission levels. System Information This section shows general hardware information such as the Hardware and Firmware Version, the serial number, current / local System Time, the system name, contact, location and uptime.
  • Page 16: Current Connections

    2.2.2 Current Connections Fig.10 WebCAM Current Connections The Current Connections page shows all the users currently viewing either Camera A or Camera B (First icon denotes Camera A). It also lists the login time and total bytes received. Note: Administrator privilege is required to view and use Block IP. Otherwise, the IP and Account details will be hidden and Block IP function disabled.
  • Page 17 Chapter 3: Web Interface Fig.12 WebCAM Event Log: Administrator privilege. Fig.13 WebCAM Event Log: Operator privilege. WebCAM - user manual -14-...
  • Page 18: Basic Settings

    2.3 Basic Settings The following option allows the user to customize their unit. 2.3.1 Camera Settings 2.3.2 Patrol Settings 2.3.3 Network 2.3.4 Account Settings 2.3.1 Camera Settings Use this section to set up the USB camera. Setting up Camera A (or Camera B) Fig.14 Individual Camera Configuration Image Size User can select the following image size;...
  • Page 19 Choose Yes and WebCAM will increase the lighting of the image. This is useful when monitoring indoors. Choose No if you do not want WebCAM to compensate for bright indoor lighting and view the images as is. Color Choose Yes for color and No for black and white display. Black and White display results in slightly faster FPS (Frames Per Second) video.
  • Page 20 This section allows the user to define hotspots, required patrol boundary, and see where the current camera position. Click to select which camera to control. Show ful Pan Tilt range. User defined Pan Tilt boundary Fig.15 WebCAM Patrol Setting / Controls HotSpot Settings This part shows the hotspot coordinates and the Administrator can give each location a name.
  • Page 21 b. Square – The camera will patrol along the user defined boundary in a clock wise manner. c. Pan only – The camera will perform Pan function only. d. Tilt only – The camera will perform tilt function only. e. In sequence (1-5) – The camera will jump to each Hotspot location in sequence and wait for 10 seconds in each spot.
  • Page 22 Chapter 3: Web Interface Fig.17 WebCAM DNS Server IP Primary DNS Server IP This item sets WebCAM primary DNS Server IP address. This is the default DNS and cannot be edited. Secondary DNS Server IP Use this to set WebCAM Secondary DNS Server IP address. WebCAM will use the Secondary DNS Server IP address if the Primary DNS Server IP address is not working.
  • Page 23 Each WebCAM unit is shipped with a default domain name ***.icv99.net, where *** is the unique 10 digit serial number located at the back of WebCAM. Fig.20 WebCAM Default Dynamic DNS Use Default Domain Name Each unit of WebCAM is shipped with a default Domain Name. To activate this feature;...
  • Page 24 4. Once registered, user can change either, the default domain name, DNS password or Email address. Click Confirm to save changes. Note: Enter a valid Email address. In the event you have forgotten the password to your DNS account, a new password will be sent to this email address upon request.
  • Page 25 Other Dynamic DNS Fig.21 Dynamic DNS from other Service Providers Service Provider In addition to http://ddns.iCV99.net, WebCAM can be configured to register with other Dynamic DNS providers. The following free DDNS service providers are supported; • dhs.org • dyndns.org • myddns.com •...
  • Page 26: Account Settings

    Use Public IP to register Choose Yes to ensure that WebCAM uses the WAN / Public IP to register with the selected DDNS server. iii. PPPoE Use this option to allow WebCAM to connect to the internet directly using your xDSL modem.
  • Page 27 User Name Assign a User Name / Account. The administrator can set up to 32 case sensitive character names. Password Assign a password to the account. The administrator can set up to 32 case sensitive passwords. Permission This sets the access level to individual user accounts. Administrator: An Administrator has full access including write permission to all menus and sub-sections.
  • Page 28 Fig.24 WebCAM Permit Hours Configuration Click Configure to set the hours. The Administrator can set up to 4 different Permit Hours (in 24hr format). without saving. Note: The Reset button only revert the fields to initial values prior to any changes being made.
  • Page 29: Advanced Settings

    2.4 Advanced Settings This section allows the Administrator to set up some of the features available in the server. 2.4.1 Event Notification 2.4.2 Motion Detection 2.4.3 Image Recording 2.4.4 Email / FTP 2.4.5 System Settings 2.4.6 Image Server 2.4.7 Language 2.4.8 About 2.4.1 Event Notification This section determines the type of event that will be included if an email notification is...
  • Page 30 The available Email addresses are listed here. See Section 2.4.4 on how to enter an Email address to the Address Book. To add an email address click Edit. configuration prior to leaving this page. Recipients Up to 8 valid email accounts can receive Email Notification. To add an email address to the recipient list, click <.
  • Page 31 Chapter 3: Web Interface Fig.27 Event Selection List Note: The Image Recording and Motion Detection notification function here will only send an email notification WITHOUT any picture attached. For email notification with images, the Administrator has to setup the Motion Detection page (see Section 2.4.2) and Image Recording page (see Section 2.4.3) WebCAM - user manual -28-...
  • Page 32 Chapter 3: Web Interface WebCAM will email the following notification depending on which event was selected. Fig.28 Event Notification: User Login Details (Date, Time, Camera & IP) Fig.29 Event Notification: Camera A Motion Detected WebCAM - user manual -29-...
  • Page 33: Motion Detection

    Fig.30 Event Notification: PPPoE Connect Successful with Public IP shown 2.4.2 Motion Detection This page allows the Administrator to set Motion Detection functions for the cameras. Camera A (or Camera B) Enable The Administrator has two options for Motion Detection; a.
  • Page 34 Note: Check that you have setup valid Email / FTP accounts first before proceeding with the rest of the configuration. To setup Email / FTP, see Section 2.4.4 Detection Sensitivity This will determines the level of change before motion capture is triggered. A high percentage means a small change will trigger motion capture.
  • Page 35 Loop from … to … This will determine the number of files in the sequence. Once the last file number is reached, it’ll loop and replace the first file in the sequence with the most current image. Digits … This will determine the number of digits assignable for the above sequence. The Administrator can choose to assign between 1 to 6 digits.
  • Page 36: Image Recording

    To remove a recipient from the list, click > To remove all the recipients from the list, click >> Click Apply to confirm and save the settings. 2.4.3 Image Recording Image recording allows the user to receive a string of JPG images to either their email account or FTP account.
  • Page 37: E-Mail / Ftp

    Chapter 3: Web Interface Fig.34 Email of Image Recorded 2.4.4 E-mail / FTP This webpage sets up the necessary Email and FTP server information. Administrator will have to enter a valid Account Name and Password to the Email server and/or FTP server. These information has to be setup in order for Event Notification, Motion Detection and Image Recording function to work.
  • Page 38 FTP Settings FTP Server The Administrator will have to enter the full FTP server address here. Account Name Enter the FTP login account name here. Password Enter the account password. Click Apply to save the above settings. Email Settings E-mail Server The Administrator will have to enter the Email server address here.
  • Page 39 iii. Sending Test Mail a. Click Test Mail to check that the Email Setting has been correctly configured. Fig.39 Saving configuration before sending a test mail b. Click Yes to save configurations and proceed to the following window. Fig.40 Test mail recipient email address c.
  • Page 40: System Settings

    The administrator can also check Information failure. Fig.42 Event Log: Test mail successful Email Address Book Enter an Email address in the box provided and click Add Email Address. The listed emails will be available for use in Event Notification, Motion Detection and Image Recording webpage.
  • Page 41 Chapter 3: Web Interface Fig.45 System Settings page System Time Fig.46 System Time System Time Updates The administrator can set an interval for time synchronization. Select either; 1, 3, 12 hours or 1, 10 & 30 days. Time Server Choose the nearest Time Server to your WebCAM location. The Administrator can choose from the list of a maximum of 30 Time Servers.
  • Page 42 Time Zone (Relative to GMT) Select the appropriate time zone. Click Apply to save changes. System Time (yyyy/mm/dd hh:mm:ss) This section is to manually set WebCAM System Time. pre-determined to: yyyy/mm/dd hh:mm:ss (in 24hr format). Adjust to save the changes. System Restart Auto Restart System Every …...
  • Page 43: Image Server

    System Name This is to give WebCAM a name identifiable in a SNMP network. System Contact This is to give the Administrator an identity in the SNMP network. System Location This is to set WebCAM SNMP location. Manager IP Address This set the LAN IP address where the administrator can manage WebCAM from.
  • Page 44 Fig.51 Image Server settings page Enable Choose Yes to enable this feature or No to disable. Community This is a security feature. Set a Community password to add an extra level of internet security to WebCAM. Community password is left blank by default. Click Apply to confirm settings.
  • Page 45 Fig.53 iMage account Registration page 3. Once registered, a confirmation email will be sent to your email address. You can now sign in to your account using your new iMage User ID. 4. Goto Add / Remove Unit, and enter the Serial Number and Community ID (if one has been set under Advanced Settings Community).
  • Page 46 Chapter 3: Web Interface Unit added to My List 5. Next click Return to My List, and and click on the “eye” icon to view the camera. Click on either opened “eye” icon to view the camera. WebCAM - user manual -43-...
  • Page 47: Language

    2.4.7 Language Use this section is to set WebCAM Interface language. Interface Language At the moment, the user can choose the following versions; a. Western version for; • English, • Spanish, • French, • Dutch, and • Portuguese. b. Eastern version for; •...
  • Page 48: About

    2.4.8 About The administrator can use this section to check firmware information, save/restore settings, upgrade firmware and see manufacturer’s details. About This shows the Firmware Version, Hardware Version and Serial Number. Save / Restore Settings Save Current Configuration Click Save to save the configuration to your PC. The text file will have a default format of YYYY_MMDD_####.cfg.
  • Page 49: Chapter 4: View Images Using Pda / Ppc / Mobile

    Chapter 4: View Images Using PDA / PPC / mobile WebCAM supports image viewing from a GRPS / WiFi enabled PDA / PPC / Symbian mobile device. To view the images; a. Make sure that the PDA / PPC / Mobile unit is connected to LAN or Internet. b.
  • Page 50 e. The default file name is showimg_pda.jpg, click Save As… to change the file name or save location. Note: The downloaded image size depends on the resolution set in Basic Settings Camera Settings Image Size. Approximately; 6KB @ 320x240 vs. 17KB @ 640x480 resolution. The images are downloaded and displayed one at a time.
  • Page 51: Chapter 5: Using The Utility

    Chapter 5: Using the Utility Section 1. Installation 1. Insert the enclosed Utility CD into the CD-ROM drive. The following menu will show up. Click on the buttons on the left to install the programs you want. Utility - This is a program that helps the user perform quick installation. It will detect the current configuration and take the user through the necessary network setup.
  • Page 52: Section 2. Using The Utility Program

    Section 2. Using the Utility Program The Utility main menu is shown below. The selection menu is located on the left. The Serial Number, current Firmware and IP Address of every WebCAM connected to the LAN will be displayed on the table to the right. 2.1 Setup Wizard Click Setup Wizard to take you through the setup process.
  • Page 53 4. Enter the necessary camera configurations. Choose the appropriate frequency (Indoor 60 Hz, Indoor 50 Hz or Outdoor) to prevent flickering on the video feed. Enter a name for the camera in the Location: box to identify the camera. 5. Click Next > to configure the Network Connection. Obtain an IP address by DHCP Choose this if you want your Router to assign an IP address to WebCAM.
  • Page 54 Obtain an IP address by Bootp Choose this if you want to allow WebCAM to obtain an IP address using Bootp protocol. 6. Click Next > to proceed to xDSL/Cable modem setup. Choose this if you want WebCAM to connect directly to your xDSL line. a.
  • Page 55 DDNS service allows you to assign a Domain Name to your Dynamic IP. This way, you will always be able to locate your device over the internet. (For more details see Chapter 4, Section 2.3.2, part v) 8. Click Next > to change your administrator account and password information. An administrator account is necessary to ensure privacy.
  • Page 56: Launch Mimic

    2.2 Launch WebCAM Click Launch WebCAM or double click the WebCAM listed in the table to launch it. WebCAM - user manual Chapter 5: Using the Utility Program Click either one to Launch WebCAM camera. -53-...
  • Page 57 WebCAM login screen will appear. Click Apply. Enter the Account (Login Name) and Password (Login Password) set earlier. Otherwise, use the default login and password at the back of WebCAM unit. If you did not configure one, then just click Apply to login. WebCAM User Interface webpage will appear.
  • Page 58: Ip Configuration

    2.3 IP Configuration This section allows you to configure the IP address for WebCAM. You do not have to edit this section if you have gone thru Setup Wizard earlier. Select the WebCAM unit on the right display screen, and click IP Configuration. This will bring up the following configuration window.
  • Page 59: Advanced (For Password And Http Configuration)

    Obtain an IP address by DHCP Choose this if you want your Router to assign an IP address to WebCAM. This is the default setting. Obtain an IP address by Bootp Choose this if you want to allow WebCAM to obtain an IP address using Bootp protocol.
  • Page 60 Once set, Utility will request for the Device Password when you try to click on either, Setup Wizard, Launch WebCAM or IP Configuration button. To remove the password, a. Select the WebCAM unit from the Utility list. b. Click IP Configuration. c.
  • Page 61: About

    Example: If a value of say, 8080 is set as the HTTP port number, then enter http://192.168.0.177:8080 in order to access WebCAM web interface. Uncheck to disable this function. 2.5 Upgrade Firmware Click this to bring up the upgrade firmware dialog box. To check the internet for the latest firmware, click Next Otherwise, check Upgrade the firmware with file saved on the local hard drive.
  • Page 62 Chapter 5: Using the Utility Program The user can do a manual search by clicking the Refresh. WebCAM - user manual -59-...
  • Page 63: Chapter 6: Multimonitor

    Chapter 6: MultiMonitor MultiMonitor is a program to manage multiple WebCAM. It is able to detect the IP address of all WebCAM installed in LAN and list them for easy management. Section 1. Installing MultiMonitor Click on setup.exe and follow the installation wizard After installation, there will be a WebCAM group in the Windows Start group Click “MultiMonitor”...
  • Page 64 Chapter 6: MultiMonitor Fill out the necessary information shown below and click Next >. WebCAM - user manual -61-...
  • Page 65 Click Finish and the MultiMonitor Logon window below will pop up. Just click OK to start using MultiMonitor Note: The default security Logon name is Admin, no password is set. To set a password, click User Change Password … WebCAM - user manual Chapter 6: MultiMonitor New Password -62-...
  • Page 66: Device

    2.1 Device Start MultiMonitor and press the “Enumerate” button, MultiMonitor will start a search for all the WebCAM units on the network and list them in the main window. Once detected, the following will show in the main window: This shows that the camera is online and active. This shows that the camera is off-line WebCAM - user manual Chapter 6: MultiMonitor...
  • Page 67 Chapter 6: MultiMonitor Manually adds the WebCAM camera to be monitored. a. Access by WebCAM Address Host Address: Enter either address (without webcam.myddns.com) or LAN IP of WebCAM (eg: 192.168.0.30) Remote Port: This is WebCAM UDP port. b. Access by Image Server Image Server Address: Enter the Image Server Address if available.
  • Page 68 Highlight the WebCAM to be deleted from MultiMonitor’s list. Click Yes to confirm deletion. Use this function to change WebCAM IP Address & Port Number. WebCAM - user manual Chapter 6: MultiMonitor -65-...
  • Page 69 Display the current Camera settings. Camera Select: Account: Password: Image Zoom: Camera Rotation: Mirror the Image: Maximum frame per second: Put Date/Time information on image WebCAM - user manual Chapter 6: MultiMonitor Select either camera A or B If you have setup user account, the information must Otherwise access will be denied.
  • Page 70 Display the Motion Detection Settings. Enable Motion Detect: Sensitivity: Window on-top when Motion Detected Mark Motion Detected object in Track Moving Object Image Recording Click “Start Recording when Motion Detected” to enable the feature. Click the “Details..” button for the following options; WebCAM - user manual Chapter 6: MultiMonitor Click...
  • Page 71 Image Compression: Recording AVI File Path Recorded files are save using the following file extension; avifile[three digit numerical sequence]. Note: Use the Detail View to check the stop time. You can change the display view or add a new folder here. Stop after idle for: Send AVI file Notification by...
  • Page 72 Chapter 6: MultiMonitor Configure Settings for Email Notification You will need to enter the correct Message Sender Information in order for WebCAM to send emails. Server Require Authentication Click Settings… then enter your Account Name and Account Password. Notified Email Address Click Add…...
  • Page 73 SNMP Settings Host Name: HTTP Port: Location: Manager: Using SNMP to update network ports Check this box if you want MultiMonitor to automatically update the HTTP port as set in; a. Web Interface, Basic Settings HTTP port number or in b.
  • Page 74 show the current date and time. Click to bring out zoom, resolution, direction and auto P/T controls. See below. Show current FPS. Click to record the current video onto your local PC. See below for recording options. Flip the image Rotate the image vertically.
  • Page 75 Click to auto pan tilt the camera Click on this icon to active two functions; a. Custom window zoom – use this to zoom to your chosen window size. On the video window, LEFT click, hold and drag to the desired window zoom size.
  • Page 76 Release and the program will zoom to the marquee area. Increase the resolution for a better image quality. While zoomed in, the user can digitally pan or tilt the camera window. Even if it is a static camera! Click the depressed the zoom bar to the left.
  • Page 77: View

    Release to set the window frame. Video in this custom window will be updated while those outside are ‘frozen’. You can digitally pan and tilt the smaller window while in this state. Only video in the custom window will be updated. This feature works with Static or Pan Tilt Camera.
  • Page 78: User

    Set the SNMP Parameter. 2.4 User Change Change Password … Password Use this feature to change the User’s login password to iMultiView. Administrator or User can change their passwords. Account Management… Use this section to Add, Delete or Change the Password of an Account. WebCAM - user manual Either Account...
  • Page 79: Help

    Add User… There is no limit to the number of Account that can be added. Note: The first account is set to Administrator permission. This cannot be changed or deleted. Account: Password: Permission: Choose Manager or User. 2.5 Help Help Display MultiMonitor version, Copyright information and product service contact.
  • Page 80: Drag-And-Drop Feature

    Chapter 6: MultiMonitor 2.6 Drag-and-Drop Feature MultiMonitor feature a “Drag-and-Drop to Desktop” function. Double click the icon on your desktop to immediately view the video. Useful when monitoring multiple cameras at a time. Step 1: Select the camera location of your choice.
  • Page 81 Chapter 6: MultiMonitor Step 4: Double click on the icon on the desktop, to view the images. WebCAM - user manual -78-...
  • Page 82: Appendix A: Router Configuration

    If your particular router manufacturer or model is not listed below, please contact your router manufacturer for further assistance in configuring the router. The Following Router manufacturers and models are included in this document: Brand Model 3Com 3C857-US 3CRWE52196 Belkin F5D6230-3 F5D7230-4–...
  • Page 83 MN-500 NETGEAR RP614 MR814 MR314 FVS318 Proxim ORiNOCO Broadband Gateway Siemens SpeedStream 2602 SpeedStream 2623 SpeedStream 2604 SpeedStream 2624 SMC2404WBR SMC7004VBR SMC7004CWBR SMC7004AWBR WebCAM - user manual Appendix A: Router Configuration Wireless Base Station Web Safe Router Wireless Router Cable/DSL Wireless Router ProSafe VPN Firewall BG-2000 2-Port DSL/Cable Router...
  • Page 84 Appendix A: Router Configuration 3Com (http://www.3com.com) 3C857-US – OfficeConnect Cable/DSL Gateway 3CRWE52196 – OfficeConnect Wireless Cable/DSL Gateway 1. Log into your router using your router IP. 2. On the main page, select Firewalls on the left side of the page.
  • Page 85 Belkin (http://www.belkin.com) F5D6230-3 – Wireless Cable/DSL Gateway Router 1. Log into your router using your router IP. 2. On the main page, select Virtual Server on the left side of the page under the Securit section. 3. Enter the following information on the page: Line #1: Private IP: Type in the camera’s IP address.
  • Page 86 Private Port 80 to 80 Line #2 Enable: Checked in Description: WebCAM – Camera Internet Port: 9001 to 9001 Type: Private IP address: Type in the camera’s IP address. (Look on the WebCAM Address LCD display for the last 3 digits of the camera’s IP address) Private Port 9001 to 9001...
  • Page 87 D-Link (http://www.dlink.com) DI-604/DI – 614+/DI-624 1. Log into your router using your router IP. 2. On the main page, click on Advanced at the top of the page. 3. On the left side of the page, click on Virtual Server. Note: Make sure DMZ host is disabled.
  • Page 88 Enabled/Disabled: Enabled For ID#2 Service Port: 9001 Service IP: Type in the camera’s IP address, for example: 192.168.0.5 Enabled/Disabled: Enabled 4. Save your settings. WebCAM should now be configured to work with your router and be accessible from the internet. DI714 1.
  • Page 89 Appendix A: Router Configuration Dell (http://www.dell.com) TrueMobile 2300 Wireless Broadband Router 1. Log into your router using your router IP. 2. On the main page, click on Advanced Settings at the top of the page. 3. Go to the Port Forwarding section and select Custom Port Forwarding Settings. 4.
  • Page 90 Linksys (http://www.linksys.com) BEFSR41 – EtherFast Cable/DSL Router BEFSX41 – Instant Broadband EtherFast Cable/DSL Firewall Router with 4-Port Switch/VPN EndPoint BEFW11S4 – Wireless Access Point Router with 4-Port Switch – Version 2 1. Log into your router using your router IP. 2.
  • Page 91 Appendix A: Router Configuration Microsoft (http://www.microsoft.com/hardware/broadbandnetworking) MN-100 – Wired Base Station MN-500 – Wireless Base Station 1. Log into your router using your router IP. 2. Open the Bass Station Management Tool, and then click Security. 3. On the Security menu, click Port Forwarding, and then click Set up persistent port forwarding.
  • Page 92 NETGEAR (http://www.netgear.com) RP614 – Web Safe Router MR814 – Wireless Router 1. Log into your router using your router IP. 2. Click Advanced -> Port Forwarding on the left side of the page. 3. Click Add Customer Service. 4. Enter the following information on the page: Service Name: Starting Port: Ending Port:...
  • Page 93 Line #2: Starting Port: Ending Port: Server IP Address: 5. Click Apply to save the settings. WebCAM should now be configured to work with your router and be accessible from the internet. FVS318 – ProSafe VPN Firewall 1. Log into your router using your router IP. 2.
  • Page 94 D. Local Server Address: Enter the IP address of the camera E. WAN Users Address: Any F. Click Apply. 12. Click Add again. A. For Service name select: WebCAM Cam B. Action: ALLOW always C. Local Server Address: Enter the IP address of the camera D.
  • Page 95 Proxim (http://www.proxim.com) ORiNOCO BG-2000 Broadband Gateway 1. Log into your router using your router IP. 2. On the router’s main page, click on Setup at the top of the page. 3. On the left side of the page, click on Advanced settings -> Port Forwarding. 4.
  • Page 96 Siemens (http://www.speedstream.com) SpeedStream 2602 – 2-Port DSL/Cable Router SpeedStream 2623 – Wireless DSL/Cable Router SpeedStream 2624 – Wireless DSL/Cable Router 1. Log into your router using your router IP. 2. After you are logged in, click on Advanced Setup -> Virtual Servers. 3.
  • Page 97 Appendix A: Router Configuration 7. Under Internal Port No type in: 80 8. Under External Port No type in: 80 9. Click on Add to save these settings. 10. Under the first box, next to the Enable checkbox, type in: WebCAM Cam. 11.
  • Page 98 SMC (http://www.smc.com) SMC2404WBR – Barricada Turbo 11/22 Mbps Wireless Cable/DSL Broadband Router SMC7004VBR – Barricada Cable/DSL Broadband Router SMC7004CWBR – Barricada Wireless Cable/DSL Broadband Router 1. Log into your router using your router IP. 2. After you are logged in, click NAT on the left side of the page. 3.
  • Page 99 For ID #2: Service Port: Private IP: Enable: 4. Click Save to save the settings. WebCAM should now be configured to work with your router and be accessible from the Internet. WebCAM - user manual Appendix A: Router Configuration 9001 Type in the camera’s IP address, for example: 192.168.0.5 (Look at WebCAM’s IP Address LCD display for the last 3 digits of the camera’s IP address)
  • Page 100: Appendix B: Methods To Update Webcam Firmware

    Appendix B: Methods to Update WebCAM Firmware You can update WebCAM firmware using any of the following methods. Method 1: Through WebCAM Web Page (1) Enter the WebCAM Web Page (2) Go to “About”, click “update software” and you will be automatically linked for update.
  • Page 101: Appendix C: Ip Address, Subnet And Gateway

    Appendix C: IP Address, Subnet and Gateway This section discusses Communities, Gateways, IP Addresses and Subnet masking Communities A community is a string of printable ASCII characters that identifies a user group with the same access privileges. For example, a common community name is “public”. For security purposes, the SNMP agent validates requests before responding.
  • Page 102 Subnetting and Subnet Masks Subnetting divides a network address into sub-network addresses to accommodate more than one physical network on a logical network. For example: A Class B company has 100 LANs (Local Area Networks) with 100 to 200 nodes on each LAN.
  • Page 103: Appendix D: Glossary

    Appendix D: Glossary The Glossary section defines the terms used in this User Manual Term Definition Ethernet Local Area Network technology, originally developed by Xerox Corporation, can link up to 1,024 nodes in a bus network. Ethernet provides raw data transfer in a rate of 10 megabits/sec. with actual throughputs in 2 to 3 megabits/sec.
