4. Use the removeChannelFromScanner command to remove a channel from the scanning
procedure. In the id field, enter the ID of the scanned channel (the IDs are shown in the
results of the showScanner operation).
Figure 5-3: removeChannelfromScanner screen
5. To add a channel for scanning purposes, select the addChannelToScanner command.
Figure 5-4: addChannelToScanner screen
Enter the bandwidth and the frequency. An ID will be allocated automatically.
Note
The frequency and bandwidth should match the cBST configuration
6. To display physical statistics on the downlink, choose "SS" tab, from the menu on the left
hand side of the screen, choose showSsPhyStatDl. Press the "CALL" button. Check the SS
RSSI and CINR levels. Hit the "CALL" button to refresh the screen.
Figure 5-5: showSsPhyStatDl screen
WiN5200
Equipment Configuration and Monitoring | 40
