Three bar LEDs are On
Four bar LEDs are On
Five bar LEDs are On
Six bar LEDs are On
Seven bar LEDs are On
Eight bar LEDs are On
Only the 8
significant)
WiN5200
th
LED is On (Most
Green
15dB = SNR < 20dB
Green
20dB = SNR < 24dB
Green
SNR = 24dB and RSSI < -75dBm
Green
SNR = 24dB and RSSI = -75dBm
Green
SNR = 24dB and RSSI = -70dBm
Green
SNR = 24dB and RSSI = -60dBm
Green
RSSI = -20dBm (saturation)
Product Description | 26
