- Page 1 MODEL Burner Instruction Manual Type “F” air tube combinations Voltage: 120 Vac / 60 Hz Model AF Burner Beckett...
-
Page 2: Table Of Contents
AF72XO AF90XO AF104XO AF130XO AF160XO 1.65-2.50 2 ¾ AF44XP AF53XP AF65XP AF72XP AF90XP AF104XP AF130XP AF160XP 2.50-3.00 None AF44XS AF53XS AF65XS AF72XS AF90XS AF104XS AF130XS AF160XS *Refer to Beckett OEM Specification Guide, Part No. 6711, for non-standard air tube combinations... -
Page 3: Verify Specifications
NOTICE or controls during unpacking, notify the carrier at once and file the appropriate claim. When contacting Beckett for service information — Please NOTICE record the burner serial number (and have available when calling or writing). You will find the serial number on the silver label located on the left rear of the burner. -
Page 4: Inspect/Prepare Installation Site
Refer to separate instruction sheet supplied with AF outside air kit for 2.00 13 ½ installation. This optional kit allows combustion air to be piped directly to the burner (Beckett part number 51747). 2.50 You must install the outside air kit strictly following the kit WARNING 3.00... -
Page 5: Prepare Burner
If the nozzle is not installed, obtain a nozzle of the manufacturer, capacity and Servicing nozzle line assembly spray angle specified in appliance manufacturer’s information or Beckett OEM 1. Turn off power to burner before proceeding. Specification Guide, part number 6711. For conversions or upgrades, when 2. -
Page 6: Check/Adjust "Z" Dimension
S (adapter to static plate), ± (Note 1) straight edge across the head, measure the distance to the face of the head. (A Beckett T gauge may also be used.) Q (nozzle line length) • Slide the nozzle line forward or back until this dimension for F heads is 1⅛"... -
Page 7: Mount Burner On Appliance
Mounting dimensions against the appliance or the ceiling joists (to avoid vibration noise). • When using the Beckett universal adjustable flange, mount the air tube at Never use Teflon tape on any fuel fitting. Tape fragments can a 2° downward pitch unless otherwise specified by the appliance... - Page 8 Beckett Instruction Manual – Model AF Oil Burner Pipe, wire, and adjust burner Figure 4 – Typical wiring, R8184G or equivalent primary control Electrical shock hazard. Disconnect DANGER power before servicing. SK9437 Figure 5 – Typical wiring, R7184 primary control (R7184P shown) DANGER Electrical shock hazard.
-
Page 9: Startup Burner/Set Combustion
• For R7184 primary controls, see Technician’s Quick Reference Guide, Check all wiring for secure connections or insulation breaks. Beckett part number 61351, for special pump priming sequence. Check the pump pressure and cutoff function. • Prepare for combustion tests by drilling a ¼" sampling hole in the flue Check primary control safety lockout timing. -
Page 10: Replacement Parts
Beckett Instruction Manual – Model AF Oil Burner Service & maintain burner Replacement parts SK9462D Item Description Part Number Item Description Part Number Burner housing assembly 5624B Blower wheel (use only RWB replacement) 2459U Coupling 2454 Air band assembly – 8 slot... -
Page 11: Owner's Information
Beckett Instruction Manual – Model AF Oil Burner Service & maintain burner Owner’s information WARNING This burner must be installed, adjusted and started only by a qualified service agency — an individual or agency, licensed and experienced with all codes and ordinances, who is responsible for the installation and adjustment of the equipment. -
Page 12: Owner Service And Maintenance
BECKETT R.W. CORPORATION U.S.A.: P.O. Box 1289 • Elyria, Ohio 44036 Canada: R.W. Beckett Canada, Ltd. • Unit #3, 430 Laird Road • Guelph, Ontario N1G 3X7 Form Number 6104BAF R0803 Printed in U.S.A. © 2003 R.W. Beckett Corporation Bar code...
