Initial installation
Setting options for the satellite system (single satellite):
Select single
INITIAL INSTALLATION (DVB-S)
satellite
Select single satellite
Astra1 19,2°E
Hot Bird 13°E
Astra2 28,2°E
Astra3 23,5°E
Atlantic Bird1 12,5 °W
Atlantic Bird2 8°W
Atlantic Bird3 5°W
Eurobird1 28,5°E
Eurobird 9A 9°E
Eutelsat W2 16°E
Eutelsat W3A 7°E
Eutelsat W4 36°E
Proceed
OK
Select satellite,
OK Proceed.
Network
INITIAL INSTALLATION
selection
Network selection
other network
CanalDigitaal
Proceed
OK
Select network.
If several networks are available over DVB-S, you
can decide which network you want to receive your
channels from.
OK Proceed.
High band
INITIAL INSTALLATION (DVB-S)
High band
no yes (with 0/22 kHz)
Proceed
OK
High band no / yes.
Specify here whether the high band of the selected
satellite is to be searched in addition to the low
band.
OK Proceed.
LNB
INITIAL INSTALLATION (DVB-S)
frequencies LNB frequencies
Low band
High band
Proceed
OK
Set LNB frequencies.
Normally, you do not need to change the values for
high and low band, unless the LNC (LNB) of your
satellite system uses a different oscillator frequency
(important for the frequency display).
OK Proceed.
(with Setting options for DVB-S reception (continued)
on page 29).
Hellas Sat2 39°E
OK
Hispasat 30°W
Intelsat10 02 1°W
Intelsat901 18°W
Nilesat 7°W
Pan Am Sat 43°W
Sirius2/3 5°E
Telekom2C 5°W
Telekom2D 8°W
Telestar12 12,5°W
Thor2/3 0,8°W
Türksat 42°E
OK
Back
OK
Back
9750 MHz
10600 MHz
Back
Setting options for the satellite system (2 satellites on 22 kHz switchbox
/ 2 satellites on toneburst switch):
Satellite
INITIAL INSTALLATION (DVB-S)
selection
Satellite selection
Satellite 1
Satellite 2
Proceed
OK
Select Satellite 1 / Satellite 2,
select satellites from list,
OK Proceed.
Network
INITIAL INSTALLATION
selection
Network selection
other network
CanalDigitaal
Proceed
OK
Select network.
If several networks are available over DVB-S, you
can decide which network you want to receive your
channels from.
OK Proceed.
LNB
INITIAL INSTALLATION (DVB-S)
frequencies
LNB frequencies
ASTRA1 19,2°E
(22 kHz
Hot Bird 13°E
switchbox)
Proceed
OK
LNB
INITIAL INSTALLATION (DVB-S)
frequencies
LNB frequencies
ASTRA1 19,2°E Low band
(toneburst
ASTRA1 19,2°E High band
Hot Bird 13°E Low band
switch)
Hot Bird 13°E High band
Proceed
OK
Set LNB frequencies.
Normally, you do not need to change the values for
high and low band, unless the LNC (LNB) of your
satellite system uses a different oscillator frequency
(important for the frequency display).
OK Proceed.
(with Setting options for DVB-S reception (continued)
on page 29).
Astra1 19,2°E ...
Hot Bird 13°E
Back
OK
Back
9750 MHz
9750 MHz
Back
9750 MHz
10600 MHz
9750 MHz
10600 MHz
Back
