PreMIuM veNT-Free
uNIverSAL FIrebOxeS
INSTALLer:
Leave this manual with the appliance.
cONSuMer:
Retain this manual for future reference.
wArNINg
FIre Or exPLOSION hAZArD
Failure to follow safety warnings exactly
could result in serious injury, death or
property damage.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— whAT TO DO IF yOu SMeLL gAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Leave the building immediately.
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
INSTALLATION INSTrucTIONS
AND OwNer'S MANuAL
GAS-FIRED
ANSI Z21.91
Ventless Fireplace
Enclosures
for Gas Fired
Decorative Type
Unvented Room
Heaters
uNIverSAL FIrebOx
FOr ALL veNT-Free
LOg SeTS MODeLS:
vFP32Fb0F- 6
vFP36Fb0F- 6
vFP32Fb0L- 6
vFP36Fb0L- 6
vFP36Fb2AF- 6
vFP36Fb2AL- 6
wArNINg
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Refer to this manual. For
assistance or additional information, con-
sult a qualified installer, service agency or
the gas supplier.
FOr uSe ONLy wITh A LISTeD gAS-FIreD
uNveNTeD DecOrATIve rOOM heATer NOT TO
exceeD 40,000 bTu/h. Do not build a wood fire.
Do not attempt to modify or alter the construc-
tion of the firebox or its components. Any modi-
fication or alteration of construction may void
the warranty of this firebox. Children and adults
should be alerted to the hazards of high surface
temperature and should stay away to avoid burns
or clothing ignition. Young children should be
carefully supervised when they are in the same
room as the firebox.
Carefully review the instructions supplied with
the decorative type unvented room heater for
the minimum fireplace size requirement. Do not
install a vent-free log set in this firebox, unless
this firebox meets the minimum dimensions
required for the installation.
vFP42Fb0F- 6
vFP42Fb0L- 6
vFP42Fb2AF- 6
vFP42Fb2AL- 6
Page 1
