Suunto D9 Instruction Manual

Hide thumbs Also See for D9:
Table of Contents

Advertisement

Quick Links

Download this manual
EN

Advertisement

Table of Contents
loading

Related Manuals for Suunto D9

Summary of Contents for Suunto D9

  • Page 2 QUICK REFERENCE GUIDE Present Depth Active Water Contact Daily Alarm Indicator Indicator Dive Alarm Indicator Diver Attention Symbol Do Not Fly Icon Current Time Display Mode Indicator No-Decompression Time Total Ascent Time Ceiling Depth Safety Stop Indicator Safety/Deep Stop Time Surface Interval Time No-Fly Time Remaining Air Time...
  • Page 3 SUUNTO, D9, Consumed Bottom Time (CBT), Oxygen Limit Fraction (OLF), SUUN- TO Reduced Gradient Bubble Model (RGBM), Continuous Decompression and their logos are all registered or unregistered trademarks of SUUNTO. All rights are reser- ved. This product is protected by the following patents and patent applications:...
  • Page 4 The D9 is designed to comply with this standard. ISO 9001 SUUNTO Oy’s Quality Assurance System is certifi ed by Det Norske Veritas to be ac- cording to the ISO 9001 in all SUUNTO Oy’s operations (Quality Certifi cate No. 96-...
  • Page 5 SUUNTO Oy does not assume any responsibility for losses or claims by third parties, which may arise through the use of this device. Due to continuous product development, the D9 is subject to change without notice.

  • Page 6: Warnings

    The demands of commercial or professional diving may expose the diver to depths and exposures that tend to increase the risk of decompression ill- ness (DCI). Therefore, Suunto strongly recommends that the device be not used for commercial or professional diving activity.
  • Page 7 As an added measure of safety, you should consult a physician regarding your fi t- ness before diving. WARNING! SUUNTO STRONGLY RECOMMENDS THAT SPORT DIVERS LIMIT THEIR MA- XIMUM DEPTH TO 40 M [130 FT] OR TO THE DEPTH CALCULATED BY THE COMPUTER BASED ON THE SELECTED O % AND A MAXIMUM PO OF 1.4...
  • Page 8 WARNING! DIVES WITH REQUIRED DECOMPRESSION STOPS ARE NOT RECOMMEN- DED. YOU SHOULD ASCEND AND BEGIN DECOMPRESSION IMMEDIATELY WHEN THE DIVE COMPUTER SHOWS YOU THAT A DECOMPRESSION STOP IS REQUIRED! Note the blinking ASC TIME symbol and the upward pointing arrow. WARNING! USE BACK-UP INSTRUMENTS! Make sure that you use back-up instrumentati- on including a depth gauge, submersible pressure gauge, timer or watch, and have...
  • Page 9 WARNING! DO NOT EXPOSE THE D9´S OPTIONAL PRESSURE TRANSMITTER TO ANY GAS MIX CONTAINING MORE THAN 40% OXYGEN! Enriched air with greater oxygen content presents a risk of fi re or explosion and serious injury or death.
  • Page 10 WARNING! THE DIVE COMPUTER WILL NOT ACCEPT FRACTIONAL PERCENTAGE VA- LUES OF OXYGEN CONCENTRATION. DO NOT ROUND UP FRACTIONAL PERCENTAGES! For example, 31.8% oxygen should be entered as 31%. Roun- ding up will cause nitrogen percentages to be understated and will affect decom- pression calculations.
  • Page 11 NOTE! It is not possible to change between Air, Nitrox and Gauge modes before the instru- ment has counted down the no-fl ying time. There is one exception to this: You can change from Air to Nitrox mode even during the no-fl...

  • Page 12: Table Of Contents

    TABLE OF CONTENTS WARNINGS! ......................4 1. INTRODUCTION....................14 1.1. SAFETY PRECAUTIONS ................16 1.1.1. EMERGENCY ASCENTS...............16 1.1.2. DIVE COMPUTER LIMITATIONS ..........17 1.1.3. NITROX ..................17 1.1.4. FREEDIVING..................18 2. GETTING ACQUAINTED..................19 2.1. DISPLAY AND BUTTONS .................19 2.2. WATER CONTACTS .................21 2.3. OPERATING MODES................22 2.4. WIRELESS PRESSURE TRANSMISSION ..........23 2.5.
  • Page 13 3.3.7. TONES ...................29 4. COMPASS MODE ....................29 4.1. ACCESSING THE COMPASS..............29 4.2. COMPASS DISPLAY .................29 4.3. COMPASS SETTINGS ................31 4.3.1. DECLINATION................31 4.3.2. CALIBRATE..................31 5. BEFORE DIVING ....................34 5.1. ACTIVATION AND PRECHECKS..............34 5.1.1. DIVE MODE ACTIVATION .............34 5.1.2. BATTERY POWER INDICATION...........36 5.1.3.
  • Page 14 5.3. WIRELESS TRANSMISSION SETUP ............48 5.3.1. INSTALLING THE WIRELESS TRANSMITTER ......48 5.3.2. PAIRING AND CODE SELECTION..........49 5.3.3. TRANSMISSION DATA..............51 6. DIVING WITH THE SUUNTO D9................54 6.1. DIVING IN AIR MODE [DIVEAIR] ..............54 6.1.1. BASIC DIVE DATA .................54 6.1.2. BOOKMARK ...................55 6.1.3.
  • Page 15 9.4. WATER RESISTANCE INSPECTION ............92 9.5. BATTERY REPLACEMENT...............93 9.5.1. COMPUTER BATTERY REPLACEMENT........93 9.5.2. WIRELESS TRANSMITTER BATTERY REPLACEMENT .....94 10. TECHNICAL DATA .....................97 10.1. TECHNICAL SPECIFICATION ..............97 10.2. SUUNTO REDUCED GRADIENT BUBBLE MODEL (RGBM) ....102 10.3. OXYGEN EXPOSURE................106 11. WARRANTY......................108 12. GLOSSARY ......................111...

  • Page 16: Introduction

    1. INTRODUCTION Congratulations on your purchase of the SUUNTO D9 dive computer. The D9 builds on the Suunto tradition of delivering feature-rich dive computers and provides many new and enhanced features that cannot be found in other dive computers, such as di- gital compass, gas switching and optional wireless air-integration.
  • Page 17 • The Suunto RGBM/Deep Stop Algorithm The Suunto Reduced Gradient Bubble Model (RGBM) utilized in the D9 predicts both dissolved and free gas in blood and tissues of divers. It is a signifi cant advance on the classic Haldane models, which do not predict free gas. The advantage of Suunto RG- BM is additional safety through its ability to adapt to a variety of situations and dive profi...

  • Page 18: Safety Precautions

    Make sure that you fully understand the use, displays and limitations of the instrument. If you have any questions about the manual or the dive computer, contact your SUUNTO dealer before diving with the dive com- puter.

  • Page 19: Dive Computer Limitations

    STEP 1: Assess the situation calmly and then move promptly to less than 18 m [60 ft]. STEP 2: At 18 m [60 ft], slow down your ascent rate to 10 m/min [33 ft/min] and move to a depth between 3 and 6 meters [10 to 20 ft]. STEP 3: Stay there as long as you assess your air supply will safely allow.

  • Page 20: Freediving

    DIVING IS NOT RECOMMENDED. You should avoid freediving and not exceed fi ve meters [16 ft] for at least two hours after scuba diving. Suunto also recommends you to be trained in freediving technique and physiology be- fore conducting breathhold dives. No dive computer can replace the need for proper...

  • Page 21: Getting Acquainted

    Calibrate and test the compass function. If the D9 is to be used with the optional wireless pressure transmitter install it and enable the pressure transmission in the D9’s settings. Try the pressure trans- mission.
  • Page 22 Long continuous push (> 2 sec.): To activate the electroluminescent backlight in the other modes • Select (S) Button Short push: To select a sub mode • To accept the settings in the Setting Mode • To select the active segment in the Setting Mode •...

  • Page 23: Water Contacts

    Long continuous push (> 2 sec.): To enable gas switching in Nitrox mode. • Down (DOWN) Button Short push: To toggle between date, second or dual time display in the Watch mode • To change submode • To decrease the value in the Setting Mode •...

  • Page 24: Operating Modes

    2.3. OPERATING MODES The Suunto D9 provides three main operating modes, time mode (TIME), dive mode (DIVE) and memory mode (MEM). In addition a compass mode can be activated from the TIME and DIVE modes.

  • Page 25: Wireless Pressure Transmission

    In order to use the transmitter the wireless integration needs to be enabled in the D9’s settings. To enable or disable the wireless integration refer to chapter 5.2.8 Tank pressure set- tings. Fig. 2.5. D9’s optional wire-...

  • Page 26: Pc-Interface

    The PC interface cable is connected to the right side of the Suunto D9 (fi g. 2.6), and to the USB port of your PC. For instructions on how to install and use the Dive Manager Soft- Fig. 2.6. Connecting D9’s PC- ware refer to chapter 8.1 Suunto Dive Manager.

  • Page 27: Stopwatch (Timer)

    DOWN buttons when in TIME mode until the stopwatch display appears. (Fig. 3.1 d). c) the dual The stopwatch of the D9 lets you measure elapsed and split time is times. The range of the stopwatch is 99 hours, 59 minutes, displayed 59.9 seconds (Fig.

  • Page 28: Time Mode Settings

    3.3. TIME MODE SETTINGS To enter the time mode settings press the DOWN button for >2s when in TIME mode. The display will briefl y display “Time Settings” (Fig 3.3), and then display the fi rst available setting. The settings available in TIME mode are: 1.

  • Page 29: Time

    The daily alarm settings include: activate/deactivate daily alarm [on/off] • set the desired alarm hour [hh] • set the desired alarm minute [mm] • 3.3.2. TIME In Time/Date setting mode you are able to: Fig. 3.5. Adjusting Daily Alarm set the desired hour [hh] •...

  • Page 30: Units

    NOTE! The day of the week is automatically calculated in ac- • cordance with the date. The date can be set within the range of Jan 1, 2000 to • Dec. 31, 2089. 3.3.5. UNITS Fig. 3.8. Entering Dual Time Settings In Units setting mode you can: switch between metric/imperial units [metr./imp]...

  • Page 31: Tones

    • 4. COMPASS MODE Fig. 3.11 Adjusting Date The Suunto D9 is the fi rst dive computer in the world to in- clude a digital compass, which can be used both while diving as on the surface. 4.1. ACCESSING THE COMPASS The compass function can be called from both the TIME and DIVE modes.
  • Page 32 (TIME or DIVE). LOCKING A BEARING To lock a bearing move your D9 horizontally until the intended bearing is displayed. Press SELECT to lock the bearing. The directional arrows above the compass rose will guide you to- wards the locked bearing as described below.

  • Page 33: Compass Settings

    4.3.2. CALIBRATE Because of changes in the surrounding magnetic fi eld the D9 electronic compass occasionally needs to be re-calibra- ted. During the calibration process the compass adjusts itself to the surrounding magnetic fi eld. As a basic rule, you should calibrate the compass when it does not seem to operate pro- perly, or after replacing the D9 battery.
  • Page 34 Strong electromagnetic fi elds, such as powerlines, loudspea- kers and magnets can affect the compass calibration. It is the- refore advisable to calibrate the compass if the D9 has been exposed to these fi elds. NOTE! It is recommended to calibrate the compass before using it at a new location.
  • Page 35 Fig. 4.6. Setting Fig. 4.7. Entering Compass Declination Calibration Fig. 4.8. Compass Calibration a) Hold the Suunto D9 b) Graph indicates c) Compass proper- d) Calibration failed, level, and slowly rotate progress during ly calibrated and rea- try again.

  • Page 36: Before Diving

    5. BEFORE DIVING Fig. 5.1 Dive Modes 5.1. ACTIVATION AND PRECHECKS The Suunto D9 has three diving modes: Air mode (Fig 5.1a) for diving with standard air only, Nitrox mode (Fig 5.1b) for diving with oxygen enriched mixtures and Gauge mode (Fig 5.1c) for use as bottomtimer and for freediving.
  • Page 37 and personal settings are displayed (Fig. 5.3) A few seconds later the battery power indicator is shown (Fig. 5.4.) At this time, perform your prechecks making sure that: the instrument operates in the correct mode and pro- • vides a complete display (Air/Nitrox/Gauge mode) the battery level is ok •...

  • Page 38: Battery Power Indication

    you have enough air for your planned dive. You Fig. 5.4 Battery check: • should also check the pressure reading against your back-up pressure gauge. And if set to Nitrox mode (refer to chapter 6.2 Diving in Nitrox mode), make sure that: the correct number of mixes are set and that the oxy- •...

  • Page 39: Diving At Altitude

    display is faded or weak, the battery may be too low to ope- rate the dive computer and battery replacement is recommen- ded. NOTE! For safety reasons the backlight cannot be activated when the low battery warning is indicated by the battery sym- bol.

  • Page 40: Personal Adjustments

    TABLE 5.1. ALTITUDE ADJUSTMENT RANGES Altitude Mode Altitude Range 0-300m [0-1000ft] 300-1500m [1000-5000ft] 1500-3000m [5000-10000ft] Fig. 5.7. Entering Air Dive Settings Section 5.2.4. ”Altitude Adjustment and Personal Adjustment Setting” describes how the Altitude Mode is adjusted. Traveling to a higher elevation can temporarily cause a chan- ge in the equilibrium of dissolved nitrogen in the body.
  • Page 41 The personal factors which tend to increase the possibility of DCI include, but are not limited to: - cold exposure - water temperature less than 20 °C [68 °F] - the diver is below average physical fi tness level - diver fatigue - diver dehydration Fig.
  • Page 42 Some mentioned factors or conditions exist Several mentioned factors or conditions exist The D9 also allows experienced divers who are willing to accept a greater level of risk to adjust the RGBM model. The default setting is 100% which gives full RGBM effect.

  • Page 43: Safety Stops

    Reasons to perform a safety stop include a reduction in sub clinical DCI, microbubble reduction, ascent control, and orientation before surfacing. The D9 displays two different types of safety stops: Recom- Fig. 5.11. Setting Dive Ti- me Alarm. Press up/down mended Safety Stop and Mandatory Safety Stop.
  • Page 44 The Suunto RGBM calculation model responds to this by adding a Mandatory Safety Stop to the di- ve. The time of this Mandatory Safety Stop will depend on the severity of the ascent rate excess. The STOP sign will appear in the display and when you reach...

  • Page 45: Deep Stops

    (MIX2, MIX3). terval time before your next dive. 5.1.6. DEEP STOPS The Suunto D9 allows the user to choose a Deep Stop al- gorithm instead of the traditional recommended safety stop. Deep Stops are decompression stops that occur deeper than traditional stops, with the purpose of minimizing microbubble formation and excitation.

  • Page 46: Dive Mode Settings

    5.2. DIVE MODE SETTINGS This D9 has several User Defi nable Functions and depth and time related alarms that you can set according to your perso- nal preference. The dive mode settings are dependent on the DIVE sub-mode chosen (Air, EAN, Gauge), so that e.g. nitrox settings are only available in the DIVEean sub-mode.

  • Page 47: Dive Time Alarm

    5.2.2. DIVE TIME ALARM The instrument has one Dive Time Alarm Setting, which can be used for several purposes to add to your diving safety (Fig 5.10). The alarm can be set, for example, to your planned bot- tom time. The Dive Time alarm can be set on or off and the ti- me from 1 to 999 minutes (Fig.5.11).

  • Page 48: Personal/Altitude Settings

    The default oxygen percentage (O %) setting is 21% (air) and oxygen partial pressure (PO ) setting 1.4 bar. After entering values for MIX1 you can enable/disable and set additional gas mixes MIX2 and MIX3 (Fig. 5.12-5.14). NOTE! If only MIX 1 is enabled (MIX2/3 set OFF), MIX1 will revert to default settings (21% O and PO 1.4 bar) after ap-...

  • Page 49: Safety Stops/Deepstops

    5.2.6. SAFETY STOPS/DEEPSTOPS The deepstop setting allows the user to choose between tra- ditional safety stops or deep stops. If Deepstops are set to OFF, traditional safety stop calculation is used. If set to ON, iterative Deepstops will be prompted instead. The length of the individual deepstops can be set to 1 or 2 minutes.

  • Page 50: Units

    Fig. 5.25. Entering Unit settings 2. Thread the high pressure transmitter of the D9 into the HP port of your regulator with your fi ngers. DO NOT OVERTIGHTEN! Maximum torque 6 Nm (4.4...

  • Page 51: Pairing And Code Selection

    D9’s transmitter. When there is no stored code the D9 will display “cd:--” and receive with lowered sensitivity from a very short distance on- ly (Fig. 5.30 a). By taking the D9 close to the transmitter it will...
  • Page 52 HP port and that the regulator is pro- transmitter perly attached to the cylinder. 2. Ensure that the D9 is turned on, an that the wireless integration is enabled in the D9’s settings (HP set on, see chapter 5.2.8). The D9 should display “cd:--” in the lower left corner of the alternative display.

  • Page 53: Transmission Data

    The pressure is displayed in either bars or psi depending on the unit selecti- on. Any time the D9 receives an appropriate signal it fl ashes the lightning fi gure in the display’s lower left corner. A pressure reading of over 360 bar [5220 psi] will display as “---“...
  • Page 54 If the dive is started without that the D9 and the transmitter have been properly paired, the D9 will indicate that no cylinder data is available by displaying “OFF” (Fig. 5.30e). TABLE 5.3. PRESSURE TRANSMISSION RELATED DISPLAYS Display Indication Figure 5.30 Cd:-- Set Code.
  • Page 55 a) Set code b) Overpressure c) Fail d) Low battery e) Off Fig 5.30. Pressure transmission related displays...

  • Page 56: Diving With The Suunto D9

    6.1. DIVING IN AIR MODE [DIVEAIR] Fig. 6.1. Dive has just be- gun and available no-de- The D9 has three diving modes: Air mode (DIVEair) for diving compression time is over with standard air only, Nitrox mode (DIVEean) for diving with 99min.

  • Page 57: Bookmark

    the ascent rate by a bar graph on the right side the Diver Attention Symbol if surface interval should be prolonged (see Table 6.1.) Alternative displays by pressing the UP/DOWN buttons: the elapsed dive time in minutes, shown as DIVE TIME the water in temperature in °C [°F] Fig.

  • Page 58: Tank Pressure Data

    to Dive Manager. The bookmark logs the depth, time and wa- ter temperature as well as compass heading and tank pressu- re when available. To make a bookmark in the profi le memory during a dive press the SELECT button. A brief confi rmation will be given (Fig.

  • Page 59: Ascent Rate Indicator

    The remaining air time calculation includes a 35 bar [500 psi] safety reserve. This means that when the instrument shows the air time to be zero, there is still about 35 bar [500 psi] pressure left in your cylinder depending on your air consump- tion rate.

  • Page 60: Safety Stops And Deep Stops

    When the maximum allowed ascent rate is exceeded, the fi fth SLOW warning segment and the STOP sign appear and the depth reading starts to blink, indicating that the maximum as- cent rate has been exceeded continuously or that the current ascent rate is signifi...

  • Page 61: Decompression Dives

    6.1.6. DECOMPRESSION DIVES When your NO DEC TIME becomes zero, your dive becomes a decompression stop dive, i.e. you must perform one or se- veral decompression stops on your way to the surface. The NO DEC TIME on your display will be replaced by an ASC TI- ME and a CEILING notation will appear.
  • Page 62 plus the time needed at the ceiling. The ceiling is the shal- • lowest depth to which you should ascend plus the time needed at the Mandatory Safety Stop (if any) • plus Fig. 6.10. Decompressi- the time needed to reach the surface after the ceiling on dive without deepstops, •...
  • Page 63 CEILING, CEILING ZONE, FLOOR AND DECOMPRESSI- ON RANGE When in decompression, it is important that you understand the meaning of ceiling, fl oor, and decompression range (Fig. 6.14.): The ceiling is the shallowest depth to which you should ascend when in decompression. At this depth, Fig.
  • Page 64 Fig. 6.12. Decompression ceiling. Suunto recommends that decompression takes place dive, at ceiling zone. Two arrows point at each other deeper than 4 m [13 ft], even if the indicated ceiling is shallo- (“hour glass”).
  • Page 65 DISPLAY ABOVE THE FLOOR When you ascend above the fl oor, the ASC TIME display stops blinking and the upward pointing arrow disappears (Fig. 6.11.). Decompression will now begin, but is very slow. You should therefore continue your ascent. DISPLAY AT THE CEILING ZONE Fig.
  • Page 66 situation. You must immediately descend to or below the cei- ling. If you continue to violate the decompression, the dive compu- ter goes into a permanent Error Mode. In this mode the instru- ment can only be used as a depth gauge and timer. You must not dive again for at least 48 hours (see also section 6.7.

  • Page 67: Diving In Nitrox Mode [Diveean]

    6.2. DIVING IN NITROX MODE [DIVEEAN] 6.2.1. BEFORE DIVING IN NITROX MODE If set to the Nitrox mode (DIVEean), the correct oxygen per- centage of the gas in your cylinder must always be entered in- to the computer to ensure correct nitrogen and oxygen calcu- lations.
  • Page 68 To set the Nitrox mixes refer to chapter 5.2.3 Nitrox settings. DEFAULT NITROX SETTINGS In Nitrox mode the D9 allows the user to set 1-3 nitrox mixes containing 21-99% oxygen. In the Nitrox mode, the default setting for MIX1 is standard air Fig.

  • Page 69: Oxygen Displays

    6.2.2. OXYGEN DISPLAYS If set to Nitrox mode the D9 will additionally show on the alter- native display: the oxygen percentage, labeled with O • the set oxygen partial pressure limit, labeled with PO • the current oxygen toxicity exposure, labeled OLF •...

  • Page 70: Gas Change, Multiple Breathing Gas Mixes

    6.2.4. GAS CHANGE, MULTIPLE BREATHING GAS MIXES The D9 has as a special feature the possibility to set two addi- tional nitrox mixes to be used during the dive. This feature can be activated by setting the MIX2 and/or MIX3 “ON” and ente- ring other parameters in the same way as on the primary gas.

  • Page 71: Diving In Gauge Mode [Divegauge]

    (Fig. 6.20) Select mix by pressing SELECT. If no button is pressed in 15 seconds the D9 will go back to dive display without changing gas mix. Upon ascent the D9 prompts you to change gas when the Fig.

  • Page 72: Using The Compass In Dive Mode

    When the SELECT button is pressed during the dive: A special mark, bookmark is written in the profi le me- mory. The Dive Timer shown in the center window is stop- ped, reset and started again The previously timed interval (leg) is displayed Fig.

  • Page 73: At The Surface

    the current depth is displayed all diving related alterative display data is available the ascent rate bar-graph is displayed the tank pressure bar-graph is displayed (if wireless transmission enabled) In order to save battery power the compass display will auto- matically return to the DIVE mode after 60s has elapsed since Fig.

  • Page 74: Dive Numbering

    Er, if the decompression ceiling was violated (= Error Mode) (Table 6.1) Or in the alternative displays: maximum depth of last dive in meters [ft] dive time of last dive in minutes, shown as DIVE TIME the current time, shown as TIME the current temperature with °C for Centigrade [or °F for Fahrenheit] Cylinder pressure in bars [psi] (if enabled) If set to Nitrox mode, the following information will also be shown:...

  • Page 75: Repetitive Dive Planning

    Do Not Fly Symbol 6.5.3. REPETITIVE DIVE PLANNING The Suunto D9 includes a dive planner that allows you to review the no-decompressi- on limits on a subsequent dive taking the residual nitrogen loading of previous dives in consideration. The Dive Planning mode is explained in chapter 7.1.

  • Page 76: Flying After Diving

    6.5.4. FLYING AFTER DIVING The no-fl ying time is shown in the center window next to the airplane image. Flying or travelling to a higher altitude should be avoided at any time the computer counts down the no-fl ying time. The no-fl...

  • Page 77: Audible And Visual Alarms

    Following any dive that required a decompression stop, fl ying should be de- layed for at least 24 hours, and if possible, for 48 hours. Suunto recommends that fl ying is avoided until all the DAN and UHMS guide- lines and the dive computer wait to fl y conditions are satisfi ed.
  • Page 78 Continuous beeps and activated backlight when: the maximum allowed ascent rate, 10 m/min [33 ft/min], is exceeded. Ascent rate bar graph blinks and STOP warning appears (Fig. 6.6.). the decompression ceiling depth is exceeded. An error warning Er and a downward pointing arrow appear.

  • Page 79: Error Conditions

    OXYGEN ALARMS IN NITROX MODE Continuous beeps for 3 minutes activated backlight, when: the set oxygen partial pressure limit is exceeded. The alternative display is replaced with a current blinking PO value. You should immediately ascend above the PO depth limit (Fig. 6.17-6.18.). the OLF value reaches 80%.
  • Page 80 OMITTED DECOMPRESSION The Error Mode results from omitted decompression, i.e. when you stay above the ceiling for more than three minutes. During this three-minute period the Er warning is shown and the audible alarm beeps. After this, the dive computer will enter a perma- nent Error Mode.

  • Page 81: Memory Mode

    7. MEMORY MODE Fig. 7.1. Memory options. [MEM]. The memory options include a dive planner (MEMplan), dive logbook (MEMlog) and diving history (MEMhis) (fi g 7.1) The dive entry time and date is registered in the Logbook me- mory. Always check before diving that the time and date are correctly set, especially after traveling between different time zones.
  • Page 82 Altitude and Personal Adjustment Mode selections Fig. 7.3. Dive Planning Mo- de. For a 9m dive the avai- are shown in Table 10.1 and 10.2 in section 10.2. ”Suunto lable no-decompression ti- Reduced Gradient Bubble Model”. me is 67 minutes.

  • Page 83: Dive Logbook [Memlog]

    The surface interval must be at least 5 minutes for a dive to be considered a repetitive dive. Otherwise, it is considered a continuation of the same dive. The dive number will not chan- ge and the dive time will continue where it left off (see also section 6.5.2.
  • Page 84 The following information will be shown on three pages: Page I, main display (Fig. 7.4.) maximum depth (NOTE! Depending on the sampling • rate, the reading may differ from the maximum depth reading of the Dive History up to 0.3 m [1 ft].) date of dive •...

  • Page 85: Dive History [Memhis]

    999 diving hours. When these maximum values are reached, the counters will start again from zero. NOTE! The maximum depth can be reset to 0.0 m [0 ft] using the PC-Interface unit and the Suunto Dive Manager software.

  • Page 86: Additional Features

    8. ADDITIONAL FEATURES The instrument can be connected to an IBM compatible personal computer (PC), using the PC-Interface and software. With the PC-Interface unit, dive data from the dive computer can be downloaded to a PC. The PC software can be used for edu- cational and demonstration purposes, for planning dives, and for keeping a comple- te record of your dive history with the instrument.

  • Page 87: Suunto Dive Manager

    • Using the PC software, you are able to enter setup options such as: input a personal, 30 character fi eld into the D9 (i.e. your name) • reset the Dive History’s max depth to zero •...

  • Page 88: Suuntosports.com

    PC interface. SuuntoSports.com offers you a number of features that help you to get the most out of your sport and your Suunto D9. If you already own a personal Suunto sports instrument you can access all sport-spe- cifi...
  • Page 89 My Suunto The My Suunto section of the site is meant for your personal information. You can sto- re information about yourself, your wristop computer, your sporting and training activi-...
  • Page 90 You can also publish your logs and compare them with other users’ logs. The My Suunto section also contains a personal calendar that you can use to mark personal events and other useful information.
  • Page 91 When the opening page appears, click the Register icon and register yourself and your Suunto sports instrument. You can chan- ge and update your personal and equipment profi les in My Suunto section afterwards. After the registration you will automatically enter the SuuntoSports.com home page that introduces the site structure and functional principles.

  • Page 92: Care And Maintenance

    9. CARE AND MAINTENANCE This SUUNTO D9 dive computer is a sophisticated precision instrument. Though de- signed to withstand the rigors of scuba diving you must treat it with proper care and caution as any other precision instrument. 9.1. IMPORTANT INFORMATION...
  • Page 93 The service requires special tools and training. Therefore, it is advisab- le to contact an authorized SUUNTO dealer or distributor for biennial service. Do not attempt to do any service that you are not sure about how to do.

  • Page 94: Maintenance

    As a result of this buildup, moisture will be trapped next to the water contact and will not allow your Suunto D9 to operate properly. The water contact can be cleaned with a small brush (e.g. toothbrush).

  • Page 95: Battery Replacement

    In case of a leak, immediately take the dive computer to an authorized SUUNTO dea- ler or distributor. 9.5. BATTERY REPLACEMENT 9.5.1.

  • Page 96: Wireless Transmitter Battery Replacement

    9.5.2. WIRELESS TRANSMITTER BATTERY REPLACEMENT NOTE! It is advisable to contact an authorized Suunto dealer for transmitter battery replacement. It is imperative that the change is made in a proper manner to avoid any leakage of water into the transmitter.
  • Page 97 Check for any traces of fl ooding, or for any other damage. In case of a leak or any ot- her damage, bring the transmitter to an authorized SUUNTO dealer or distributor for check and repair. 6. Check the condition of the O-ring; a defective O-ring may indicate sealing or other problems.
  • Page 98 10. Carefully put the transmitter cover into place. Note that the cover will only fi t in one position. Match the three slots on the inside of the cover with the three ledges below the battery. 11. Screw the four screws back into place. Fig.

  • Page 99: Technical Data

    10. TECHNICAL DATA 10.1. TECHNICAL SPECIFICATION Dimensions and weight: Diameter: 50.0 mm [1.97 in]. Thickness: 17.6 mm [0.67 in]. Weight: 110g [3.88 oz]. Transmitter: Max. diameter: 40 mm [1.57 in]. Length: 80mm [3.15 in]. Weight: 118g [4.16 oz]. Rated working pressure: 300 bar [4000 psi], maximum allowed pressure 360 bar [5000 psi].
  • Page 100 Accuracy: ± 1% of full scale or better from 0 to 80 m [262 ft] at 20°C [68°F] (complying with EN 13319). Depth display range: 0 … 200 m [656 ft]. Resolution: 0.1 m from 0 to 100 m [1 ft from 0 to 328 ft]. Temperature display: Resolution: 1°C [1.5°F].
  • Page 101 It is recommended that the instrument be stored in a dry place at room temperature. NOTE! Do not leave the dive computer in direct sunlight! Tissue Calculation Model Suunto Deepstop RGBM algorithm (developed by SUUNTO and Bruce R. Wienke, BS, MS and PhD). 9 tissue compartments.
  • Page 102 Reduced gradient (variable) “M” values based on diving habit and dive viola- tions. The “M” values are tracked up to 100 hours after a dive. The EAN and oxygen exposure calculations are based on recommendations by R.W. Hamilton, PhD and currently accepted exposure time limit tables and principles.
  • Page 103 which cannot be tested in advance). The time the dive computer has been stored until it gets to the customer. The battery is installed into the unit at the factory. Transmitter: One 3V lithium battery: 1/2AA (K5546) and O-ring 2,00 mm x 25,00 mm (K5538).

  • Page 104: Suunto Reduced Gradient Bubble Model (Rgbm)

    It was deve- loped in a co-operation between Suunto and Bruce R. Wienke BSc, MSc. PhD. It is based on both laboratory experiments and diving data, including data from DAN.
  • Page 105 When this is detected in addition to adapting the decompression algorithm the Suunto RGBM model will in some circumstances also advise, with the Diver Attention Symbol (review chapter 5.2) that the diver extend the surface interval.
  • Page 106 TABLE 10.1. NO-DECOMPRESSION TIME LIMITS (MIN) FOR VARIOUS DEPTHS (M) FOR THE FIRST DIVE OF A SERIES Personal Mode / Altitude Mode Depth P0/A0 P0/A1 P0/A2 P1/A0 P1/A1 P1/A2 P2/A0 P2/A1 P2/A2...
  • Page 107 TABLE 10.2. NO-DECOMPRESSION TIME LIMITS (MIN) FOR VARIOUS DEPTHS [FT] FOR THE FIRST DIVE OF A SERIES Personal Mode / Altitude Mode Depth [ft] P0/A0 P0/A1 P0/A2 P1/A0 P1/A1 P1/A2 P2/A0 P2/A1 P2/A2...

  • Page 108: Oxygen Exposure

    ALTITUDE DIVING The atmospheric pressure is lower at high altitudes than at sea level. After traveling to a higher altitude, the diver will have additional nitrogen in his body, compared to the equilibrium situation at the original altitude. This “additional” nitrogen is released gra- dually in time and equilibrium is reached.
  • Page 109 for recreational scuba diving, the recommended upper limit of 1.4 bar PO used as a default the CNS% limits up to 1.6 bar are based on 1991 NOAA Diving Manual limits the OTU monitoring is based on the long-term daily tolerance level and the re- covery rate is reduced Oxygen related information displayed by the dive computer is also designed to ensu- re all warnings and displays in the appropriate phases of a dive.

  • Page 110: Warranty

    If a claim under this or any other warranty appears to be necessary, return the pro- duct, freight prepaid, to your Suunto dealer or distributor or qualifi ed repair facility. In- clude your name and address, proof of purchase and/or service registration card, as required in your country.
  • Page 111 fi tness for a particular purpose, are limited from date of purchase and in sco- pe to the warranties expressed herein. Suunto shall not be liable for loss of use of the product or other incidental or consequential costs, expenses or damage incurred by the purchase.

  • Page 112: Glossary

    12. GLOSSARY Air Time The amount of dive time remaining, based on a calculation of cylinder pressure and ambient pressure and present air consumption. Altitude dive A dive made at an elevation greater than 300 m [1000 ft] above sea level. Ascent rate The speed at which the diver ascends toward the surface.
  • Page 113 Central Nervous System Toxicity Toxicity caused by oxygen. Can cause a variety of neurological symptoms. The most important of which is an epileptic-like convulsion which can cause a diver to drown. CNS% Central Nervous System toxicity limit fraction. Also note Oxygen Limit Fraction Compartment See “Tissue group”.
  • Page 114 Dive series A group of repetitive dives between which the dive computer indicates some nitrogen loading is present. When nitrogen loading reaches zero the dive computer deactivates. Dive time Elapsed time between leaving the surface to descend, and returning to the surface at the end of a dive. Delta P, describing the Cylinder Pressure drop during the ∆P dive;...
  • Page 115 OEA = EAN = EANx Abbreviation for Oxygen Enriched Air Nitrox. Abbreviation for Oxygen Limit Fraction. Abbreviation for Oxygen Tolerance Unit. Oxygen Tolerance Unit Is used to measure the Whole-Body-Toxicity. Oxygen Limit Fraction A term used by SUUNTO for the values displayed in the...
  • Page 116 Oxygen Toxicity bargraph. The value is either the CNS% or the OTU%. Oxygen percentage or oxygen fraction in the breathing gas. Standard air has 21% oxygen. Oxygen partial pressure Limits the maximum depth to which the used Nitrox mixture can safely be used. The maximum partial pressure limit for enriched air diving is 1.4 bar.
  • Page 117 Tissue group Theoretical concept used to model bodily tissues for the construction of decompression tables or calculations. Whole-Body Toxicity Another form of oxygen toxicity, which is caused by prolonged exposure to high oxygen partial pressures. The most common symptoms are irritation in the lungs, a burning sensation in the chest, coughing and reduction of the vital capacity.
  • Page 118 Printed in Finland 09.2004 / Esa Print Oy / 140689...
  • Page 119 COMPASS SETTINGS Declination Calibrate TIME DIVE COMPASS LIGHT COMPASS LIGHT LIGHT SETTINGS SETTINGS SUB-MODES SUB-MODES Alarm Depth Alarm Time Dive Time Alarm Plan Date Nitrox Gauge Units Personal/Altitude Backlight Sample rate Tones Deepstops RGBM Tank Pressure Units HP Code MODES AND SETTINGS...
