Toto TCF802 Series Instruction Manual

Toto TCF802 Series Instruction Manual

Washlet

Advertisement

Quick Links

TOTO ASIA OCEANIA
10, Eunos Road 8, #12-07, Singapore Post Centre. Singapore 408600.
PTE. LTD.
Phone : +65-6744-6955 Fax : +65-6841-0819 http://asia.toto.com/
TOTO ASIA OCEANIA
Middle East Branch LOB19-1701-1702, Jebel Ali Free Zone, P.O. box 261804, Dubai U.A.E.
PTE. LTD.
Phone : +971-4-886-5983 Fax : +971-4-886-5986 http://asia.toto.com/
TOTO ASIA OCEANIA
Manila Representative Office. Unit 1010, 10th Floor Rufino Building, Ayala Avenue cor.V.A.
PTE. LTD.
Rufina Street, Makati City,1226 Philippines.
Phone : +63-2-887-6643 Fax : +63-2-887-4084 http://asia.toto.com/
Yangon Branch
#303, Prime Hill Business Square, No.60, Shwe Dagon Pagoda Road,
Dagon Township, Yangon, Myanmar
Phone : +95-1-382710, +95-1-382720 Fax : +95-1-382638
TOTO (THAILAND) LTD.
77 Moo 5 HSIL Industrial Zone T.Nong -Plamor A.Nong-Khae Saraburi 18140 Thailand
Spare Part and
Phone : +66-92-246-5880, +66-92-246-6612, +66-36-382-760
After Service Center
Fax
: +66-2-650-9923 http://th.toto.com/en/index.php
TOTO INDIA INDUSTRIES
101, Kamla Executive Park, Opp. Vazir Glass Works,
PVT. LTD
Off. Andheri Kurla Road, Andheri (East), Mumbai 400 059, India.
Phone : +91-22-4022-3717 / 3718 Fax : +91-22-4022-3719 http://asia.toto.com/
TOTO VIETNAM
R. 810, Daeha Business Centre, 360 Kim Ma St., Ba Dình Dist., Ha Noi City
Co., Ltd.
Phone : +84-4-37714354 Fax : +84-4-37714355 http://toto.com.vn/
You are advised to record the following information to allow quick service.
Date of purchase :
Name of shop :
Date : year month day
Tel : (
)
WASHLET
TCF802***
TCF801***
TCF804***
TCF803***
Thank you for your recent purchase of this product.
Please read the enclosed information to ensure the safe use of your product.
Be sure to read this Instruction Manual before using your product and keep it in a safe place
for future reference.
2020.6.10
D07774
Instruction Manual

Advertisement

Table of Contents
loading

Summary of Contents for Toto TCF802 Series

  • Page 1 101, Kamla Executive Park, Opp. Vazir Glass Works, PVT. LTD Off. Andheri Kurla Road, Andheri (East), Mumbai 400 059, India. Phone : +91-22-4022-3717 / 3718 Fax : +91-22-4022-3719 http://asia.toto.com/ TOTO VIETNAM R. 810, Daeha Business Centre, 360 Kim Ma St., Ba Dình Dist., Ha Noi City TCF802*** Co., Ltd.
  • Page 2: Table Of Contents

    The available functions vary according to the part no. Keep It Table of Contents Product name, Check your model's Part No. Safety Precautions ....4 part no. and write a Operational Precautions ..9 check mark in this Clean Parts Names ......10 Preparation ......
  • Page 3: Safety Precautions

    Safety Precautions These precautions are important for safe usage. Be sure to follow them and use the product correctly. WARNING Symbols and Meanings Do not use the product if a malfunction occurs. WARNING May result in death or serious injury. OFF.
  • Page 4 Safety Precautions (Continued) WARNING CAUTION This is an electrical product. Do not install it anywhere water is likely to get on Do not use the product if the main unit is unstable. the product or anywhere with humidity high enough that water is likely to form Doing so may cause the main unit to come loose and fall, resulting in injury.
  • Page 5: Operational Precautions

    Safety Precautions Operational Precautions (Continued) For prevention of malfunctions For prevention of damage CAUTION Do not block the body sensor or the remote control Wipe plastic areas transmitter or receiver. such as the main unit and remote control < About the body sensors > If a water leak should occur, always close the shutoff valve.
  • Page 6: Parts Names

    Parts Names Main display Left side of the main unit Right rear of the main unit Power LED Seat LED Power switch Remote control (Page 13) Energy saver LED receiver Soft light CLEAN indicator Deodorizer outlet Cover (Page 35) Toilet lid cushions Product name, part no., etc.
  • Page 7: Preparation

    Preparation Using the Product for the First Time 1. Insert the battery If the remote control is secured 2. Turn on the power 3. Open the shutoff valve (for anti theft) Remove the remote control from Fully open the shutoff valve. Switch the breaker on the distribution board to ON.
  • Page 8: Basic Operations

    Basic Operations ● The "Water pressure adjustment","Wand position adjustment" and "Personal setting" functions are Operate the controls on the remote control; a beep sounds when the main unit receives the signal. swipe operated. ● Functions that operate when a button is pressed Flushing during "Rear cleansing", "Rear soft cleansing"...
  • Page 9 ▶ Basic Operations You can set as desired About the Menu Screen If you want to return to the previous item, press the button. See the corresponding pages for the detailed descriptions. Level 1 Level 2 Level 3 Remote control back side MANUAL CLEANING 1.WAND CLEAN...
  • Page 10: Automatic Functions (Cleaning Features)

    Lights to show that the "CLEAN" functions are operating. Automatic Functions Cleaning Features Lights to show that auto bowl CLEAN Lights to show that the "clean" As you As you As you and auto wand CLEAN are operating. functions are operating. "ewater+"...
  • Page 11: Automatic Functions (Convenience Features)

    Automatic Functions Convenience Features As you As you As you As you Various automatic functions are available. approach stand up move away • Operation under the initial settings is described below. settings When using the toilet seat The toilet cases. (After 60 seconds have passed, (After about ON/OFF...
  • Page 12: Temperature Adjustment (Warm Water, Toilet Seat, Drying)

    Temperature Adjustment Warm Water, Toilet Seat, Drying Five different temperature levels from high to low and "OFF" can be set. Remove Mount the Press. <Settings Select the Select the item you want to set. the remote remote control complete> temperature level. control from in the hanger.
  • Page 13: Energy Saver Features

    Energy Saver Features Type Main display "Auto energy saver", "Auto energy saver+" or "Timer energy saver" can be selected. To save energy, the temperature of the toilet seat becomes low (or "OFF"). "Auto energy saver" takes about 10 days to detect time periods in which the toilet seat is never or infrequently used.
  • Page 14 Energy Saver Features How to Set Set the "Timer energy saver" at the time you want to start it. ENERGY Press. Select SAVER Press 1.AUTO ENERGY [AUTO ENERGY SAVER]. SAVER Auto energy 2.TIMER SAVER Select [ENERGY SAVER]. saver AUTO ENERGY SAVER Select AUTO ENERGY...
  • Page 15: Main Unit

    Maintenance Main Unit Main Unit WARNING (Approximately daily) (Failure to do so may cause electric shock or malfunction, resulting in a breakdown.) Soft cloth soaked in water • Toilet paper • Dry cloth • Nylon scrubbing brush (May cause damage.) before maintenance.
  • Page 16: Wand

    Maintenance Wand Deodorizing Filter Wand Deodorizing Filter (Approximately once a month) (Approximately once a month) <If you notice dirt (Wand cleaning)> switch to "OFF". (Page 28) Hold the knob and pull outward. Do not pull with undue force. (May cause damage or malfunction.) Soft cloth Toilet paper, etc.
  • Page 17 Maintenance Gap between the Main Unit and Bowl Unit Gap between the Main Unit and Bowl Unit Gap between the Main Unit and Bowl Unit (Approximately once a month) (Approximately once a month) (Continued) You can remove the main unit to clean Mount the main unit.
  • Page 18 Maintenance Gap between the Main Unit and the Toilet Lid Water Filter Drain Valve Water Filter Drain Valve Gap between the Main Unit and the Toilet Lid (Approximately once a month) (Approximately once every 6 months) <If you think the water pressure has weakened> The toilet lid can be removed for thorough cleaning.
  • Page 19 Changing Settings Setting List Applicable How to Set Available Settings Setting Types Models Ref. Page Bold: Initial settings Set whether or not to clean the bowl unit / OFF automatically TCF802*** 5seconds / Page 38 TCF804*** Change the amount of time before the 10seconds MENU 15seconds...
  • Page 20 Changing Settings AUTO FLUSH Select Press Press. 1.AUTO FLUSH [AUTO FLUSH]. 2.AUTO FLUSH Set whether or not to DELAY MENU clean the bowl unit Select automatically 1.MANUAL CLEANING Auto AUTO [AUTO FUNCTION]. FLUSH Select 2.ENERGY Press SAVER AUTO Press 3.AUTO FLUSH OFF FUNCTION [ON] or [OFF].
  • Page 21 Changing Settings AUTO OPEN /CLOSE Select Press Press. 1.AUTO OPEN /CLOSE [AUTO OPEN/CLOSE]. 2.AUTO CLOSE Set whether or not to DELAY TIME MENU open and close the toilet Select lid automatically 1.MANUAL CLEANING AUTO OPEN [AUTO FUNCTION]. /CLOSE 2.ENERGY Select Press SAVER close...
  • Page 22 Changing Settings AUTO OPEN /CLOSE Select Press. 1.AUTO OPEN /CLOSE [AUTO OPEN DELAY]. 2.AUTO CLOSE Press DELAY Change the time period MENU Select 3.AUTO OPEN till automatic opening DELAY 1.MANUAL (After closing by hand.) CLEANING Auto open [AUTO FUNCTION]. AUTO OPEN 2.ENERGY Press DELAY...
  • Page 23 Changing Settings Cleaning Features AUTO CLEANING Select Press Press. 1.AUTO WAND CLEAN [AUTO WAND CLEAN]. Set whether or not MENU to clean the wand Select automatically 1.MANUAL CLEANING Auto wand AUTO WAND [AUTO FUNCTION]. CLEAN Select 2.ENERGY Press SAVER CLEAN AUTO WAND 3.AUTO CLEAN OFF...
  • Page 24 Changing Settings Cleaning Features (Continued) AUTO CLEANING Select Press. 1.AUTO WAND CLEAN [DEODORIZER]. 2.AUTO BOWL Press Set whether or not to CLEAN MENU Select deodorize automatically 3.DEODORIZER after sitting on the toilet 1.MANUAL CLEANING seat [AUTO FUNCTION]. DEODORIZER 2.ENERGY Press Select Deodorizer SAVER...
  • Page 25: Bowl Unit

    Changing Settings Light LIGHT Select Press Press. 1.SOFT LIGHT [SOFT LIGHT]. MENU Set whether or not to Select use the soft light 1.MANUAL CLEANING Soft light SOFT LIGHT [AUTO FUNCTION]. Select 2.ENERGY Press SAVER SOFT LIGHT Press 3.AUTO FUNCTION [ON] or [OFF]. AUTO (To return FUNCTION...
  • Page 26 Changing Settings Language settings Select 语言 / 語言 / Select the language LANGUAGE Press. displayed on the back of remote control [ 中文简体 ], [ 繁體中文 ] or LANGUAGE 中文简体 ENGLISH Language [ENGLISH]. Press MENU 繁體中文 Select settings ENGLISH 2.ENERGY SAVER (To return [ 语言...
  • Page 27 Changing Settings Other settings OTHER SETTING Select Press Press. 1.BEEP [BEEP]. Set whether or not to MENU Select make a beep sound BEEP Beep sound Select 3.AUTO FUNCTION BEEP OFF [OTHER SETTING]. Press 4.语言 / 語言 / Press LANGUAGE [ON] or [OFF]. 5.OTHER SETTING (To return...
  • Page 28 Changing Settings Other settings (Continued) OTHER SETTING Select Press. 1.BEEP [PERSONAL SETTING]. 2.SETTING Press LOCK MENU Select Set whether or not to 3.PERSONAL SETTING use the personal setting 3.AUTO FUNCTION Personal [OTHER SETTING]. PERSONAL 4.语言 / 語言 / Select SETTING Press Press LANGUAGE...
  • Page 29: What To Do

    What to Do? Freeze Damage Prevention When the ambient temperature is likely to drop to 0 °C or lower, take measures to prevent freezing. If you cannot operate with the remote control Attention! • When the ambient temperature is likely to drop to 0 °C or lower, do not use the energy saver feature. (May damage the product.) •...
  • Page 30: Long Periods Of Disuse

    What to Do? Long Periods of Disuse If the toilet is in a location you will not visit for a long time, drain the water. Resupplying the Water (The water in the tank may cause malfunctions or become contaminated and cause skin irritation or other problems.) Open the shutoff valve.
  • Page 31: Removal Of Operation Guide

    Removal of Operation Guide Follow the procedure below. First, try the actions described on pages 61 - 67. If the problem persists, consult the installer, seller, or TOTO customer service (see contact information on the back cover). How to remove the operation guide CAUTION If a water leak occurs, close the shutoff valve.
  • Page 32 Flip the power switch to OFF and wait about 10 seconds before flipping it on again. Flushing If the same symptom reappears. There may be a malfunction. Consult with TOTO customer service (see contact information on the back cover). Ref. Trouble Please check...
  • Page 33 Troubleshooting Toilet Seat and Toilet Lid Ref. Ref. Trouble Please check Trouble Please check Page Page Is "Auto open/close" set to "OFF"? Is the toilet seat temperature set to "OFF" or a low level? Set to "ON". Even when set to "ON", "Auto open/close" is not performed for about 15 Is energy saver in operation? seconds after the toilet seat or toilet lid is closed.
  • Page 34 Even after sitting down, you do not hear operation sounds. connections seems to be not TOTO customer service (see contact information on the back cover). Sit back on the toilet seat. If you hear an operation sound from the deodorizer, but odors are not...
  • Page 35: Safety Guidelines

    W 391 mm x D 579 mm x H 108 mm About 7 kg Weight About 7 kg (For Australia, about 6 kg) *1 Temperature around the warm air outlet measured by TOTO. When disposing of this product, please follow your local or state guidelines for proper disposal. 01.米国向け(英)...
  • Page 36: Limited Warranty

    4. This warranty gives you specific legal rights. You may have other rights which vary from country to country. 5. T o obtain warranty repair service under this warranty, you must take the product or deliver it prepaid to a TOTO service facility, together with a letter stating the problem, or contact a TOTO distributor or product service contractor, or directly to TOTO sales office.
