GOSH- to –Home Long Term Ventilation Service
HOW TO SAFETLY CARE FOR A CHILD NEEDING NIV: A basic guide
Ensure you know why the patient needs Non Invasive Ventilatory support.
CPAP is Continuous Positive Airway Pressure. It provides a positive pressure of air through the nose
and mouth, stenting open the upper-airway, preventing the bronchioles and alveoli from collapsing
and maintaining adequate gaseous exchange. Measured in centimetres of water (cmH2O).
BIPAP is BI-level Positive Airway Pressure and this provides two pressures; an IPAP (Inspiratory positive
airway pressure) and an EPAP (Expiratory positive airway pressure). It assists inspiration to achieve an
optimal tidal volume, while preventing airway closure during expiration.
Three main Long Term NIV ventilators in the Trust
Stellar 100/150
CPAP/BIPAP
How to connect to main power supply
Ensure the plug is securely in the socket at the back of the ventilator and the plug at the wall is
switched on.
If mains power is not connected
The Stellar 100 has a 2-4 hr internal battery depending on pressure needed and if humidification is
required. The vent will automatically switch to battery mode and alarm to inform you. Amount of
battery charge is shown on the top right of vent screen.
The Nippy has a 2-4 hour battery depending on pressure. The amount of battery charge is shown on
the top right of vent screen.
The Airsense 10 does not have a battery therefore cannot be used unless plugged into the mains. If a
child is more dependent on their ventilation they should be on either the Nippy or the Stellar
To note -the older the ventilator the less likely the ventilator will have a fully functional battery.
Always keep the ventilator plugged in and carry out a battery test if needed to be used.
Garry Rendle & Victoria Robinson NIV CNS 27/03/2020
INTRODUCTION TO THE VENTILATOR
Nippy
CPAP/BIPAP
Airsense 10
CPAP
Advertisement
Related Manuals for ResMed Stellar 100
Summary of Contents for ResMed Stellar 100
- Page 1 If mains power is not connected The Stellar 100 has a 2-4 hr internal battery depending on pressure needed and if humidification is required. The vent will automatically switch to battery mode and alarm to inform you. Amount of battery charge is shown on the top right of vent screen.
- Page 2 C. Bacterial filter may be required on a loan device D. Long term NIV mask with Carbon dioxide exhalation port Ventilator- with/without a humidifier The Airsense 10-withoiut humidity The NIPPY- without humidity The Stellar 100- with humidity Garry Rendle & Victoria Robinson NIV CNS 27/03/2020...
- Page 3 GOSH- to –Home Long Term Ventilation Service How to deliver pressure The Stellar 100 If the screen is not in standby mode, flick the black switch on the back of the ventilator near the plug. Once the clock appears on the screen to turn on/off see below:...
- Page 4 The NIPPY- does not have a Ramp feature The Stellar 100- Ramp can be turned off by scrolling the dial over the ramp bar on the front screen (while there is no treatment pressure ), pressing the dial until the bar becomes yellow and scrolling back to 0, press the dial again until the ramp bar goes blue to lock.
-
Page 5: Oxygen Supply
The Airsense 10- as per NIPPY advice The Stellar 100- the oxygen should go via the back of the machine using the white oxygen port. If this is not available then use a green oxygen enrichment port and attach between the vent and the tubing as per NIPPY advice. - Page 6 Can change the filter Dust particle filters at the back of the ventilator on the Stellar 100, the Nippy and on the side of an Airsense They should be changed 3 monthly on manufacturer advice, check monthly, if very dirty discard and replace, do not wash and re-use Avoid keeping the ventilator on the floor.
- Page 7 GOSH- to –Home Long Term Ventilation Service MASK FIT Where possible fit mask first then start ventilation once good placement of mask has been achieved Fit the mask correctly To fit the mask well, ensure the nostrils are not occluded and the mask is not in the eyes. Nasal mask: place the mask at the tip of top lip and roll up to the nasal bridge Fullface mask: start with base at the crease of the chin and roll up to sit below the eye.
- Page 8 The NIPPY An external humidifier is needed With the Stellar 100 and Airsense 10 Never fill chamber when machine is on (it’s a messy experience!), Ensure the lid is closed properly, this is a major cause for leak. Aim to have the humidifier below the patient to avoid rainout traveling towards the airway.
- Page 9 Learn the circuit if adding a humidifier to Stellar 100 Attach humidifier to vent, mask and tubing, press the ticks button 3 times and use dial to press learn...
-
Page 10: Cleaning And Maintenance
Servicing requirements PAT testing needs to be done yearly but a full servicing on the Stellar 100 and Airsense 10 needs to be done every 5 years. To be aware that the battery on the Stellar 100 may deplete after 2 year... - Page 11 GOSH- to –Home Long Term Ventilation Service NEBULISERS Reasons for giving nebulisers Mucolytics and saline for clearing secretions or antibiotic use for bacterial colonisation We would not use nebulisers via an NIV circuit unless the patient was 24/7 dependant Nebulisers are not as efficient via a NIV circuit as via a face mask and should be avoided if possible, they exhalation port on the mask can become blocked with saline and cause the non-vented mask alarm to sound.
- Page 12 This should be done under the guidance of a medic as ventilation pressure is a medical prescription The Stellar 100 Re Lock by holding down the scroll dial and the 2 ticks button. Garry Rendle & Victoria Robinson NIV CNS 27/03/2020...
- Page 13 GOSH- to –Home Long Term Ventilation Service The NIPPY While the ventilator is on. Hold the 2 buttons down together for 5 secs. The machine will alarm and the padlock will be unlocked. Highlight the clinical settings that needs to be changed and use the same initial 2 buttons to increase or decrease as requested.
