Wireless N 150 Ultra Mini USB Adapter
Section 1
Install the Wireless USB Adapter
This Quick Installation Guide only provides the basic installation instructions.
For detailed instructions of other advanced features, please refer to the User's
Manual that can be found on the provided CD.
For Macintosh users, you can find the software and installation instructions for
MAC 10.4, 10.5, 10.6 is under the MAC directory on the provided CD.
Step 1.1
Insert the USB adapter into an available USB port of your computer.
Step 1.2
Click Cancel when you see the Found New Hardware Wizard.
Quick Installation Guide
Model # AWLL5099
Package Contents:
• Wireless N 150 USB
Adapter
• Driver & Utility CD
• Quick Installation Guide
Ver. 1.0
Advertisement
Related Manuals for Airlink101 AWLL5099
Summary of Contents for Airlink101 AWLL5099
-
Page 1: Quick Installation Guide
Step 1.1 Insert the USB adapter into an available USB port of your computer. Step 1.2 Click Cancel when you see the Found New Hardware Wizard. Model # AWLL5099 Package Contents: • Wireless N 150 USB Adapter • Driver & Utility CD •... - Page 2 Windows XP/2000 Users: Windows 7/Vista Users:...
- Page 3 Step 1.3 Insert the Installation CD in the CD ROM drive. The Autorun screen will pop up. Select Install Utility and Driver from the menu. Note: If the Autorun screen doesn’t appear automatically, go to Start, Run, and type D:\Utility\Setup.exe (where D is the letter of your CD ROM drive) and click OK.
- Page 4 Step 1.5 Click Next to begin the installation. Please wait for Windows to finish installing the Airlink101 Wireless Monitor and driver for Airlink101 Wireless Adapter, and the utility. Step 1.6 Select Yes, I will restart my computer now. Click Finish to complete the installation.
-
Page 5: Connect To Wireless Network
Section 2 Connect to Wireless Network Step 2.1 Click on the wireless icon in the system tray at the bottom right-hand corner of your screen. Airlink101 Wireless Monitor screen will popup. Click on Available Network tab, a list of available network will be shown. - Page 6 Step 2.2 Then, select the one you want to connect to and click Connect. Step 2.3 Enter the network security key if the wireless network you are attempting to connect has wireless encryption enabled. Click OK. The connection should be now established.
- Page 7 Step 2.4 The Easy Setup Button(WPS compatible button) is a new and easy way to configure the encryption for your wireless network clients, it is Wi-Fi compatible. In order to use it, you need to have a router that supports this feature.
- Page 8 3. The router will now start the handshake with the wireless Adapter. The connection will be established in 2 minutes. Notice that there are cases that the WPS button on the router to be pushed first before pushing the one on the adapter.
- Page 9 Step 2.6 Enter the wireless security key into the Network Key box if the network you are attempting to connect has wireless security enabled. Click OK. The Adapter will automatically detect the type of Network Authentication and the Data encryption. All you need to do is to enter the Network Key in the appropriate boxes according to the settings of the wireless router and then click OK to connect.
- Page 10 Congratulations! You have now connected to the wireless network successfully.
-
Page 11: Troubleshooting
Troubleshooting 1. If you cannot open the wireless monitor utility, make sure that the USB adapter is inserted firmly into the USB port. 2. If you cannot connect to the wireless router, you may want to double check the wireless security settings on the router. The network key you entered in Step 2.4 must match with the settings on the wireless router.
