Quick Installation Guide
Wireless N 150 USB Adapter with 10dBi Antenna
Model # AWLL5055
Section 1
Install the Wireless USB Adapter
This Quick Installation Guide only provides the basic installation instructions.
For detailed instructions of other advanced features, please refer to the User's
Manual that can be found on the provided CD.
For Macintosh users, you can find the software and installation instructions for
MAC 10.4/10.5/10.6 under the MAC folder on the provided CD.
Step 1.1
Insert the USB adapter into an available USB port of your computer.
Step 1.2
Click Cancel when you see the Found New Hardware Wizard.
Ver. 1.0
Package Contents:
• Wireless N 150 USB Adapter
with 10dBi Antenna
• Driver & Utility CD
• Quick Installation Guide
Windows XP/2000
Users:
Windows 7/Vista
Users:
Step 1.3
Insert the Installation CD in the CD drive. The autorun screen will pop
up. Select Install Utility and Driver from the menu.
Advertisement
Related Manuals for Airlink101 AWLL5055
Summary of Contents for Airlink101 AWLL5055
-
Page 1: Quick Installation Guide
Quick Installation Guide Wireless N 150 USB Adapter with 10dBi Antenna Model # AWLL5055 Package Contents: • Wireless N 150 USB Adapter • Driver & Utility CD • Quick Installation Guide Section 1 Install the Wireless USB Adapter This Quick Installation Guide only provides the basic installation instructions. - Page 2 Windows XP/2000 Users: If the Autorun screen doesn’t appear automatically, go to Start, Run, and type D:\Utility\Setup.exe (where D is the letter of your CD drive) and click OK. Windows 7/Vista Users: When you get warning message(s), make sure that you give permission to continue with the installation of the driver software.
- Page 3 Windows 7/Vista Users: click on Install this driver software anyway. Please wait when Windows is installing the driver for Airlink101 Wireless Adapter and the utility, Airlink101 Wireless Monitor. Step 1.7 Click Finish to complete the installation Step 1.8 Select Yes, I will restart my computer now. Click Finish to complete the installation.
-
Page 4: Connect To Wireless Network
Section 2 Connect to Wireless Network For Windows 7 Users: You will need to use the utility built in Windows 7 to manage this wireless USB adapter. Currently, Airlink101 Wireless Monitor does not support Windows 7. Step 2.1 Click on the wireless icon in the system tray at the bottom right-hand corner of your screen. - Page 5 Step 2.2 Click the Available Network tab of the Wireless Monitor, select the wireless network that you wish to connect to, and click Add to Profile. If the network that you are attempting to connect does not have encryption enabled, you will receive a warning about connecting to an unsecured network. Click OK to complete the connection.
-
Page 6: Troubleshooting
Troubleshooting 1. If you cannot open the wireless monitor utility, make sure that the USB adapter is inserted firmly into the USB port. 2. If you cannot connect to the wireless router, you may want to double check the wireless security settings on the router. The network key you entered in Step 2.3 must match with the settings on the wireless router.
