Wireless N 150 Ultra Mini USB Adapter
Section 1
Install the Wireless USB Adapter
This Quick Installation Guide only provides the basic installation
instructions. For detailed installation instructions on advanced features,
please refer to the User's Manual on the provided CD.
Step 1.1
Insert the USB adapter into an available USB port of your
computer.
Step 1.2
Click Cancel if you see the Found New Hardware Wizard.
Quick Installation Guide
Model # AWLL5088
Package Contents:
• Wireless N Ultra Mini
USB Adapter
• Driver & Utility CD
• Quick Installation Guide
Ver. 1.0
Advertisement
Related Manuals for Airlink101 AWLL5088
Summary of Contents for Airlink101 AWLL5088
-
Page 1: Quick Installation Guide
Insert the USB adapter into an available USB port of your computer. Step 1.2 Click Cancel if you see the Found New Hardware Wizard. Quick Installation Guide Model # AWLL5088 Package Contents: • Wireless N Ultra Mini USB Adapter • Driver & Utility CD •... - Page 2 Windows Vista Users: Windows XP Users: Step 1.3 Insert the Installation CD in the CD drive.
- Page 3 Step 1.4 The Autorun screen will pop up. Select Install Utility and Driver from the menu. Windows 7 / Vista Users: When you get warning message(s), make sure that you give permission to continue with the installation of software. Step 1.5 Select the language and click Next.
- Page 4 Step 1.6 Click Next and follow the instructions on the window to finish installation. Step 1.7 Give Permission to Window to install the driver software. Windows 7 / Vista Users: Click the Install this driver software anyway.
- Page 5 Windows XP Users: Click Continue Anyway at the Windows Logo Screen.
- Page 6 You will see the following message when it is installing the driver for Airlink101 Wireless Adapter and the Airlink101 Wireless Monitor. Step 1.8 Select Yes, I will restart my computer now. Click Finish to complete the installation. Congratulations! You have installed the driver and utility successfully.
-
Page 7: Connect To The Wireless Network
Section 2 Connect to the Wireless Network Step 2.1 After rebooting the computer, open Airlink101 Wireless Monitor utility by double clicking on the Airlink101 Wireless Monitor Utility icon on your desktop. Step 2.2 Click the Available Network tab of the Wireless Monitor, select the SSID (Network Name) of the wireless network that you wish to connect to, and click Add to Profile. - Page 8 Step 2.3 Enter the wireless security key into the Network Key box if the network you are attempting to connect has wireless security enabled. Click...
- Page 9 Step 2.4 The connection should be now established. Verify that IP Address, Subnet Mask and Gateway have valid numbers assigned to them (instead of all 0’s). The Status should be Associated, and there will be green bars next to Signal Strength and Link Quality.
-
Page 10: Troubleshooting
Troubleshooting If you are experiencing problems with the connection (unable to connect, low signal strength, slow connection speed, not working, unstable wireless connection) you may want to tune your router’s signal by changing the channels on the router and/or by adjusting the direction of the antenna(s). You do not need to change the channel on the Adapter;...
