4.2.7 Recommended Wire Gauge
• Input connection to the VIN and PGND terminal blocks (T1, T2, and T3) – The recommended wire size is
AWG #12, with the total length of wire less than two feet (1-foot input, 1-foot return).
• Output load connection to the VOUT_A, VOUT_B, and PGND terminal blocks (T5, T6, T7, and T8) – The
minimum recommended wire size is AWG #10, with the total length of wire less than two feet (1-foot output,
1-foot return). A thicker wire gauge can be required to minimize the voltage drop in the wires.

4.3 List of Test Points, Jumpers, and Connectors

Table 4-1 lists the test point functions.
Test Point Name
TP1 PVIN
TP2, TP3,
TP4, TP10,
PGND
TP16,
TP22, TP27
TP5 Remote Sense Vout A (+) VOUT_A remote sense + voltage point
TP6 VOUT_A
TP7 CHA_VoutA
TP8 CHB_VoutA
TP9 Remote Sense Vout A (–) VOUT_A remote sense - voltage point
TP11 PGood_A
TP12 VSHARE_A
TP13 VSHARE_B
TP14 PGood_B
TP15 SYNC
TP17 Remote Sense Vout B (+) VOUT_B remote sense + voltage point
TP18 VOUT_B
TP19 CHA_VoutB
TP20 CHB_VoutB
TP21 Remote Sense Vout B (–) VOUT_B remote sense - voltage point
TP23 CNTL
TP24 CLK
TP25 SMBALRT
TP26 DATA
Table 4-2 lists the EVM jumpers.
Jumper Name
JP1 AVIN_A
JP2 AVIN_B
JP3 EN_A
JP4 EN_B
JP5 VDD5_A
JP6 VDD5_B
JP7 USB to PVIN
JP8 PMBus to AVIN
Table 4-3 lists the options for the EN/UVLO pin selections on JP2 and JP4.
SLUUCK6 – DECEMBER 2021
Submit Document Feedback

Table 4-1. Test Point Functions

Description
PVIN test point
PGND test point
VOUT_A sensing test point
Channel A for VOUT_A small signal loop gain measurements (B/A setup)
Channel B for VOUT_A small signal loop gain measurements (B/A setup)
PGOOD signal of VOUT_A
VSHARE_A measurement point. Sensitive signal
VSHARE_B measurement point. Sensitive signal
PGOOD signal of VOUT_B
External clock input (SYNC IN) or output to synchronize other devices (SYNC OUT)
VOUT_B sensing test point
Channel A for VOUT_A small signal loop gain measurements (B/A setup)
Channel B for VOUT_A small signal loop gain measurements (B/A setup)
CNTL signal on J2 header
CLK signal on J2 header
SMBALERT signal on J2 header
DATA signal on J2 header

Table 4-2. Jumpers

Description
AVIN_A input source selection
AVIN_B input source selection
EN_A pin selections
EN_B pin selections
External VDD5_A connection
External VDD5_B connection
Short to connect PVIN to micro USB connector
Short to connect USB-to-GPIO 3.3V to AVIN
