9 Bill of Materials

Table 9-1 lists the BOM for the TPSM8D6C24EVM-2V0.
Designator Quantity Value Description
!PCB1 1 Printed Circuit Board
C1, C7, C8, 4 100 μF CAP, AL, 100 μF, 35 V,
C9 ±20%, 0.15 Ω, SMD
C2, C3, C4, 8 22 μF CAP, CERM, 22 μF, 25 V,
C5, C10, C11, ±10%, X6S, 1210
C12, C13
C6, C14 2 6800 pF CAP, CERM, 6800 pF, 50
V, ±10%, X7R, 0402
C15, C16, 26 47 μF CAP, CERM, 47 μF, 10 V,
C20, C21, ±10%, X7R, 1210
C26, C27,
C28, C29,
C30, C34,
C35, C37,
C38, C48,
C49, C50,
C51, C52,
C56, C57,
C59, C60,
C64, C65,
C69, C70
C23, C42 2 100 pF CAP, CERM, 100 pF, 50 V,
±10%, X7R, 0402
C24, C25, 4 10 μF CAP, CERM, 10 μF, 10 V,
C46, C47 ±20%, X7R, 0603
C39, C40, 4 470 μF CAP, Tantalum Polymer,
C61, C62 470 μF, 6.3 V, ±20%, 0.01
Ω, 7343-40 SMD
C41, C43 2 0.1 μF CAP, CERM, 0.1 μF, 50 V,
±10%, X7R, 0603
D1, D2 2 30 V Diode, Schottky, 30 V, 2 A,
AEC-Q101, SOD-123FL
H3, H4, H5, 4 Bumpon, Hemisphere, 0.44
H6 X 0.20, Clear
J1 1 Connector, Receptacle,
Micro-USB Type B, R/A,
Bottom Mount SMT
SLUUCK6 – DECEMBER 2021
Submit Document Feedback

Table 9-1. TPSM8D624EVM-2V0 Bill of Materials

PackageReference PartNumber
BSR192
SMT Radial G EEE-FC1V101P
1210 GRM32EC81E226KE15L
402 GRM155R71H682KA88D
1210 GRM32ER71A476KE15L
402 8.85012E+11
603 GRM188Z71A106MA73D
7343-40 6TPF470MAH
603 C0603C104K5RACTU
SOD-123FL MBR230LSFT1G
Transparent Bumpon SJ-5303 (CLEAR)
MICRO USB CONN, R/A 1981568-1
Copyright © 2021 Texas Instruments Incorporated
Manufacturer Alternate Alternate
PartNumber Manufacturer
Any
Panasonic
MuRata
MuRata
MuRata
Wurth Elektronik
MuRata
Panasonic
Kemet
ON Semiconductor
3M
TE Connectivity
TPSM8D6C24EVM-2V0 User's Guide
Bill of Materials
