e Instructions
Model Number:
B9758, C4644
f Instructions
Numéros de modèle :
B9758, C4644
S Instrucciones
Números de modelo:
B9758, C4644
e
Product features and decorations may vary from picture above.
f
Les caractéristiques du produit et les décorations peuvent varier par rapport à l'illustration ci-dessus.
S
Las características y decoración del producto pueden variar de las mostradas.
e
• Please read these instructions before use of this product. Keep
this instruction sheet, as it contains important information.
• Adult assembly is required. Tool needed for assembly: Phillips
Screwdriver (not included).
• Requires four "D" (LR20) alkaline batteries (not included)
for operation.
•Only to be used by children that cannot climb out of seat.
f
• Lire les instructions avant d'utiliser ce produit. Les conserver
car elles contiennent des renseignements importants.
• Le produit doit être assemblé par un adulte. Outil requis pour
l'assemblage : tournevis cruciforme (non fourni).
• Fonctionne avec 4 piles alcalines D (LR20), non fournies.
•Utiliser seulement pour un enfant incapable de sortir seul de
la balançoire.
S
• Leer estas instrucciones antes de usar este producto. Guardar
estas instrucciones para futura referencia, ya que contienen
información de importancia acerca del producto.
•Requiere montaje por un adulto. Herramienta necesaria para
el montaje (no incluida): destornillador de estrella.
• Funciona con cuatro pilas alcalinas tipo 4 x "D" (LR20) x 1,5V
(no incluidas). LEA LAS INSTRUCCIONES ANTES DE USAR
ESTE PRODUCTO.
•Solo usar con niños que no puedan salirse del asiento.
