Deluxe Quick Response Swing
with Remote Control
Model Number: B1637
PLEASE KEEP FOR FUTURE REFERENCE.
Please read these instructions before assembly and use of this product, as they contain important information.
Adult assembly is required.
Tools needed for assembly: Phillips Screwdriver and Scissors (both not included).
Requires four "D" (LR20) alkaline batteries for swinging and sound operation;
three "AA" (LR6) alkaline batteries for sound 'n lights tray operation; and
three "AAA" (LR03) alkaline batteries for remote operation (all batteries not included).
Maximum Weight Limit: 24 lbs. (10.9 kg).
IMPORTANT! The maximum weight limit for this product is 24 lbs. If your child weighs
less than 24 lbs., but is really active and appears to be able to climb
out of the swing, immediately discontinue its use.

Advertisement

Table of Contents
loading

Related Manuals for Fisher-Price B1637

Summary of Contents for Fisher-Price B1637

  • Page 1 Deluxe Quick Response Swing with Remote Control Model Number: B1637 PLEASE KEEP FOR FUTURE REFERENCE. Please read these instructions before assembly and use of this product, as they contain important information. Adult assembly is required. Tools needed for assembly: Phillips Screwdriver and Scissors (both not included).

  • Page 2: Warnings And Caution

    Usually, we can solve the problem over the telephone or send you replacement parts. Please call Fisher-Price® Consumer Relations, toll-free at 1-800-432-5437, 8 AM - 6 PM EST Monday through Friday. Hearing-impaired consumers using TTY/TDD equipment, please call 1-800-382-7470.
  • Page 3 Parts 2 Front Legs (Longer) Motor Housing Front Base Seat with Restraint 2 Seat Wire Caps Seat Wire M4 Bolt - 1 Shown Actual Size Note: Tighten or loosen all screws and bolt with a Phillips screwdriver. Do not over-tighten the screws. Remote Control and Holder (with M4 Lock Nut)
  • Page 4 IMPORTANT! Before assembly, inspect this product for damaged hardware, loose joints, missing parts or sharp edges. DO NOT use if any parts are missing or broken. Contact Fisher-Price® for replacement parts and instructions if needed. Never substitute parts. Front Legs...
  • Page 5 Assembly Holder • Position the holder so that the hole in the holder aligns with the hole in the front leg. • Insert the M4 bolt through the holder, front leg and into the lock nut. Tighten the bolt. Holder •...
  • Page 6 Assembly Pull Rear • Pull both rear legs out until they “snap” into place. Press Button Front Rear Base Base • Place the rear base on a flat surface so that the buttons face the front base. • While pressing the buttons on each side of the rear base, fit the rear legs onto the rear base.
  • Page 7 Assembly M4 Lock Nut Rounded Side Shown Actual Size Seat Lock Nut Tubes Hexagonal Opening • Position the bracket so that the tall end is toward the bottom edge of the seat. Hint: The M4 lock nuts have been assembled to the bracket at the factory.
  • Page 8 Assembly Slots • Lift the seat tubes slightly. • With the seat wire hanging down, insert the ends of the seat wire through the slots in the seat, as shown. Rounded Edge Up Seat Wire Cap Hole Seat Wire Ends of Seat Wire Seat Wire •...
  • Page 9 Assembly Frame Hub Push Button Swing Tube Front of Seat Curved Front Base • Position the seat assembly so that the front of the seat is toward the curved front base. • While pressing the buttons on the swing tubes, insert them into the frame hubs.

  • Page 10: Battery Installation

    Assembly Elastic Loop • Fit the bottom edge of the pad around the bottom edge of the seat. • Hook the elastic loops on each side of the pad to the peg on the back of the accessory bins. • Position the lights ‘n sounds tray on a flat surface, with the roller facing you.

  • Page 11: Battery Safety Information

    Battery Installation Lights ‘n Sounds Tray • Locate the battery compartment door on the bottom of the lights ‘n sounds tray. • Loosen the screw in the battery compartment door. Lift to remove the battery compartment door. • Insert three “AA” (LR6) alkaline batteries. •...

  • Page 12: Securing Your Child

    Securing Your Child IMPORTANT! Before each use, inspect this product for damaged hardware, loose joints, missing parts or sharp edges. DO NOT use if any parts are missing or broken. Contact Fisher-Price® for replacement parts and instructions if needed. Never substitute parts.

  • Page 13: Adjusting The Seat

    Adjusting the Seat Upright Recline Adjust the seat angle in any of three positions: Upright, Semi-Recline or Recline. To adjust the seat angle: Push down on the seat back to position the seat wire in the desired groove in the bracket for Upright, Semi-Recline or Recline.
  • Page 14 Swinging IMPORTANT! The maximum weight limit for this product is 24 lbs. If your child weighs less than 24 lbs., but is really active and appears to be able to climb out of the swing, immediately discontinue its use. • Slide the power switch to on If you do not use the remote, this swing continues swinging until the power switch is turned off Power L.E.D.
  • Page 15 Storage Press Buttons • Fit the bottom of the remote into the cupped portion of the holder. • Push to “snap” the top of the remote under the holder clips. • Press the button on the inside of each housing and push the rear legs toward the front legs.

  • Page 16: For Best Results

    YOU MAY ALSO HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A. ©2003 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
