- Page 1 CSR10 THEATER SURROUNDING SPEAKER USER'S MANUAL U M- CSR10 - 2 0 1 8 0 6 0 5 Ve r...
- Page 2 SAFETY INSTRUCTIONS PLEASE READ THIS MANUAL FIRST Thank you for buyin product. Read this manual first as it will help you operate the system properly. Please keep this manual for future reference. WARNING: This product must be installed by professionals. When using hanging brackets or rigging other than those supplied with the product, please ensure they comply with the local safety codes.
-
Page 3: Table Of Contents
CSR10 CONTENT THEATER SURROUNDING SPEAKER CONTENT INTRODUCTION Features Description Applications CONNECTION Connection Method System Connection Reference INSTALLATION Mounting Accessories Installation Reference TECHNICAL SPECIFICATION Technical Sheet Frequency Response Curve & Impedance Curve 2D Dimension Product information subjeets to be updated without notification,... -
Page 4: Introduction
CSR10 PRODUCT INTRODUCTION THEATER SURROUNDING SPEAKER CSR10 10" Two-way full range speaker Features: Two transducers two- way full range One 10 big power woofer " One 44mm compression driver Frequency response (-3dB):60Hz-20kHz Sensitivity 94dB, Maximum SPL 120dB Rated power 200W, peak power 500W... -
Page 5: Connection
CSR10 PRODUCT INTRODUCTION THEATER SURROUNDING SPEAKER CSR10 with one terminal to connect amplifier. Terminal: Connection Diagram: INPUT Red: + Crossover Black: - HIGH Red: + Black: - System Connection BRIDGE IN CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CHA OUTPUT... -
Page 6: Installation
CSR10 INSTALLATION THEATER SURROUNDING SPEAKER Accessories(Optional) Installation Method: CSR10 with 6 lifting points for installation. 1. Hanging plate 1. Hanging Method: Commodity Code: 101.06.0036.00153_90*40mm/black 300 mm 6.8mm 68 mm 68 mm 2. U bracket Commodity Code: 101.06.0020.00004 ） 2. Hanging Method（... -
Page 7: Technical Specification
CSR10 TECHNICAL SPECIFICATION THEATER SURROUNDING SPEAKER Specification Speaker Testing Method 1. Frequency Response Construction: passive wooden speaker 1X10" LF Transducers: Use pink noise to test the speaker in the anechoic chamber, adjust the level to make the speaker work at its rated impedance... -
Page 8: 2D Dimension
CSR10 TECHNICAL SPECIFICATION THEATER SURROUNDING SPEAKER 2D Dimension Back 556mm [21.9in] Front Side Bottom... - Page 9 Notes:...
- Page 10 www.beta3pro.com.
