SAFETY INSTRUCTIONS PLEASE READ THIS MANUAL FIRST Thank you for a buying product. Read this manual first as it will help you operate the system properly. Please keep this manual for future reference. WARNING: This product must be installed by professionals. When using hanging brackets or rigging other than those supplied with the product, please ensure they comply with the local safety codes.
db100C-W controller user guide LINE INPUT 1 S/N: 100C- POWER LINE INPUT 2 VU METER SIG + SIG - SIG - SIG + RoHS 12 - 12 + VU OUTPUT INDICATOR + 30dB 12 + 12 - Function introduce 1. Master volume 9.
Page 26
The connection of db-series is very convenient, According to needs to choose the number of db100 connect together. But maximum is 6 to connect with one controller. It s easy and quick to install a sound system. For the needed power supply please strictly refer to products instruction book but normally minimum needed external power is 12V/40A.
