Freestanding cooker
Installation instructions
User guide
OR90SDBGFPX models
and
NZ AU

Advertisement

Table of Contents
loading

Related Manuals for Fisher & Paykel OR90SDBGFPX

Summary of Contents for Fisher & Paykel OR90SDBGFPX

  • Page 1 Freestanding cooker Installation instructions User guide OR90SDBGFPX models NZ AU...

  • Page 3: Table Of Contents

    Contents Safety and warnings Installation instructions First use Setting the clock Using your oven Cooking functions Cooking guide Using the rotisserie Using the electronic timer Automatic cooking Using your gas cooktop Care and cleaning Using the Self Clean function Troubleshooting Warranty and service Important! SAVE THESE INSTRUCTIONS...

  • Page 4: Safety And Warnings

    Safety and warnings Installation WARNING! Electrical Shock Hazard Always disconnect the cooker from the mains electricity supply before carrying out any maintenance operations or repairs. Failure to follow this advice may result in death or electrical shock. WARNING! Cut Hazard Take care - panel edges are sharp.
  • Page 5 Safety and warnings Electrical This cooker is to be installed and connected to the electricity supply only by an authorised person. If the installation requires alterations to the domestic electrical system, call a qualified electrician. The electrician should also check that the electrical system is suitable for the electricity drawn by the cooker.
  • Page 6 Safety and warnings Operation Your freestanding cooker has been carefully designed to operate safely during normal cooking procedures. Please keep the following guidelines in mind when you are using it: WARNING! Explosion Hazard Do not store flammable materials such as gasoline near the cooktop. Do not store flammable material in the oven or storage compartment.
  • Page 7 Safety and warnings Important safety instructions Never leave the appliance unattended when in use. Boilover causes smoking and greasy spillovers that may ignite. Isolating switch: make sure this cooker is connected to a circuit which incorporates an isolating switch providing full disconnection from the power supply. Household appliances are not intended to be played with by children.
  • Page 8 Safety and warnings Operation Important safety instructions Do not place aluminium foil or plastic dishes on the cooktop burners. Do not let large saucepans or frying pans overlap the bench as this can deflect heat onto your benchtop and damage the surface. Do not let large saucepans, frying pans or woks push any other pans aside.
  • Page 9 Safety and warnings Operation Important safety instructions Never leave the appliance unattended when in use. Boilover causes smoking and greasy spillovers that may ignite. Wear proper apparel. Do not wear loose fitting or hanging garments when using the appliance. They could ignite or melt if they touch an element or hot surface and you could be burned. Always keep oven vents unobstructed.

  • Page 10: Installation Instructions

    Installation instructions Installation instructions Dimensions and clearances Installation clearances and protection of combustible surfaces shall comply with the current local regulations eg. AS/NZS5601.1:2010 Gas Installations code. Installation shall comply with the dimensions in Fig. 1, bearing in mind the following requirements: Overhead Clearances In no case shall the clearance above the highest part of the cooker be less than 600 mm or, for an overhead exhaust fan, 750 mm.
  • Page 11 Installation instructions Cooker overall dimensions [mm] • height: 897 - • product width: • depth: • cavity width Fig. 1 Dimensions and distances from cooker Dotted line showing Locating the area for gas and electrical connection the position of the cooker when installed Area for gas connection...
  • Page 12 Installation instructions Installation instructions Levelling the cooker Important! Using the supplied adjustable feet is MANDATORY. For safety reasons and to ensure adequate ventilation, the cooker chassis MUST NOT sit directly on the floor, a plinth, or other support surface. For ease of installation, first remove the kickstrip.
  • Page 13 Installation instructions Fitting the anti-tilt bracket Important! To restrain the appliance and prevent it tipping accidentally, the anti- Dotted line showing the position tilt bracket and restraining plate of the cooker when installed supplied must be fitted according to the instructions below. Drill four 8mm diameter holes for Fig.
  • Page 14 Installation instructions Installation instructions Moving the cooker Important! To prevent damaging the adjustable feet or lower trim, ensure the cooker is always lifted by two people. Do not lift the cooker by the door handles. DO NOT DRAG the cooker. Lift the feet clear of the floor.
  • Page 15 Installation instructions Connecting the cooker to the gas supply The gas connection must be carried out by an authorised person according to the relevant standards. Before connecting the appliance to the gas main, mount the brass conical adaptor onto the gas inlet pipe, upon which the washer has been placed (see Fig.s 12-13 following).
  • Page 16 Installation instructions Gas connection for Gas connection for NATURAL GAS Gas inlet pipe Gas inlet pipe Nipple Nipple Washer Washer Brass conical adaptor Brass conical adaptor Test (Thread tight: use (Thread tight: use point suitable seal) suitable seal) Test point adaptor Gas pressure regulator Test...
  • Page 17 Installation instructions Leak-testing and flame-testing the cooker After installing the freestanding cooker and connecting the gas supply: Using a suitable leak detection fluid solution, check each gas connection one at a time by brushing the solution over the connection. The presence of bubbles will indicate a leak. If there is a leak, tighten the fitting and then recheck for leaks.
  • Page 18 Installation instructions Injector Injector Fig. 15 Semi-rapid burner Fig. 16 Triple-ring wok burner Injectors for Injector for Injectors for Injector for outer crown inner crown outer crown nner crown Fig. 17 Dual burner...
  • Page 19 Installation instructions Adjusting the minimum burner setting Check whether the flame spreads to all burner ports when the burner is lit with the gas valve set to the minimum position. If some ports do not light, increase the minimum gas rate setting. Check whether the burner remains lit even when the gas valve is turned quickly from the maximum to the minimum position.
  • Page 20 Installation instructions Natural gas Test Point Pressure [kPa] 2.75 Injector Injector Orifice Dia. Consumption Orifice Dia. Consumption BURNER [mm] [MJ/h] [mm] [MJ/h] 1.17 6.50 0.70 6.30 Semi-rapid 1.54 11.88 0.98 12.00 Triple-ring wok 0.76 0.50 16.20 16.20 (inner crown) (inner crown) (inner and (inner and Dual...
  • Page 21 Installation instructions Wiring diagram...

  • Page 23: First Use

    First use OR90SDBGFPX Fig. 20 Control panel - Control buttons Rear right (semi-rapid) burner dial Clock display Front right (triple-ring) burner dial Temperature dial Function indicator light Function dial Door lock indicator light Front left (triple-ring wok) burner dial Rear left (semi-rapid) burner dial...
  • Page 24 First use Buttons 12:00 sets the timer sets the cooking time sets the stop time for automatic cooking set the oven temperature / select Celsius or Fahrenheit decreases the time and temperature increases the time and temperature Fig. 21 Clock display and control buttons sets the Self Clean time starts the Self Clean cycle Illuminated symbols...

  • Page 25: Setting The Clock

    Using your oven Before using your new oven, please: Read this user guide, taking special note of the ‘Safety and warnings’ section. Remove all accessories and packaging. Peel the protective film off all surfaces and accessories. Set the clock. The oven will not work until the clock has been set. See ‘Setting the clock’ . If not already fitted, fit the telescopic sliding shelf supports.
  • Page 26 Using your oven Door lock Function indicator light indicator light Fig. 23 Function and temperature dials FUNCTION TEMPERATURE 210 C 225C Select a function Adjust the temperature Rotate the function dial to select a function There are two ways to set the The function indicator light will come on.
  • Page 27 Using your oven When the oven is preheating and during To check the set temperature cooking Press the button. indicator will show in the display. The display will flash showing the set indicator will go out when the oven temperature. has reached the set temperature.

  • Page 28: Cooking Functions

    Cooking functions OVEN LAMP Only the oven light comes on. It remains on in all the cooking functions. DEFROST this is not a cooking function Only the oven fan comes on. The fan circulates air around the oven, speeding up the defrosting process by approximately 30%.
  • Page 29 Cooking functions ROTISSERIE A delicious way to cook meat and poultry. The slowly rotating meat is basted continuously in its own juices, making it tender on the inside and well browned and full of flavour on the outside. See ‘Using the rotisserie’ . SELF CLEAN this is not a cooking function The oven heats to a high temperature, reducing food residue to a fine ash that can be wiped out...

  • Page 30: Cooking Guide

    Cooking guide Changing the oven from Celsius to Fahrenheit You can set your oven to display the temperature in Fahrenheit or Celsius. Select a cooking function. While the display is flashing, press to reduce the oven to the minimum temperature C / 120 When the display stops flashing , press and hold the button until...
  • Page 31 Cooking guide SAVOURY Recommended Shelf Food Shelves Temp (°C) Time (mins) Function positions 15-20 Roast Chicken Rotisserie Rotisserie 180-210 min/450g Lasagne Single Fan Bake 175-180 45-50 Quiche Single Pastry Bake 180-200 30-40 Pizza Single Pastry Bake 225-250 10-15 Casserole Single Fan Forced 170-190 55-70...

  • Page 32: Using The Rotisserie

    Using the rotisserie Important! If fitted, remove the sliding shelf supports from shelf position 1 before using the rotisserie. Remove all oven shelves and trays. Prepare the rotisserie supports. Place the grill tray on the benchtop. Insert the supports into the lock studs. Push the supports all the way down to lock them in firmly.
  • Page 33 Using the rotisserie Position the skewer on the supports. Place the skewer on the supports, and check that the meat does not touch the grill tray. Twist the handle off. It must not be left in the oven. Place the rotisserie in the oven. Slide the grill tray all the way to the back on shelf position 1.

  • Page 34: Using The Electronic Timer

    Using the electronic timer 12:00 You can use the timer at any time, even when the oven is not in use. Important! The timer does NOT turn the oven off. To set the timer Press the timer button. 0:00. The time will show Press buttons to set the time you want (up to 3 hours in one minute steps).

  • Page 35: Automatic Cooking

    Automatic cooking 12:00 To set the oven for automatic cooking Set the oven Check the clock shows the correct time (eg 12:07). Select the function and set the temperature. The oven will turn on. Set the cooking time Decide how long the food will take to cook, allowing time for preheating if necessary (eg 40 minutes).

  • Page 36: Using Your Gas Cooktop

    Using your gas cooktop Fig 25 Cooktop layout Triple-ring wok burner Semi-rapid burner Dual burner Gas burners The dial controls the flow of gas through the safety valve. Semi-rapid and triple-ring wok burners = closed valve (OFF) = maximum flow of semi-rapid and triple-ring burner burners = minimum flow of semi-rapid and triple-ring burner burners You can choose to cook at any heat between , but never...
  • Page 37 Using your gas cooktop Before using your cooktop Before using your new cooktop, please: Read this user guide, taking special note of the ‘Safety and warnings’ section. Make sure all burner control dials are turned off. Turn the power to the cooker on at the wall. Using the gas burners Choose the control dial for the burner you want to use.
  • Page 38 Using your gas cooktop If a burner does not light Check that: The cooker is plugged in and the electricity is switched on. The gas is turned on. The gas bottle is not empty (if you are using bottled gas). You have held down the dial for at least 10 seconds.
  • Page 39 Using your gas cooktop Matching cookware to burner Use flat-bottomed pans, and make sure they match the size of the burner, as shown in the following table. A small pot on a large burner is not efficient. Diameters of pans which may be used on the cooktop Burners Minimum Maximum...

  • Page 40: Care And Cleaning

    Care and cleaning Important! Before you start cleaning your cooker, please: Read these cleaning instructions and the ‘Safety and warnings’ section at the start of this user guide. Turn the cooker off at the wall. Make sure the cooker is a safe temperature to touch. Do not use a steam cleaner.
  • Page 41 Care and cleaning Burner parts and pan supports You can remove and clean these parts with hot soapy water or non-abrasive detergents. Clean spills regularly before they become burnt on. Do not wash these parts in a dishwasher. After cleaning, check that the burners and their flame spreaders are dry before replacing correctly.
  • Page 42 Care and cleaning Replacing the triple-ring wok and dual burners Carefully replace the burner parts as per the following Figs. Fit the flame spreader to the housing as shown by the arrow in the Figs.32a-32b. Make sure the burner is not able to rotate (Fig. 33). Check that: the ignitor is always clean to ensure trouble-free sparking.
  • Page 43 Care and cleaning Cleaning the inside of your oven Note: if using the Self Clean function remove all shelves and side racks first. See ‘Using the Self Clean function’ . Do not use abrasive cleaners, cloths or pads to clean the enamel. Removing the side racks Using a small coin or a flat-head screwdriver, loosen and remove the front fixing screw.
  • Page 44 Care and cleaning Cleaning the enamel cavity Clean the enamel on the inside of the oven when it has cooled down, using household detergents. You may use ‘off the shelf’ oven cleaners, if you carefully follow the manufacturers’ instructions. Cleaning the grill tray and shelves Clean these in hot, soapy water.
  • Page 45 Care and cleaning Fitting and removing the sliding shelf supports When fitting the sliding shelf supports, make sure that you fit: the side racks the slides to the top wire of a shelf position both sides of each pair of slides both slides on the same level.
  • Page 46 Care and cleaning Storage Drawer The drawer opens like a normal drawer. The drawer slides prevent the drawer from sliding out. To remove the drawer Open the drawer fully. Press the lever on the left guide rail down and the right guide rail up. Holding the levers, disengage and remove the drawer.
  • Page 47 Care and cleaning Replacing the oven light bulbs The oven light bulbs (12V/20 W halogen) have a very long life, but if you should need to replace one, use only a replacement bulb purchased from your nearest Fisher & Paykel dealer and follow these steps.
  • Page 48 Care and cleaning Removing and replacing the door glass panes for cleaning. Make sure you follow the precautions and instructions below very carefully. Replacing the glass panes and the door incorrectly may result in damage to the oven and may void your warranty.
  • Page 49 Care and cleaning Removing the door Turn the oven off at the wall. Make sure Open the levers on the left and right you have prepared enough space for hinges to their full extent, as shown. resting the door and its glass panes on a clean, flat surface.
  • Page 50 Care and cleaning Remove the inner and middle glass panes Glass retainer Press down on both tabs (1) to release the Lift the inner pane (D) slightly (1), then glass retainer (2). gently slide out (2). Slide the first middle pane (C) slightly Slide the second middle pane (B) slightly towards yourself (1), then lift (2) and slide towards yourself (1), then lift (2) and slide...
  • Page 51 Care and cleaning After cleaning, replace the glass panes When replacing the glass panes, make sure that: you replace all three panes correctly, as shown. Each pane must be in the position described below in order to fit into the door and to ensure that the oven operates safely and correctly. you take extra care not to bump the edges of the glass against any object or surface.
  • Page 52 Care and cleaning Take the other middle pane (C) and hold it firmly. Insert it in the next pair of grooves (1), push it slightly towards yourself (2) and gently lower into place (3). Angle-cut corner Take the inner pane (D), holding it with the angle-cut corner orientated as shown. Insert it in the uppermost pair of grooves (1), push it slightly towards yourself (2) and gently lower into place (3).
  • Page 53 Care and cleaning Clamp Clamp Glass retainer Position the glass retainer, as shown. It should sit on the bottom edge of the outer glass (A). Check that the clamps of the glass retainer are not deformed or damaged. “Click” Glass retainer Gently push the glass retainer back into place.
  • Page 54 Care and cleaning Refit the door Notch Hold the door firmly. Insert the hinge tongues into the slots, making sure that the notches on both sides drop into place as shown. Open the door to its full extent. Fully close the levers on the left and right hinges, as shown.
  • Page 55 Care and cleaning Sensor Door Lock Check the door shuts completely and that the door lock (at top centre of door) is not obstructing the door. Check the door sensor (top left) is correctly operating: start a ‘Self Clean’ cycle (see ‘Using the Self clean function’) wait five minutes - the door lock indicator light should turn on.

  • Page 56: Using The Self Clean Function

    Using the Self Clean function During the pyrolytic Self Clean cycle the extremely high temperature burns off and breaks down grime and grease deposits. All that is left is a small amount of grey ash that you can easily remove. You can set the Self Clean cycle time between one and a half and three hours.
  • Page 57 Using the Self Clean function To start a Self Clean cycle Remove oven shelves, side racks and all other accessories, bakeware, and utensils. Wipe up any spills. Failure to do so may discolour the oven surfaces. Check the inner glass pane of the oven door (D). If it has soiling on it (eg stains from greasy splatter), you will need to clean it manually before starting a Self Clean cycle.
  • Page 58 Using the Self Clean function Select the Self Clean Function P1:30 The display will show will flash Adjust the cycle time (optional) You may set the time between 1-1/2 hours (P1:30 and 3 hours (P3:00). For normal soiling use a 3 hour cycle. For light or localised soiling decrease the time. Press the button - the will go out.

  • Page 59: Troubleshooting

    Troubleshooting Problem Possible solutions A burner does not light. Check the cooker is switched on at the wall. Check the gas supply valve is turned on and the supply to the house is working. You should hear the gas when you turn a burner on. Check the gas bottle is not empty.
  • Page 60 Troubleshooting Problem Possible solutions The oven door does not open The oven is too hot for the door to be after a Self Clean cycle. opened safely. When the oven has cooled to a safe temperature the door will automatically unlock and the door lock indicator will go out.

  • Page 61: Warranty And Service

    Warranty and service Before you call for service or assistance ... Check the things you can do yourself. Refer to the installation instructions and your user guide and check that: Your product is correctly installed. You are familiar with its normal operation. If after checking these points you still need assistance, please refer to the Service &...
  • Page 64 www.fi sherpaykel.com Copyright © Fisher & Paykel 2013. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available.
