- Page 1 INSTALLATION MANUAL PENTEK INTELLIDRIVE ™ PID2000-1123 Installation/Operation/Parts For further operating, installation, or maintenance assistance: Call 1-300-137-344 www.onga.com.au PNX900 (Rev. 9/14/10) ©2010...
-
Page 2: Table Of Contents
Table of Contents Owner’s Information..........................2 General Safety ............................3 Description / Typical Installation........................ 4 Keypad Nomenclature & Functions ......................5 Installation..............................6 Connections............................6–8 Programming ............................8–9 Advanced Programming........................9–11 I/O Connections ............................12 Troubleshooting ..........................13–15 Wire Sizing Tables ........................... 15 Repair Parts.............................. -
Page 3: General Safety
Safety GENERAL SAFETY Risk of electrical shock if VFD is connected to the power wiring before hanging the box. Read the Owner’s Manual and related documentation Always hang the VFD box before connecting the wires to it. carefully before attempting to install or operate the PENTEK INTELLIDRIVE . -
Page 4: Description / Typical Installation
Description / Typical Installation Transducer • Do not allow loose foreign objects which can conduct electricity (such as screws and metal fragments) inside The drive uses a 4-20mA, 0-690 kPa pressure transducer to the VFD box at any time. Do not allow flammable control the speed of the motor. -
Page 5: Keypad Nomenclature & Functions
Keypad Table 1: Model Number Structure The PENTEK INTELLIDRIVE has a thermostatically controlled internal fan. The fan may not operate under PID2000-1123: normal operating conditions. It will automatically start PID2000 – 1 – 1 – 2 – 3 when necessary to cool the drive. Keypad Product Family The Keypad programs the drive, monitors the status of the... -
Page 6: Installation
Installation INSTALLATION Wiring To allow for ease of wiring, the wiring area is free of Mounting (See Figure 3) electronics other than the terminals. Conduit holes and Mount the drive in an easily accessible area with knockouts are located so that the wire can be fed straight temperature maintained between –4°F and 104°F (–20°C to through to the connectors, with minimal bending. -
Page 7: Connections
Connections Table 4: Control Pressure Set Point and Output Connections (See Figure 5, Page 7): Tank Pre-Charge Pressure Values See Table 6, Page 15, for correct wires sizes, VFD to motor. The output of PID2000 Series drives is 220V single phase Pressure Setpoint Precharge Pressure power. -
Page 8: Programming
Connections / Operation The transducer terminals, marked AI+ and AI-, are located to the left of the output terminals. Connect the red wire of Service Factor Amps (See Table 5) the transducer cable to AI+, connect the black wire to AI–, To get the best performance out of your pump, be and connect the cable shield to the metal lug to the right. -
Page 9: Advanced Programming
Operation / Programming Changing a Parameter Value: Pump out the well (if necessary): Direct the pump’s discharge to an appropriate NOTE: This procedure works for ANY parameter. location not connected to the system and press Pump 1. Find the parameter and display the current parameter Out. - Page 10 Operation / Programming 1) SETTINGS: (Has 5 submenus) Password (2 parameters): Time (2 parameters): Password Timeout: Sets the time (in minutes) that Hour: Allows you to change the time of day. the drive takes to lock out the password-protected Date: Allows you to change the calendar day. (blue) buttons on the keypad.
- Page 11 Advanced Programming 3) SENSOR (2 parameters plus Reset): 6) I/O (Two Submenus): Min Pressure (kPa): The minimum pressure of the External Input (4 parameters – see Figures 6 through 9, transducer 0 kPa. The default is 0 kPa. Do not Page 12).
-
Page 12: I/O Connections
I/O Connections The I/O terminals are located in the center of the wiring Output Relay Rating: compartment, to the left of the transducer terminals. The The unique design of the PENTEK INTELLIDRIVE allows Relay Output terminal is marked O1. The Relay Output this output to be 24V DC or 24-240V AC. -
Page 13: Troubleshooting
Troubleshooting Fault Display Possible Causes Actions Over Shorted output. Check for any shorts in the motor cables. Current Motor current exceeded the S. F. Amp Make sure that motor Service Factor Amps are correct. Motor oversized or pump undersized. Make sure that pump and motor are sized correctly. - Page 14 Troubleshooting Fault Display Possible Causes Actions Shorted Short in transducer wires. Check for shorted transducer wires, Transducer reversed leads, or damaged insulation. Failed transducer. Disconnect transducer from cable and press auto start; if the error now reads “Open Transducer” (and leads are not reversed) then replace the transducer.
-
Page 15: Wire Sizing Tables
Troubleshooting / Wiring Size Charts Warning Cause Drive Operation TPM: Service Motor current has exceeded S F Amps. Drive goes into TPM and limits the motor Amps current. TPM: Speed Drive internal temperature limit Drive goes into TPM and limits the motor Reduced exceeded. -
Page 16: Repair Parts
Your only remedy, and PENTAIR WATER’s only duty, is that PENTAIR WATER repair or replace defective products (at PENTAIR WATER’s choice). You must pay all labor and shipping charges associated with this warranty and must request warranty service through the installing dealer as soon as a problem is discovered.
