Canon BJC-S200 Setup Instructions

1
Unpack the Printer
1
Carefully remove all items from the box.
S200 Series
Color Bubble Jet Printer
Paper Rest
Output Tray
Documentation
and Software Kit
Printhead (ink tanks are included)
Power Cord
Start Here
Easy Setup Instructions
2
Prepare the Printer
1
Remove the shipping tape from the front,
sides and inside of the printer.
Shipping Tape
2 Plug the power cord into the back of the
printer and connect the other end to a
power outlet.
The printer automatically turns on when
the printer is plugged in.
3 Open the front cover. The printhead holder
automatically moves to the center.
Serial
number
4 Write down the serial number located to
the right of the printhead. You will need
this later to register the product.
3
Prepare the Printhead
1 Remove the printhead from its package.
2
Remove the protective cap and tape from
the printhead.
NOTE: Do not touch the electrical contacts.
Electrical contacts
4
Install Printhead
1 Ensure that the blue lock lever is raised.
2 Gently slide the printhead into the holder
until it is securely seated.
Do not press it down.
3
Lower the lock lever until it locks into place.
4
Close the front cover and attach the
paper rest and output tray.
5 Place a stack of blank paper (up to 50 sheets)
in the paper rest.
Color Bubble Jet Printer
TM
S200
5
Connect the Printer
To Your Computer
1 Unplug the power cord from the back
of the printer.
IMPORTANT: Be sure printer is
unplugged before continuing,
or the computer will attempt to
install the printer driver before
the printer is ready.
2 Turn your computer off.
3
Connect one end of a USB cable (not
included) to the computer, the other to
the printer.
USB Port
USB Port
USB Cable
Continue with Step 6
on side two.
