- Page 1 TECHNICAL MANUAL Simplebus2 Ultra audio module Art. UT2010 Passion.Technology.Design.
-
Page 2: Warning
• any purpose other than the intended use, • failure to observe the indications and warnings contained in this Manual / Instruction sheet. Comelit Group S.p.A. reserves the right to change the information provided in this Manual / Instruction Sheet at any time and without prior notice. -
Page 3: Table Of Contents
Table of contents Warning .................... 2 Description ..................4 UT2010 ......................4 Technical specifications ..............6 Art. UT2010 ....................6 Installation ..................7 Flush-mounted installation composition table ........7 Surface-mounted installation composition table ........7 Flush-mounted installation ............. 8 Removing nameplates (2A) / module (2B) ..........9 Installation with side-by-side boxes .............10 Wall-mounted installation ............. -
Page 4: Description
Description UT2010 Audio module for Ultra entrance panel, Simplebus2 system. For use in systems with power supply unit art. 1210 / 1210A. Easy to install and simple to configure, thanks to the smart programming of call buttons. Twilight sensor for automatic nameplate backlighting switch-off during daylight hours. Omnidirectional digital microphone and double loudspeaker for high-fidelity audio. - Page 5 3. 4. 5. 14. 15. 1. Indicator LEDs 13. Terminal block for connection: call sent (green) / system busy (red) RTE programmable RTE (local lock-release input) or DO input (door open indication) lock-release enabled GND SE- RTE and door lock input reference negative communication enabled SE+ electric door lock connection...
-
Page 6: Technical Specifications
Technical specifications Art. UT2010 GENERAL DATA Type Modular Product height (mm) Product width (mm) Product depth (mm) Product colour Black RAL9005, Transparent, Aluminium Product weight (g) Coating material type Polycarbonate, Aluminium alloy Flush mounting Yes, with specific accessory Surface mounting Yes, with specific accessory COMPATIBLE SYSTEMS Simplebus 2 audio/video with... -
Page 7: Installation
Installation The entrance panel is available in flush-mounted or surface-mounted variants: Flush-mounted installation composition table A = Flush-mounted box B = Rain shield C = Flush-mounted module holder with finishing frame 3110/1 3110/2 3110/3 3110/4 3110/1A 3110/2A 3110/3A 3110/4A UT9181 UT9182 UT9184H UT9183... -
Page 8: Flush-Mounted Installation
Flush-mounted installation Optional Optional BLACK... -
Page 9: Removing Nameplates (2A) / Module (2B)
CLACK! CLACK! CLACK! CLACK! CLACK! CLACK! The button has a nameplate which can be written on (A); alternatively, an adhesive label can be applied (B). The total thickness of the nameplate + adhesive label MAX 0,2 mm must not exceed 0.2 mm. You can visit the website pro.comelitgroup.com to download the PDF to print the entrance panel name cards, using the MAX 0,2 mm... -
Page 10: Installation With Side-By-Side Boxes
Installation with side-by-side boxes Before installing the boxes in the wall, fit the spacers. -
Page 11: Wall-Mounted Installation
Wall-mounted installation Optional Optional BLACK... -
Page 12: Removing Nameplates (2A) / Module (2B)
CLACK! CLACK! CLACK! CLACK! CLACK! CLACK! The button has a nameplate which can be written on (A); alternatively, an adhesive label can be applied (B). The total thickness of the nameplate + adhesive label MAX 0,2 mm must not exceed 0.2 mm. You can visit the website pro.comelitgroup.com to download the PDF to print the entrance panel name cards, using the MAX 0,2 mm... -
Page 13: Installation With Side-By-Side Boxes
Installation with side-by-side boxes... -
Page 14: Connections
Connections UT2010 connections 1210A 1210 R GND NO NC UT2010 Max 20 m. Local door-opener button. UT2010 connections with separate power supply 1210A 1595 1210 120-230 V R GND NO NC UT2010 Max 20 m. Local door-opener button. Variants Variant for using the outdoor entrance panel relay Variant for using a safety door lock 12V/24V 1210A... -
Page 15: Module Connection
Module connection On systems with Art. UT2010 and power supply unit Art. 1210/1210A, the maximum current available for the outdoor entrance panel modules is 100 mA. Calculate the total power consumption of the modules in your system configuration using the Consumption table. -
Page 16: Connection Of Button Modules Art. Ut9200
Connection of button modules Art. UT9200 1210A 1210 R GND NO NC BLACK UT2010 UT9200 MAX 8 Max 20 m. Local door-opener button. Max 8 modules (Max 30 modules with additional power supply). Connection of Touchscreen module Art. UT9270 Variant with separate power supply Maximum 80 users >... -
Page 17: Programming
Programming For correct programming, follow the instructions below in order Configure button type Address button modules III. Program call addresses Configuring the button type to maintain during normal operation (single/dual) DIP 6: configuring button type: Single button (DIP6 ON). default Dual button (DIP6 OFF, default). -
Page 18: Smart Programming Of Consecutive Addresses
Smart programming of consecutive addresses default DIP 6: configuring button type: Single button (DIP6 ON). Dual button (DIP6 OFF, default). Set the address of the apartment you wish to call (for example: 1) using the DIP-switches (see “Addressing table” 1 2 3 4 S1 S2 1 2 3 4 example:... -
Page 19: Programming Of Specific Addresses
Programming of specific addresses default DIP 6: configuring button type: Single button (DIP6 ON). Dual button (DIP6 OFF, default). Set the address of the apartment you wish to call (for example: 25) using the DIP-switches (see “Addressing table” 1 2 3 4 S1 S2 1 2 3 4 example:... -
Page 20: Special Programming Via Dip Switch
Special programming via DIP Switch S1 S2 Take note of the DIP-switch settings 1. Set the dip switches in accordance with 1 2 3 4 the function you wish to program (see “Special programming table”). 2. Press the confirm button. S1 S2 Reset the configuration of the DIP-switches... -
Page 21: Special Programming Table
Special programming table CODE DIP SWITCHES ON FUNCTIONS Audio-visual messages 1,2,7,8 Hebrew 3,7,8 Polish 1,3,7,8 Catalan 2,3,7,8 Galician 1,2,3,7,8 Basque 2,3,4,7,8 Danish 1,2,3,4,7.8 Norwegian 1,2,5,7,8 Swedish 1,2,3,5,7.8 Italian 4,5,7,8 French 1,4,5,7,8 Spanish 2,4,5,7,8 Dutch 1,2,4,5,7.8 Greek 3,4,5,7,8 English 1,3,4,5,7.8 German 2,3,4,5,7.8 Portuguese 2,4,7,8... - Page 22 3,5,6,7,8 Reset wait time (after hang-up or after lock-release): 1 sec 5,7,8 Enables “Reset wait time" on lock-release command (default) Disables “awaiting reset time" on lock-release command (awaiting response time or talk time will be 1,5,7,8 activated) 1,4,5,6,7.8 Send call: single (default) 2,4,5,6,7.8 Call transmission: triple Button tones...
-
