- Page 1 TECHNICAL MANUAL MYCOMELIT: THE APP FOR PROFESSIONALS MYCOMELIT: THE APP FOR PROFESSIONALS MYCOMELIT, L'APP PER IL PROFESSIONISTA FREE DOWNLOAD Ultra Simplebus1 audio/video module art. UT1020, UT1020B, UT1020W Ultra Simplebus1 remote camera audio module art. UT1010VC, UT1010VCB, UT1010VCW...
-
Page 2: Warning
• any purpose other than the intended use, • failure to observe the indications and warnings contained in this Manual / Instruction sheet. Comelit Group S.p.A. reserves the right to change the information provided in this Manual / Instruction Sheet at any time and without prior notice. -
Page 3: Table Of Contents
Table of contents Warning .................... 2 System functions ................32 Operating distances ................33 Description ..................4 Maximum system expansion ..............34 UT1020 ......................4 Maximum expansion per apartment.............34 UT1010VC ....................4 Wiring diagrams................35 Installation notes (art. UT1020) ............6 System performance and layouts ..........36 Technical specifications .............. -
Page 4: Description
Description UT1020 Audio/video module for Ultra entrance panel, Simplebus1 system. To be used in systems with power supply unit art. 1595 and art. 4888C. Wide-angle colour video camera (field of vision: 120° horizontal, 90° vertical) UT1010VC Audio module designed for connection of an analogue remote camera with PAL standard for Ultra entrance panel, Simplebus1 system. - Page 5 4. 5. 6. 14. 15. Art. UT1010VC 1. Indicator LEDs 13. Terminal block for connection: call sent (green) / system busy (red) RTE programmable RTE (local lock-release input) or DO input (door open indication) lock-release enabled GND RTE or DO input reference negative SE electric door lock reference negative call in progress NO NC COM relay contacts...
-
Page 6: Installation Notes (Art. Ut1020)
Installation notes (art. UT1020) 90° 90° 90° 50 cm 50 cm 50 cm 175 cm 120° The camera must not be installed in front of light sources, or in places where the filmed subject is against the light. In dim environments, we recommend additional lighting is provided. -
Page 7: Technical Specifications
Technical specifications Art. UT1020 GENERAL DATA Type Modular Product height (mm) Product width (mm) Product depth (mm) Product weight (g) Black RAL9005, Transparent, Aluminium (art. UT1020), black (art. UT1020B), white Product colour (art. UT1020W) Coating material type Polycarbonate, Aluminium alloy Flush mounting Yes, with specific accessory Surface mounting Yes, with specific accessory COMPATIBLE SYSTEMS... -
Page 8: Art. Ut1010Vc
Art. UT1010VC GENERAL DATA Type Modular Product height (mm) Product width (mm) Product depth (mm) Product weight (g) Black RAL9005, Transparent, Aluminium (art. UT1010VC), black (art. UT1010VCB), Product colour white (art. UT1010VCW) Coating material type Polycarbonate, Aluminium alloy Flush mounting Yes, with specific accessory Surface mounting Yes, with specific accessory COMPATIBLE SYSTEMS... -
Page 9: Installation
Installation The entrance panel is available in flush-mounted or surface-mounted variants: Flush-mounted installation composition table A = Flush-mounted box B = Rain shield C = Flush-mounted module holder with finishing frame 3110/1 3110/1A 3110/2 3110/2A 3110/3 3110/3A 3110/4 3110/4A UT9181 UT9181B UT9182 UT9184H... -
Page 10: Flush-Mounted Installation
Flush-mounted installation Optional Optional BLACK... -
Page 11: Removing Nameplates (2A) / Module (2B)
CLACK! CLACK! CLACK! CLACK! CLACK! CLACK! The button has a nameplate which can be written on (A); alternatively, an adhesive label can be applied (B). The total thickness of the nameplate + adhesive label must not exceed 0.2 mm. MAX 0,2 mm You can visit the website pro.comelitgroup.com to download the PDF to print the entrance panel name cards, using the pre- cut sheets (C) available in our catalogue (art. -
Page 12: Installation With Side-By-Side Boxes
Installation with side-by-side boxes Before installing the boxes in the wall, fit the spacers. -
Page 13: Wall-Mounted Installation
Wall-mounted installation Optional Optional BLACK... -
Page 14: Removing Nameplates (2A) / Module (2B)
CLACK! CLACK! CLACK! CLACK! CLACK! CLACK! The button has a nameplate which can be written on (A); alternatively, an adhesive label can be applied (B). The total thickness of the nameplate + adhesive label MAX 0,2 mm must not exceed 0.2 mm. You can visit the website pro.comelitgroup.com to download the PDF to print the entrance panel name cards, using the pre- cut sheets (C) available in our catalogue (art. -
Page 15: Installation With Side-By-Side Boxes
Installation with side-by-side boxes... -
Page 16: Connections
Connections Standard connection 4888C 1595 120-230 V 12 VAC/VDC 18 Ω MAX SE NO NC UT1020 UT1010VC Max 20 m. Local door-opener button. Variants Variant for using the outdoor entrance panel relay Variant for using a safety door lock 4888C 1595 4888C 1595... -
Page 17: Remote Camera Connection (Art. Ut1010Vc Only)
Remote camera connection (art. UT1010VC only) 4888C 1595 120-230 V ROSSO NERO BLACK 12 VAC/VDC 18 Ω MAX SE NO NC UT1010VC NERO ROSSO BLACK Max 20 m. Local door-opener button. -
Page 18: Module Connection
Module connection Connection of button modules art. UT9200 4888C 1595 120-230 V NERO BLACK 12 VAC/VDC 18 Ω MAX SE NO NC UT1020 UT1010VC ROSSO UT9200 Max 20 m. Local door-opener button. Max 19 with UT1020. Max 24 with UT1010VC. Connection of Touchscreen module art. -
Page 19: Connection Of Number Keypad Module Art. Ut9279M
Connection of number keypad module art. UT9279M 4888C 1595 120-230 V 12 VAC/VDC 18 Ω MAX SE NO NC UT1020 UT1010VC UT9279M Max 20 m. Local door-opener button. Connecting digital call module art. UT9260M 4888C 1595 120-230 V 12 VAC/VDC 18 Ω... -
Page 20: Programming
Programming For correct programming, follow the instructions below in order Configure button type Address button modules III. Program user codes Configuring the button type to maintain during normal operation (single/dual) DIP 6: configuring button type: Single button (DIP6 ON). default Dual button (DIP6 OFF, default). -
Page 21: Programming Consecutive Smart User Codes
Programming consecutive smart user codes default DIP 6: configuring button type: Single button (DIP6 ON). Dual button (DIP6 OFF, default). BEFORE you proceed: Set the user code of the apartment you wish to call (for example: 1) S1 S2 ALL DIP-switches to OFF, including using the DIP-switches DIP 6. -
Page 22: Programming Specific User Codes
Programming specific user codes default DIP 6: configuring button type: Single button (DIP6 ON). Dual button (DIP6 OFF, default). BEFORE you proceed: Set the user code of the apartment S1 S2 ALL DIP-switches to OFF, including you wish to call (for example: 25) DIP 6. -
Page 23: Special Programming Via Dip Switch
Special programming via DIP Switch S1 S2 Make a note of the DIP-switch settings BEFORE you proceed: ALL DIP-switches to OFF, including 1. Set the dip switches in DIP 6. accordance with the function you wish to program (see Special programming table). -
Page 24: Special Programming Table
Special programming table CODE DIP SWITCHES ON FUNCTIONS Audio-visual messages 1,7,8 Czech 1,2,7,8 Hebrew 3,7,8 Polish 1,3,7,8 Catalan 2,3,7,8 Galician 1,2,3,7,8 Basque 2,3,4,7,8 Danish 1,2,3,4,7,8 Norwegian 1,2,5,7,8 Swedish 1,2,3,5,7,8 Italian 4,5,7,8 French 1,4,5,7,8 Spanish 2,4,5,7,8 Dutch 1,2,4,5,7,8 Greek 3,4,5,7,8 English 1,3,4,5,7.8 German 2,3,4,5,7,8... - Page 25 2,5,8 RTE input set as door open indication 1,2,5,8 Self activation time: 60 sec (default) 1,3,5,8 Self activation time: 30 sec 1,3,4,6,7,8 Self activation: enabled (default) 2,3,4,6,7,8 Self activation: disabled 2,4,5,8 System busy signalling time: 10 sec (default) 1,2,4,5,8 System busy signalling time: 300 sec 1,2,3,4,6,7,8 Confirmation tone on user call = enabled (default) 5,6,7,8...
-
Page 26: Twilight Sensor
Twilight sensor Camera LED lighting and button backlighting management The twilight sensor is in AUTO mode by default: the camera and button LEDs light up at night and switch off during the day. To change the setting to ON (LEDs always on) or OFF (LEDs Take note of the DIP-switch always off), proceed as... -
Page 27: Checking Twilight Sensor Operation
S1 S2 Reset the configuration of the DIP-switches Checking twilight sensor operation S1 S2 S1 S2 5 sec If it is daytime and you want to check AUTO mode operation for the twilight sensor, you can proceed as follows: 1. Enter programming mode 2. -
Page 28: Adjusting The Brightness Of The Button Leds And The Camera Light
Adjusting the brightness of the button LEDs and the camera light S1 S2 Take note of the DIP-switch settings BEFORE you proceed: 1. Enable brightness Set ALL DIP-switches to OFF, control including DIP 6. (A) for the camera light (code 171) or (B) for the buttons (code 161) cod. -
Page 29: Light-Me Function
S1 S2 Reset the configuration of the DIP-switches Light-me function Thanks to this function, button backlighting is only enabled on the user’s request, by pressing the LIGHT-ME button on the audio/video module; this saves energy and reduces light pollution. Backlighting management for this button depends on the twilight sensor setting. It is in AUTO mode by default: the LEDs light up at night and switch off during the day. -
Page 30: Replacing The Audio/Video Module With Programming Restore Backup
Replacing the audio/video module with programming restore backup If the audio/video module is replaced, the following instructions must be observed. The procedure should be completed within one hour of removal of the old module. Make a note of the DIP-switch settings Wait for 90 seconds Enter programming mode by moving S2 DIP-switch upwards... -
Page 31: Configuring Via Pc
Configuring via PC All device configurations can be implemented via PC and ViP Manager configuration software, which is available to download free of charge from the website pro.comelitgroup.com (See programming manual) For example: • programming the user codes associated with the buttons •... -
Page 32: System Functions
System functions 1216 1214/2C 6701W 6721W 6601W 6801W 6741W 6701W/8 (MAX 1) (MAX 4) 4888C UT1020 1595 1216 1214/2C 6801W 6601W 6701W 6721W 6701W/8 6741W 4888C 4888C 4834/9 4833C 1200 UT1020 UT1020 1595 1212/B 1212/B 6801W 6801W 6601W 6801W/BM 6801W/BM 6601W/BM... -
Page 33: Operating Distances
A MAX B MAX C MAX D MAX E MAX F MAX G MAX H MAX I MAX Art.1216 Comelit Art. 4577/4579 1 mm² 200 m 200 m 200 m 200 m 150 m 50 m 50 m 100 m (Ø 1.2 mm AWG 17) -
Page 34: Maximum System Expansion
Maximum system expansion Devices 6801W(/BM) 6701W(/BM) 6601W(/BM) 6721W(/BM) 6741W(/BM) 6701W/8 (4888C with IR Maximum number of door ≥053) entry monitors that can be powered from art. 4888C (4888C with IR ≥021 ≤052 ) Call repetition devices that can 1229A 1229A 1229A 1229A 1229A... -
Page 35: Wiring Diagrams
Wiring diagrams 1216 6801W 6801W/BM 1214/2C 1214/2C 2738W 2738W/A 6750W 1214/2C 1 2 3 4 5 6 6741W 6721W 6701W 1214/2C 6721W/BM 6741W/BM 6701W/8 6601W 6601W/BM 1214/2C 4888C 230V 1595 120-230 V 12 VAC/VDC 18 Ω MAX NO NC UT1020 UT9200 Max 20 m. -
Page 36: System Performance And Layouts
4888C 4888C 230V 230V 1224A 1224A 1595 1595 120-230 V 120-230 V 12 VAC/VDC 12 VAC/VDC 18 Ω MAX 18 Ω MAX NO NC NO NC UT1020 UT9200 UT1020 UT9200 1595 4834/9 120-230 V 12 VAC/VDC 18 Ω MAX NO NC UT1020 UT9200 1595... -
Page 37: Table Of User Codes
