6 Technical data
6.2

Wiring diagram

6.2.1

Wiring diagram: Outdoor unit

Refer to the wiring diagram sticker on the unit. The abbreviations
used are listed below:
INFORMATION
The wiring diagram on the outdoor unit is only for the
outdoor unit. For the indoor unit or optional electrical
components, refer to the wiring diagram of the indoor unit.
1 This wiring diagram applies only to the outdoor unit.
2 Symbols (see below).
3 When using the optional adapter, refer to the installation
manual of the optional adapter
4 For connection wiring to indoor–outdoor transmission F1‑F2,
outdoor‑outdoor transmission F1‑F2, outdoor‑multi
transmission Q1‑Q2, refer to the installation manual.
5 How to use BS1~BS3 switch, refer to the "Service
Precaution" label on the electrical component box cover.
6 When operating, do NOT short-circuit the protection devices
(S1PH).
7 Only for RYYQ model
8 Only for RYYQ/RYMQ model
9 For 8~12 HP: Connector X1A (M1F) is white, connector X2A
(M2F) is red.
9 For 14~20 HP: Colours (see below).
10 Colours (see below).
Symbols:
Field wiring
Terminal block
Connector
Terminal
Protective earth
Noiseless earth
Earth wiring
Field supply
PCB
Switch box
Option
Colours:
BLK Black
RED Red
BLU Blue
WHT White
GRN Green
Legend for wiring diagram 8~12 HP:
A1P Printed circuit board (main)
A2P Printed circuit board (noise filter)
A3P Printed circuit board (inverter)
A4P Printed circuit board (fan)
A5P Printed circuit board (ABC I/P) (option)
BS1~BS3 Push button switch (MODE, SET, RETURN)
(A1P)
C* (A3P) Capacitor
Service manual
146
https://daikin-p.ru/catalog/vrv-daikn/naruzhnye-vrv-bloki-daikin
DS1, DS2 DIP switch
(A1P)
E1HC Crankcase heater
E3H Drain pan heater (option)
F1U, F2U Fuse (T 3.15 A / 250 V)
(A1P)
F3U Field fuse
F101U Fuse
(A4P)
F401U, Fuse
F403U
(A2P)
F601U, Fuse
(A3P)
HAP (A*P) Pilot lamp (service monitor is green)
K3R (A3P) Magnetic relay
K4R (A1P) Magnetic relay (Y1S)
K5R (A1P) Magnetic relay (Y2S)
K6R (A1P) Magnetic relay (E3H)
K7R (A1P) Magnetic relay (E1HC)
K9R (A1P) Magnetic relay (Y3S)
K11R (A1P) Magnetic relay (Y5S)
L1R Reactor
M1C Motor (compressor)
M1F Motor (fan)
PS (A1P, Switching power supply
A3P)
Q1DI Earth leakage circuit breaker (field supply)
Q1LD (A1P) Earth current detector (field supply)
R24 (A4P) Resistor (current sensor)
R300 (A3P) Resistor (current sensor)
R1T Thermistor (air)
R3T Thermistor (accumulator)
R4T Thermistor (heat exchanger, liquid pipe)
R5T Thermistor (subcool liquid pipe)
R6T Thermistor (heat exchanger, gas pipe)
R7T Thermistor (heat exchanger, de-icer)
R8T Thermistor (M1C body)
R21T Thermistor (M1C discharge)
S1NPH Pressure sensor (high)
S1NPL Pressure sensor (low)
S1PH Pressure switch (discharge)
SEG1~SEG 7-segment display
3 (A1P)
T1A Current sensor
V1D (A3P) Diode
V1R (A3P, Power module
A4P)
X*A Connector
X1M (A1P) Terminal block (control)
X1M (A5P) Terminal block (power supply)(option)
Y1E Electronic expansion valve (main)
Y2E Electronic expansion valve (sub‑cool)
Y3E Electronic expansion valve (liquid cooling)
RYYQ+RYMQ+RXYQ8~20U7Y1B
VRV IV+ Heat Pump
ESIE18-14 – 2019.07
