2.5.1
Antenna Ports
The RUGGEDCOM RX1400 features the following antenna ports:
1
2
3
4
5
Figure 2.6
2.5.2
Available Antennas
The RUGGEDCOM RX1400 supports the following antennas.
Cellular, GPS and WLAN Antennas
Antenna
Type
ANT1995-4MM
Omni-
Directional
RUGGEDCOM RX1400
Installation Manual, 01/2021, C79000-G8976-1103-17
ANT1 Port
ANT2 Port
ANT3 Port
ANT4 Port
ANT5 Port
Antenna Ports
Operating
Gain (dBi)
Frequency
(GHz)
2.4
2.5
5.0
0.7 to 1.0
3.0 to 4.0
1.7 to 2.7
ANT1
ANT2
1
ANT3
ANT4
2
ANT5
3
4
5
Article Number
6GK6000-8NS01-1AA0
Installing the Device
2.5.1 Antenna Ports
Port
Type
SMA
SMA
RP/SMA
RP/SMA
SMA
Reference
https://
support.industry.siemens.com/
cs/ww/en/view/109748485
Function
LTE SISO
GPS
WLAN SISO
WLAN MIMO
LTE MIMO
