Figure 1.1
Product Label
POWER LED
ALARM LED
CELL LED
Port Status LEDs
Access Plate
RS232 Serial Console Port
ANT Ports
Failsafe Alarm Relay
Power Supply Terminal Block
RUGGEDCOM RX1400
Installation Manual, 01/2021, C79000-G8976-1103-17
Power Supply Terminal Block
RS232 Serial Console Port (DB9)
ANT5 Port
POWER LED
ALARM LED
CELL LED
RUGGEDCOM RX1400
The product label details the product name, barcode, standards
compliance, etc. It also defines the article number, which describes
the hardware configuration.
For more information about how to interpret the article number,
refer to "Article Number (Page
Illuminates when power is being supplied to the device.
Illuminates when an alarm condition exists.
Indicates when the cellular modem is connected to the network.
• Solid = Activity
• Off = No activity
Indicate the status of each port:
State
Solid
Blinking
Off
The removable access plate provides access to the Micro SD card
and SIM card slots.
• Use a Micro SD card to store the firmware and configuration for
the device
• Use a single or dual (recommended) SIM cards to connect to an
LTE network
The serial console port is for interfacing directly with the device
and accessing initial management functions. For information
about connecting to the device via the serial console port, refer to
"Connecting to the Device (Page
SMA ports for connecting to an LTE network or Global Navigation
Satellite System (GNSS). For more information, refer to:
• "Connecting the Antennas (Page 16)"
• "Cellular Modem Specifications (Page 40)"
Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
• "Connecting the Failsafe Alarm Relay (Page 24)"
• "Failsafe Alarm Relay Specifications (Page 39)"
A pluggable terminal block. For more information, refer to:
• "Connecting Power (Page 25)"
• "Power Supply Specifications (Page 39)"
Introduction
1.2 Description
4)".
Description
Link established
Link activity
No link/activity
29)".
