Device Management
3.4 Inserting/Removing the MicroSD Card
Security hazard – risk of unauthorized access and/or exploitation
Make sure to remove the microSD card before decommissioning the device or
sending the device to a third-party.
To insert or remove a microSD card, do the following:
1.
2.
3.
4.
5.
6.
32
NOTICE
Power down the device.
Disconnect all network, alarm and console cables.
Unscrew the retention screw and remove the access plate.
1
MicroSD Card
1
Access Plate
2
Figure 3.3
Inserting/Removing a MicroSD Card
Without touching the contacts on the card, insert or remove the microSD card.
Install the access plate and finger-tighten the retention screw.
Power up the device.
2
RUGGEDCOM RX1400
Installation Manual, 01/2021, C79000-G8976-1103-17
