GPS Standalone Antenna Requirements
Polarization
Receive Frequency
Power Supply
DC Current
Antenna Gain
Total Gain at PTP GPS Input (includes antenna
gain, cable loss, lightning arrestor loss, line
amplifier gain and filter loss)
Axial Ratio
Output VSWR
5.7
Operating Environment
The RUGGEDCOM RSG2288 is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
Ambient Storage
Temperature
Ambient Relative
Humidity
Maximum Altitude
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Operating temperature may vary based on the limitations of installed SFPs. Refer to the RUGGEDCOM
SFP Transceivers Catalog for SFP temperature ratings.
c
Non-condensing
5.8
Mechanical Specifications
Weight
Ingress Protection
Enclosure
5.9
Dimension Drawings
Note
All dimensions are in millimeters, unless otherwise stated.
RUGGEDCOM RSG2288
Installation Manual, 04/2021, C79000-G8976-1045-17
Characteristic
-40 to 85°C (-40 to 185 °F)
a b
-40 to 85°C (-40 to 185 °F)
5% to 95%
c
2000 m (6562 ft)
4.8 kg (10.6 lbs)
IP30
18 AWG Galvanized Steel
Technical Specifications
5.7 Operating Environment
Active Antenna
RHCP (Right-Hand Circular Polarized)
1.57542 GHz ± 1.023 MHz
5 VDC
< 10 mA at 3 VDC
Select antenna gain based on system
configuration
Total Gain≤ 18 dBi
< 3 dB
< 2.5
41
