  • Page 1 Edition 11/2022 Installation Manual SIMATIC NET Rugged Ethernet Switches RUGGEDCOM RS930L https://www.siemens.com/ruggedcom...
  • Page 2 Preface Introduction Installing the Device SIMATIC NET Device Management Rugged Ethernet Switches RUGGEDCOM RS930L Communication Ports Technical Specifications Installation Manual Certification 11/2022 C79000-G8976-1034-11...
  • Page 3 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
  • Page 4: Table Of Contents

    Accessing Documentation ....................... v Registered Trademarks ......................v Warranty ..........................vi Training ..........................vi Customer Support ........................vii Contacting Siemens ....................... vii Introduction ........................... 1 Feature Highlights ....................1 Description ......................2 Required Tools and Materials ................. 4 Decommissioning and Disposal ................4 Cabling Recommendations ..................
  • Page 5 Table of Contents Failsafe Alarm Relay Specifications ..............25 Supported Networking Standards ................ 25 Copper Ethernet Port Specifications ..............26 Operating Environment ..................26 Mechanical Specifications ..................26 Dimension Drawings ................... 27 Certification ......................... 29 Approvals ......................29 6.1.1 CSA ........................29 6.1.2 European Union (EU) ..................
  • Page 6: Preface

    SIMATIC NET Glossary The SIMATIC NET Glossary describes special terms that may be used in this document. The glossary is available online via Siemens Industry Online Support (SIOS) at: https://support.industry.siemens.com/cs/ww/en/view/50305045 Accessing Documentation The latest user documentation for RUGGEDCOM RS930L is available online at https:// support.industry.siemens.com.
  • Page 7: Warranty

    Warranty Siemens warrants this product for a period of five (5) years from the date of purchase, conditional upon the return to factory for maintenance during the warranty term. This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void.
  • Page 8: Customer Support

    Call a local hotline center to submit a Support Request (SR). To locate a local hotline center, visit https://w3.siemens.com/aspa_app/?lang=en. Mobile App Install the Industry Online Support app by Siemens AG on any Android, Apple iOS or Windows mobile device and be able to: •...
  • Page 9 Preface Contacting Siemens viii RUGGEDCOM RS930L Installation Manual, 11/2022, C79000-G8976-1034-11...
  • Page 10: Introduction

    Introduction The RUGGEDCOM RS930L is an 6-port utility-grade, fully managed Ethernet switch with Ethernet over VDSL (EoVDSL) capabilitiies, designed to operate reliably in electrically harsh and climatically demanding environments. EoVDSL supports LAN segments of up to 5 km (3.1 mi) over telephone grade cable (or other legacy serial cabling) at up to 35 Mbps (upstream and downstream).
  • Page 11: Description

    Introduction 1.2 Description • Asymmetric data rates up to 40 Mbps • Automatically selects fastest data rate based on distance and quality of cable • Software selectable to be master or slave • Frequency Division Multiplexing (FDM) Rated for Reliability in Harsh Environments •...
  • Page 12 Introduction 1.2 Description POWER LED ALARM LED EoVDSL Ports Copper (10/100Base-TX) Ethernet Ports RS232 Console Port (Serial) Failsafe Alarm Relay Chassis Ground Connection Power Supply Terminal Block Figure 1.1 RUGGEDCOM RS930L POWER LED Illuminates green during boot up and when power is supplied to the device.
  • Page 13: Required Tools And Materials

    Siemens also does not recommend using copper Ethernet ports to interface with devices in the field across distances that could produce high levels of ground potential rise (i.e. greater than 2500 V), during line-to-ground fault conditions.
  • Page 14: Installing The Device

    This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void. Changes or modifications not expressly approved by Siemens Canada Ltd. could invalidate specifications, test results, and agency approvals, and void the user's authority to operate the equipment.
  • Page 15: General Procedure

    Visually inspect each item in the package for any physical damage. Verify all items are included. Note If any item is missing or damaged, contact Siemens for assistance. Mounting the Device The RUGGEDCOM RS930L is designed for maximum mounting and display flexibility.
  • Page 16: Mounting The Device On A Din Rail

    Installing the Device 2.3.1 Mounting the Device on a DIN Rail Note For detailed dimensions of the device with either DIN rail or panel hardware installed, refer to "Dimension Drawings" (Page 27). 2.3.1 Mounting the Device on a DIN Rail The RUGGEDCOM RS930L can be ordered with a DIN rail adapter preinstalled on the back of the chassis.
  • Page 17: 2.3.2 Mounting The Device To A Panel

    Installing the Device 2.3.2 Mounting the Device to a Panel Push the device against the bottom of the DIN rail, then let go of the sliding release to latch the device. Removing the Device To remove the device from a DIN rail, do the following: Insert a flathead screwdriver into the slot of the sliding release and move it down.
  • Page 18: Connecting The Failsafe Alarm Relay

    Installing the Device 2.4 Connecting the Failsafe Alarm Relay Screw (M3.5 or #6-32) Panel Mount Adapter Figure 2.3 Panel Mounting Secure the adapters to the panel with M3.5 or #6-32 screws. Connecting the Failsafe Alarm Relay The failsafe relay can be configured to latch based on alarm conditions. The NO (Normally Open) contact is closed when the unit is powered and there are no active alarms.
  • Page 19: Connecting Power

    Installing the Device 2.5 Connecting Power Normally Closed Common Normally Open Figure 2.4 Failsafe Alarm Relay Wiring Connecting Power The RUGGEDCOM RS930L supports power input from a single high AC/DC or low DC power supply. Note • For 110/230 VAC rated equipment, an appropriately rated AC circuit breaker must be installed.
  • Page 20: Connecting High Ac/Dc Power

    Installing the Device 2.5.1 Connecting High AC/DC Power 2.5.1 Connecting High AC/DC Power To connect a high AC/DC power supply to the device, do the following: NOTICE Electrical hazard – risk of damage to equipment Do not connect AC power cables to terminals for DC power. Damage to the power supply may occur.
  • Page 21: 2.5.2 Connecting Low Dc Power

    Installing the Device 2.5.2 Connecting Low DC Power Braided Ground Cable Figure 2.5 Terminal Block Wiring ± ± ± ± Positive Terminal Negative Terminal Surge Ground Terminal Braided Ground Cable Figure 2.6 Terminal Block Wiring – Dual DC Power Supply Inputs Connect the negative wire from the power source to the negative/neutral (-/N) terminal on the terminal block.
  • Page 22 Installing the Device 2.5.2 Connecting Low DC Power Connect the positive wire from the power source to the positive terminal on the terminal block. ± ± Positive Terminal Negative Terminal Surge Ground Terminal Braided Ground Cable Figure 2.7 Terminal Block Wiring – Single DC Power Supply Inputs Connect the negative wire from the power source to the negative terminal on the terminal block.
  • Page 23 Installing the Device 2.5.2 Connecting Low DC Power ± ± ± ± Positive Terminal Negative Terminal Surge Ground Terminal Braided Ground Cable Figure 2.8 Terminal Block Wiring – Dual DC Power Supply Inputs Using a braided wire or other appropriate grounding wire, connect the surge ground terminal to the chassis ground connection.
  • Page 24: Device Management

    Device Management This section describes how to connect to and manage the device. Connecting to the Device The following describes the various methods for accessing the RUGGEDCOM RS930L console and Web interfaces on the device. For more detailed instructions, refer to the "RUGGEDCOM ROS Configuration Manual"...
  • Page 25: Configuring The Device

    Device Management 3.2 Configuring the Device The serial console port implements RS232 DCE (Data Communication Equipment) on a DB9 connector. The following is the pin-out for the port:   Name Description Reserved (Do Not Connect) Transmit Data Receive Data Reserved (Do Not Connect) Signal Ground Reserved (Do Not Connect) Reserved (Do Not Connect)
  • Page 26: Communication Ports

    Communication Ports The RUGGEDCOM RS930L can be equipped with various types of communication ports to enhance its abilities and performance. Ports 1 to 6 Port 7 Port 9 Figure 4.1 Port Assignment Port Type 1 to 6 Copper Ethernet Ports (10/100Base-TX) 7 and 9 EoVDSL Ports Copper Ethernet Ports...
  • Page 27 Communication Ports 4.1 Copper Ethernet Ports WARNING Electric shock hazard – risk of serious personal injury and/or equipment interference When shielded cables are used, make sure the shielded cables do not form a ground loop via the shield wire and the RJ45 receptacles at either end. Ground loops can cause excessive noise and interference, but more importantly, create a potential shock hazard that can result in serious injury.
  • Page 28: Eovdsl Ports

    EoVDSL line configuration settings are modified on the Master and pushed to the Slave. Data flowing from the Master to the Slave is designated downstream, while data flowing from the Slave to the Master is designated upstream. Siemens supports two types of EoVDSL: • Universal EoVDSL Universal EoVDSL ports are Master/Slave selectable and offer symmetric data rates (upstream and downstream) up to 35 Mbps.
  • Page 29: Eovdsl Wiring

    Communication Ports 4.2.1 EoVDSL Wiring LEDs Each EoVDSL port has a Link/Act LED and a Master LED. On devices with Universal EoVDSL ports, the Master LED can be toggled on or off depending on whether the port is set to be a Master or Slave. On devices with Long-Reach EoVDSL ports, the Master LED will be on all the time if the device is set to be the Master, or off if the device is set to be the Slave.
  • Page 30: 4.2.2 Configuration And Setup

    Communication Ports 4.2.2 Configuration and Setup • Twisted-pairs are an effective way of reducing both magnetic and capacitive interference, as they reduce the magnetic loop area to nearly zero and maintain a consistent distribution of capacitances to both ground and other sources. Therefore, make sure twisting is consistent throughout the cable length.
  • Page 31 Communication Ports 4.2.3 EoVDSL Performance If the line conditions degrade (reducing the SNR or Signal to Noise Ratio), but the device is able to maintain the link, an alarm will be triggered to notify the user of the reduced SNR. By configuring the Rescan Mode parameter in RUGGEDCOM RS930L, the user can control at which point the scan process will be restarted when the line conditions degrade.
  • Page 32 Communication Ports 4.2.3 EoVDSL Performance Distance (km) Distance (ft) Downstream (Master Upstream (Slave to Slave) (Mbps) to Master) (Mbps) 2.00 6600 0.54 2.50 8200 0.54 3.20 10500 0.54 4.00 13100 0.54 4.60 15100 0.54 5.00 16400 0.48 0.18 RUGGEDCOM RS930L Installation Manual, 11/2022, C79000-G8976-1034-11...
  • Page 33 Communication Ports 4.2.3 EoVDSL Performance RUGGEDCOM RS930L Installation Manual, 11/2022, C79000-G8976-1034-11...
  • Page 34: Technical Specifications

    Technical Specifications This section provides important technical specifications related to the device. Power Supply Specifications Note When determining cable lengths, make sure the nominal input voltage for the power supply is provided at the power source. Power Input Voltage Internal Isolation Maximum Power Supply Type...
  • Page 35: Copper Ethernet Port Specifications

    Technical Specifications 5.4 Copper Ethernet Port Specifications Standard 10 Mbps 100 Mbps 1000 Mbps Ports Notes Ports Ports IEEE 802.3z     1000Base-LX Ÿ IEEE 802.3ab     1000Base-Tx Ÿ IEEE 802.1D MAC Bridges Ÿ Ÿ Ÿ IEEE 802.1Q VLAN (Virtual LAN) Ÿ...
  • Page 36: Dimension Drawings

    Technical Specifications 5.7 Dimension Drawings Enclosure 20 AWG Galvanized Steel Dimension Drawings Note All dimensions are in millimeters, unless otherwise stated. 65.3 116.59 7.87 Figure 5.1 Overall Dimensions RUGGEDCOM RS930L Installation Manual, 11/2022, C79000-G8976-1034-11...
  • Page 37 Technical Specifications 5.7 Dimension Drawings 13.64 101.6 11.2 78.74 120.65 Figure 5.2 Panel and DIN Rail Mount Dimensions RUGGEDCOM RS930L Installation Manual, 11/2022, C79000-G8976-1034-11...
  • Page 38: Certification

    Approvals This section details the standards to which the RUGGEDCOM RS930L complies. Note All relevant certificates and test reports are available on Siemens Industry Online Support [https://support.industry.siemens.com]. 6.1.1 This device meets the requirements of the following Canadian and U.S. standards under certificate 1550963: •...
  • Page 39: European Union (Eu)

    Certification 6.1.2 European Union (EU) 6.1.2 European Union (EU) This device is declared by Siemens Canada Ltd. to comply with essential requirements and other relevant provisions of the following EU directives: • EN 62368-1 Information Technology Equipment – Safety – Part 1: General Requirements •...
  • Page 40: Fda/Cdrh

    Title 21 Code of Federal Regulations (CFR) – Chapter I – Sub-chapter J – Radiological Health 6.1.5 ISED This device is declared by Siemens Canada Ltd. to meet the requirements of the following ISED (Innovation Science and Economic Development Canada) standard: • CAN ICES-3 (A)/NMB-3 (A) 6.1.6...
  • Page 41: 6.1.9 Rohs

    Support at https://support.industry.siemens.com/cs/ww/en/view/89855782. 6.1.9 RoHS This device is declared by Siemens Canada Ltd. to meet the requirements of the following RoHS (Restriction of Hazardous Substances) directives for the restricted use of certain hazardous substances in electrical and electronic equipment: China RoHS 2 •...
  • Page 42 Certification 6.2 EMC and Environmental Type Tests EMC Type Tests Test Description Test Levels Severity Levels Enclosure ± 8 kV 61000-4-2 Contact Enclosure Air ± 15 kV Radiated RFI Enclosure 20 V/m 61000-4-3 Ports Burst (Fast Transient) Signal Ports ± 4 kV @ 2.5 kHz 61000-4-4 DC Power ±...
  • Page 43 Certification 6.2 EMC and Environmental Type Tests Test Description Test Levels Severity Levels DC Power 30 V Continuous Ports 300 V for 1 s Ripple on DC Power Supply DC Power 61000-4-17 Ports Voltage Dips and Interrupts DC Power 30% for 0.1 s  ...
  • Page 44 Certification 6.2 EMC and Environmental Type Tests Description Test Levels DC Power Ports 2 kV AC Power Ports 2 kV Environmental Type Tests Test Description Test Levels Severity Levels IEC 60068-2-1 Cold Temperature Test Ad -40 °C (-40   °F), 16 Hours IEC 60068-2-2 Dry Heat Test Bd...
  • Page 45 Certification 6.2 EMC and Environmental Type Tests RUGGEDCOM RS930L Installation Manual, 11/2022, C79000-G8976-1034-11...
  • Page 46 For more information Siemens RUGGEDCOM https://www.siemens.com/ruggedcom Industry Online Support (service and support) https://support.industry.siemens.com Industry Mall https://mall.industry.siemens.com Siemens Canada Ltd. Digital Industries Process Automation 300 Applewood Crescent Concord, Ontario, L4K 4E5 Canada © 2022 Siemens Canada Ltd. Subject to change...
