Sony DSC-F717 Operating Instructions (primary manual) Operating Instructions Manual page 117

Built-in microphone
Electret condenser microphone
Built-in speaker
Dynamic speaker
AC-L10A/L10B AC power
adaptor
Power requirements
100 to 240 V AC, 50/60 Hz
Rated output voltage
DC 8.4 V, 1.5 A in operating mode
Operating temperature
0°C to 40°C (32°F to 104°F)
Storage temperature
–20°C to +60°C (–4°F to +140°F)
Dimensions
Approx. 125×39×62 mm
(5×1 9/16×2 1/2 inches) (w/h/d,
excluding maximum protrusions)
Mass
Approx. 280 g (10 oz)
NP-FM50 battery pack
Used battery
Lithium-ion battery
Maximum voltage
DC 8.4 V
Nominal voltage
DC 7.2 V
Capacity 8.5 Wh (1 180 mAh)
Operating temperature
0°C to 40°C (32°F to 104°F)
Dimensions
Approx. 38.2×20.5×55.6 mm
(1 9/16×13/16×2 1/4 inches) (w/h/d)
Mass Approx. 76 g (3 oz)
Accessories
• AC-L10A/L10B AC power adaptor
• Power cord (mains lead)
• USB cable
• NP-FM50 battery pack
• A/V connecting cable
• "Memory Stick" (32 MB)
• Shoulder strap
• Lens cap
• Lens cap strap
• CD-ROM (USB driver SPVD-008)
• Operating instructions
Design and specifications are subject to change
without notice.
117
