- Page 1 HAFFMANS HAFFMANS INSTRUCTION MANUAL INPACK 2000 CO METER DIGITAL TYPE ICD W W W.HAFFMANS.NL W W W.HAFFMANS.NL...
- Page 3 Serial number: from ICM-3146 Essential reading! Haffmans BV is not responsible for any damage caused by the owner’s failure to follow the instructions given in this manual. Haffmans BV is not responsible for print or translation errors in this edition of the manual. The specifications and design of this product are subject of change without notice.
-
Page 5: Table Of Contents
HAFFMANS ICD TABLE OF CONTENTS Technical specifications....................7 Inpack CO Meter....................7 Inpack Air Meter ....................7 Introduction ........................9 Intended use ......................9 Safety ..........................11 Symbols ......................11 Safety instructions....................11 General product information..................13 General description ..................... 13 Measuring principle ICM-2000 ................ - Page 6 HAFFMANS ICD Page 6 of 43...
-
Page 7: Technical Specifications
HAFFMANS ICD TECHNICAL SPECIFICATIONS Inpack CO Meter Measuring range :Manometer :-1 - 4 (pressure) :-1 - 6 on request Measuring accuracy :Manometer : DIN class 1.0 (1% of measuring range) Bottle/can height :Minimum :50 mm :Maximum :360 Bottle/can diameter :Maximum outside :120 mm diameter... - Page 8 HAFFMANS ICD Page 8 of 43...
-
Page 9: Introduction
HAFFMANS ICD INTRODUCTION Intended use The Inpack 2000 CO Meter* is intended exclusively to measure gas equilibrium pressure and liquid temperature in filled bottles or cans for determination of the CO content. The ICM-2000 can be used in combination with the Inpack Air Meter**. The Air Meter is intended exclusively for the measuring of the air content in filled bottles or cans in combination with the ICM-2000. - Page 10 HAFFMANS ICD Page 10 of 43...
-
Page 11: Safety
HAFFMANS ICD SAFETY Symbols Attention, warning and danger symbols used in this manual have the following significance. Attention! Information for correct or effective use of the equipment. Warning Incorrect or careless use can cause serious damage to the equipment. Failure to observe this information can result in major personal injury or loss of life. - Page 12 HAFFMANS ICD Page 12 of 43...
-
Page 13: General Product Information
HAFFMANS ICD GENERAL PRODUCT INFORMATION General description The ICM-2000 is an instrument for measuring the gas equilibrium pressure and liquid temperature in filled bottles or cans. After measuring the temperature the CO content (based on the two measured values) can be determined with the Haffmans CO scale, The ICM-2000 can be used in laboratories or other locations where measurement of the CO content in filled bottles or cans is desired. -
Page 14: Measurement Methods
HAFFMANS ICD Measurement methods Before using the ICM-2000, the desired measurement results must be determined so that a measurement method can be selected. The number of choices is determined by the presence or absence of an IAM. 4.5.1 ICM-2000 without IAM Measuring methods: Measuring CO without headspace air correction... -
Page 15: Installation
HAFFMANS ICD INSTALLATION Unpacking Before despatch the ICM-2000 was checked and tested by Haffmans BV Make sure that the content of the delivery is complete and undamaged. If the delivery is incomplete or damaged, please contact Haffmans BV or the representative/agent designated by Haffmans B.V, immediately (appendix III). - Page 16 HAFFMANS ICD Page 16 of 43...
-
Page 17: Operating The Co Meter
HAFFMANS ICD OPERATING THE CO METER This paragraph described the operation of the ICM-2000. Many actions may be carried out depending on the desired measurement results. See the diagram in appendix VII. Operation of the ICM-2000 has the following steps: 1. - Page 18 HAFFMANS ICD 4. Piercing the bottle or can. Check glass bottles beforehand for any cracks or breaks. Use undamaged bottles only. Before the bottle is pierced, it must be protected using the protective sleeve provided. Method: 1. Close the needle valve (pos. 8). 2.
-
Page 19: Operating The Air Meter
HAFFMANS ICD OPERATING THE AIR METER Always wear protective gloves and goggles. Lye may cause serious damage if it comes into contact with your skin or eyes. Remove lye immediately using a large quantity of flowing water. Contact a doctor immediately. Warning Used lye should be disposed of according to the national legal environmental and health regulations. -
Page 20: Uses Of The Iam
HAFFMANS ICD There will now still be air in the hose between the IAM and the ICM-2000: This can be removed in three ways: • Open the ICM-2000’s needle valve slowly until a drop of lye comes out of the needle. This will happen more quickly if the IAM is placed slightly higher than ICM-2000. - Page 21 HAFFMANS ICD 7.2.2 Determining the air content in the head gas Read the general method and follow the instructions below for the following uses. 1. Checking the filling unit => Do not shake the bottle or can. Close the needle valve in time to prevent the lye from entering the bottle or can.
- Page 22 HAFFMANS ICD Page 22 of 43...
-
Page 23: Calibration
HAFFMANS ICD CALIBRATION This chapter provides information on calibration for the ICM-2000. Check the manometer every month. Compare the ICM-2000's manometer with a precision manometer with an accuracy of +/- 0.03 bar. Attention! The Haffmans Gauge Calibration Device (GCD) is recommended for proper calibration. - Page 24 HAFFMANS ICD Page 24 of 43...
-
Page 25: Maintenance And Cleaning
HAFFMANS ICD MAINTENANCE AND CLEANING Attention! For optimal maintenance of ICM-2000 the Inpack 2000 Service set is recommended. ICM-2000 maintenance (semi-annual) Method of replacing the seals (needle valve and temperature sensor): 1. Unscrew the needle valve (pos. 8) from the instrument, 2. - Page 26 HAFFMANS ICD Page 26 of 43...
-
Page 27: Trouble Shooting
HAFFMANS ICD TROUBLE SHOOTING 10.1 Trouble shooting ICM-2000 Trouble Reason Solution Pressure drop Upper needle leakage. Replace O-ring (see paragraph 9.1). Piercing leak. Check rubber cone. PET Bottle is pressed together Use PET-bottle holder 005.218. Values measured remain unstable Manometer leak (pos. - Page 28 HAFFMANS ICD Page 28 of 43...
-
Page 29: Appendix I Haffmans Co -Formula
HAFFMANS ICD APPENDIX I HAFFMANS CO -FORMULA Attention! The partial pressure of foreign gases is not included in the calculation. ⎛ ⎞ ⎜ ⎜ ⎟ ⎟ ° × × ⎝ ⎠ weight = conversion factor/compensation factor (1*), = gas equilibrium pressure (partial), = atmospheric pressure in bar, = product-dependent factor (-10,74*), = product-dependent factor (2617,25*),... - Page 30 HAFFMANS ICD Page 30 of 43...
-
Page 31: Appendix Ii Customer Service
HAFFMANS ICD APPENDIX II CUSTOMER SERVICE The trouble shooting chart list a number of potential minor problems and indicates how the customer can solve these problems. If you can’t solve a problem or would like to order spare parts, contact Haffmans BV or their designated representative/agent. Always include the serial number, order number or invoice number (given by Haffmans BV) of the ICM-2000 in any correspondence. - Page 32 HAFFMANS ICD Page 32 of 43...
-
Page 33: Appendix Iii Terms Of Guarantee
HAFFMANS ICD APPENDIX III TERMS OF GUARANTEE This Haffmans guarantee is in addition to all the rights accruing to the buyer from the sales contract between buyer and supplier and the relevant legislation. Haffmans BV guarantees that the equipment supplied is free from material and manufacturing defects, for normal use and maintenance. - Page 34 HAFFMANS ICD Page 34 of 43...
-
Page 35: Appendix Iv Ec Declaration Of Conformity
HAFFMANS ICD APPENDIX IV EC DECLARATION OF CONFORMITY TRANSLATION OF THE ORIGINAL EC DECLARATION OF CONFORMITY EC DECLARATION OF CONFORMITY HAFFMANS B.V. Marinus Dammeweg 30 5928 PW Venlo, Holland declare entirely under our own responsibility, that the product METER, TYPE ICM INPACK-2000 upon this statement has reference to, is in conformity with the norms EN 12100-1 according to the demands of:... - Page 36 HAFFMANS ICD Page 36 of 43...
-
Page 37: Appendix V Spare Parts
HAFFMANS ICD APPENDIX V SPARE PARTS When you order spare parts please include all the following information with your order: • Serial number of the ICM-2000. • Position number (on the parts list below). • Description • Article Number. ICM-2000 INP-03-2061 Pos. - Page 38 HAFFMANS ICD Pos. Description Art. no. Cylinder. Pin 5m6 x 36 006.337 Spring rod 006.334 Axle for crankshaft 006.335 Crankshaft 004.935 Adjusting screw m. bi6kt 005.075 Adjusting screw m. bi6kt 006.336 Handle for crankshaft 006.333 Handle 006.338 Knob for handle 004.985 Bottom plate 006.329...
- Page 39 HAFFMANS ICD Pos. Description Art. no. • Seal 4,3 x 2,5 – 2 mm • Rubber 26 mm ICC/ICM M10 • O-ring 8 x 1,25 36624 • Silicon grease 5 gr. • O-ring 3,68 x 1,78 36624-007 INP-01-1324 Pos. Description Art.no.
- Page 40 HAFFMANS ICD Page 40 of 43...
-
Page 41: Appendix Vi Operation Overview
HAFFMANS ICD APPENDIX VI OPERATION OVERVIEW 2. Setting the ICC to the correct 1 Preparing the bottle or can. 3. Shaking the bottle or can to cause height. equilibrium. Heat to 25° C.Remove the foil from the Place the handle in the rear position. crown cap. - Page 42 HAFFMANS ICD Page 42 of 43...
-
Page 43: Appendix Vii Drawings
HAFFMANS ICD APPENDIX VII DRAWINGS Description Drawing number Composition ICM-2000 INP-03-2061 Composition IAM INP-03-1102 Page 43 of 43...
