Optional Modules
SZ-ADD
SZ-POL-2
INSTRUCTIONS
SZH-CLJ
SZ2-ILA
TRANSMITTED ILLUMINATION
ATTACHMENT
This instruction manual is for the Olympus SZ2-ILA Transmitted Illumination Attachment. To ensure
the safety, obtain optimum performance and to familiarize yourself fully with the use of this equip-
ment, we recommend that you study this manual thoroughly before operating the system.
Retain this instruction manual in an easily accessible place near the work desk for future reference.
A X 6 6 1 5
Advertisement
Table of Contents
Related Manuals for Olympus SZ-ADD
Summary of Contents for Olympus SZ-ADD
- Page 1 TRANSMITTED ILLUMINATION ATTACHMENT This instruction manual is for the Olympus SZ2-ILA Transmitted Illumination Attachment. To ensure the safety, obtain optimum performance and to familiarize yourself fully with the use of this equip- ment, we recommend that you study this manual thoroughly before operating the system.
-
Page 3: Table Of Contents
NOMENCLATURE TRANSMITTED LIGHT OBSERVATION Using the Mirror Rotation/Sliding Knob ................................ TROUBLESHOOTING GUIDE SPECIFICATIONS ASSEMBLY OPTIONAL MODULES 10-11 7-1 Darkfield Adapter SZ-ADD ..............................10 7-2 Simplified Polarization System SZ-POL-2 ......................11 7-3 Jewel Observation Clip SZH-CLJ............................ 11 LAMP HOUSING INSPECTION SHEET... -
Page 4: Important - Be Sure To Read This Section For Safe Use Of The Equipment
SZ2-LGB 12V22WHAL (PHILIPS JCR12V22WA/3), average life 100 hours 5. Always use the power cord provided by Olympus. If the proper power cord is not used, product safety performance cannot be warranted. 6. Always ensure that the grounding terminals are properly connected. If the equipment is not grounded, Olympus can no longer warrant the electrical safety performance of the equipment. - Page 5 SZ2-ILA Warnings Warning engravings are placed at parts where special precaution is required when handling and using the unit. Always heed the warnings. Warning engraving Lamp housing (High Temperature positions (U-LH100L-3) warning ) Getting Ready 1. The transmitted light illumination attachment is a precision instrument. Handle it with care and avoid subjecting it to sudden or severe impact.
-
Page 6: System Chart
SYSTEM CHART Lightguide Stage Glass Illuminator Power supply SP-C SZ2-LGB 100 W Halogen Lamp Housing 45 mm U-LH100L-3 frameless filter Filter holder Power supply Lamp Housing Adapter SZ2-LHAD Standard Stand Epi-Illuminator SZ2-ST LSGA Flexible Light Guide SZ2-LGSF Collector Lens SZ2-LGCL Transmitted Illumination Transmitted Light Guide Attachment... -
Page 7: Nomenclature
SZ2-ILA NOMENCLATURE Transmitted Illumination Attachment SZ2-ILA Stage glass Illuminator mount port Fresnel lens SP-C Mirror Planar mirror/Light scattering mirror Filter holder Mirror rotation/sliding knob Rotation: 360° Sliding: 30 mm Power Supply Power Supply For details, refer to the instruction manual. Main switch “... -
Page 8: Transmitted Light Observation
TRANSMITTED LIGHT OBSERVATION }If you have not assembled the transmitted illumination attachment yet, please read Chapter 6, “ASSEMBLY” (p. 8 to 9). Using the Mirror Rotation/Sliding Knob (Fig. 1) 1. Set the main switch of the power supply to “ I ” (ON) and adjust the brightness with the intensity control knob. -
Page 9: Troubleshooting Guide
Under certain conditions, performance of the unit may be adversely affected by factors other than defects. If problems occur, please review the following list and take remedial action as needed. If you cannot solve the problem after checking the entire list, please contact Olympus. Problem... -
Page 10: Specifications
Power consumption Max. 30 VA Max. 180 VA Other · Various stages applicable. · Darkfield Adapter (SZ-ADD) mountable. · Simplified Polarization System (SZ-POL-2) mountable. Operating environment · Indoor use · Altitude: Max. 2000 m · Ambient temperature: 5° to 40°C (41°F to 104°F) ·... -
Page 11: Assembly
The modules shown in the following figure are merely the typical examples. For other applicable modules that are not given below, please consult your Olympus representative or the latest catalogues. The detailed assembly procedure is given only for how to mount the halogen bulb. - Page 12 Attaching the Halogen Bulb (Figs. 2 to 4) With the U-LH100L-3 }The applicable lamp bulb model is the 12V100WHAL-L (PHILIPS 7724) halogen bulb. ² 1. Fully loosen the clamping screw @ at the top of the lamp housing using the Allen screwdriver provided with the microscope body. 2.
-
Page 13: Optional Modules
SZH-CLJ. Fig. 5 Operating Precautions # The SZ-ADD does not incorporate a light source. It can be used only in combination with the transmitted illumination attachment. # The observation brightness depends on the brightness setting of the transmitted illumination attachment. -
Page 14: Simplified Polarization System Sz-Pol-2
7-2 Simplified Polarization System SZ-POL-2 Cross-Nicol Adjustment and Observation 1. Drop the polarizer below the stage glass so that the index dot ( · ) can be viewed horizontally. 2. Turn on the transmitted light source, look through the eyepieces and rotate the analyzer so that the field of view is darkest (cross-Nicol condition). -
Page 15: Lamp Housing Inspection Sheet
{If there is any ( ) mark noted, immediately stop use of the product, and contact Olympus for detailed inspections or replace the lamp housing. {If you detect an abnormality other than that listed below or with other Olympus product, also stop the use of the product and contact Olympus for detailed inspections. - Page 16 Manufactured by Shinjuku Monolith, 2-3-1 Nishi-Shinjuku, Shinjuku-ku, Tokyo 163-0914, Japan Distributed by (Biological) (Industrial) 8F Olympus Tower, 446 Bongeunsa-ro, Gangnam-gu, Seoul, Korea 135-509 AX6615 05...
