Front Panel Section - Sony STR-ZA1000ES Service Manual

STR-ZA1000ES/ZA2000ES/ZA3000ES
Ver. 1.1
7-4.

FRONT PANEL SECTION

• Rear view
(ZA1000ES)
151
(ZA2000ES/ZA3000ES)
151
Ref. No. Part No. Description
151 4-534-376-01 BUTTON, FUNCTION (BD/DVD, SAT/CATV,
GAME, STB, VIDEO, AUX, TV, SA-CD/CD, TUNER)
152 4-534-377-01 BUTTON, MODE
153 4-534-378-02 BUTTON, POWER
154 4-534-379-01 BUTTON, ENTER (DISPLAY, AMP MENU,
155 4-534-380-01 BUTTON, CURSOR (V, B, b, v)
96
152
154
155
152
157
158
152
154
155
152
Remark
RETURN, OPTIONS, ENTER, HOME)
156
not supplied
153
156
not supplied
153
Ref. No. Part No. Description
156 4-534-381-01 INDICATOR, POWER
157 4-544-973-01 COVER (HOLE) (ZA2000ES/ZA3000ES)
158 3-087-053-01 +BVTP2.6 (3CR) (ZA2000ES/ZA3000ES)
159 A-2058-792-A PANEL ASSY (ZA3000) (SERVICE) (ZA3000ES)
159 A-2058-793-A PANEL ASSY (ZA2000) (SERVICE) (ZA2000ES)
159 A-2067-029-A PANEL (ZA1000_SV) ASSY, FRONT (for SERVICE)
159
159
Remark
(ZA1000ES)
