- Page 1 3000 Digital Series User Manual Digital Wireless Systems ATW-DR3120 Dual Receiver ATW-DR3120DAN Dual Receiver with Dante Output ATW-DT3101 Body-Pack Transmitter ATW-DT3102 Handheld Transmitter (without capsule)
-
Page 2: Table Of Contents
Contents Introduction .................2 Setting the system-related functions ............25 Important information ..............2 How to attach the transmitter (ATW-DT3101) ......28 Notes on use ................4 Making connections (basic connections) ........28 Maintenance ................4 Making connections (cascade connections) ......29 Part names and functions ............5 Achieving stable reception ............30 ATW-DR3120/ATW-DR3120DAN .............. -
Page 3: Introduction
Introduction Thank you for purchasing this Audio-Technica product. Before using the product, read through this user manual to ensure that you will use the product correctly. Please keep this manual for future reference. The frequency band can be checked with the model number of the product. You can confirm the model number of your product with the rating label. - Page 4 Important information For customers in the USA/Canada CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Caution: To prevent electric shock, do not remove the cover. There are no user-serviceable parts inside. Internal adjustments are for qualified professionals only. Refer all servicing to qualified service personnel. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...
-
Page 5: Notes On Use
Notes on use • Be sure to read the user manual for any device that you connect to the product. • Disconnect the power cable from the outlet when this product is not in use. • Turn off the power of this product before connecting or disconnecting cables. •... -
Page 6: Part Names And Functions
Part names and functions ATW-DR3120/ATW-DR3120DAN Front panel ❶ ❷ ❸ ❹ ❺ ❻ ❼ ❸ ❹ ❺ ❻ ❼ ❶ Power button ( Use to turn the receiver on or to place it in standby. : This symbol indicates standby.) ❷... - Page 7 Part names and functions Rear panel The figure below is of the ATW-DR3120. ❶ ❷ ❷ ❶ ❸ ❹ ❹ ❸ ❺ ❻ ❼ ❶ Antenna input jack : This symbol indicates direct current.) Each jack supplies 12 VDC to a connected antenna. Additionally, other compatible antenna accessories (sold separately) can be connected.
-
Page 8: Atw-Dt3101
Part names and functions ATW-DT3101 ❶ ❺ ❷ ❹ ❸ ❽ ❻ ❾ ❿ ⓮ ❼ ⓫ ⓬ ⓯ ⓭ ❶ ❼ Transmission antenna SYNC button Use to IR SYNC with the receiver (ATW-DR3120, ATW- ❷ DR3120DAN). MUTE switch ❽ UP button Turns the mute function on/off. -
Page 9: Atw-Dt3102
Part names and functions ATW-DT3102 ❶ ❷ ❸ ❹ ❺ ❻ ❼ ❽ ❾ ❿ ⓫ ⓬ ⓭ ⓮ ❶ ❾ Interchangeable microphone capsule (sold separately) SYNC button ❷ Use to IR SYNC with the receiver (ATW-DR3120, ATW- Display DR3120DAN). ❿... -
Page 10: How To Insert Batteries
How to insert batteries ATW-DT3101 ATW-DT3102 Slide the battery cover latches. Rotate the grip case of the battery compartment. Open the battery cover. • Put your finger on the hook of the battery cover and pull it to open the battery cover. -
Page 11: How To Attach And Remove The Interchangeable Microphone Capsule (Only For The Atw-Dt3102)
How to attach and remove the interchangeable microphone capsule (only for the ATW-DT3102) How to attach Attach the microphone capsule to the body of the transmitter. Rotate the microphone capsule clockwise to tighten it. How to remove Rotate the microphone capsule counterclockwise to loosen it. Remove the microphone capsule from the body of the transmitter. -
Page 12: How To Read The Display
How to read the display ATW-DR3120/ATW-DR3120DAN Main screen ❶ ❷ ❸ ❹ ❺ ❻ VOCAL1 ⓬ 000.000 ⓫ AE S Gr 06 C h 12 ❼ ❽ ❾ ❿ ❶ ❼ Transmitter information display area Group indicator Information on the connected transmitter is displayed. Refer to ❽... - Page 13 How to read the display Level meter screen ❶ ❷ -76 dBm TX - RF PWR dBFS -50 -42 -36 -30 -24 -18 -15 -12 -9 -6 -3 0 +3 +6 +9 dBu ❸ ❹ ❺ ❻ ❶ ❹ RF transmission output indicator (transmitter) Audio output indicator (receiver) ❷...
-
Page 14: Atw-Dt3101/Atw-Dt3102
How to read the display ATW-DT3101/ATW-DT3102 The main screen is displayed when the power is switched on. If you press the UP/DOWN button on the main screen, the screen display is switched. ❷ ❶ ❾ ❿ ⓫ ❷ ❷ 000.000 VOCAL1 Gr 02 Ch 05 Inst... -
Page 15: How To Operate
How to operate Basic operation Using IR SYNC Turn on the main power switch of the receiver (ATW-DR3120/ This function allows you to set the transmitter with the details ATW-DR3120DAN). configured on the receiver. When IR SYNC is started as part of setting the receiver, the “Communication in standby”... -
Page 16: Settings
Settings Various settings can be made from the menu screen shown on the ATW-DT3101/ATW-DT3102 display. Press the SET button. • The menu screen appears. ATW-DR3120/ATW-DR3120DAN ATW-DT3101 ATW-DT3102 Press the control dial. • The menu screen appears. Turn the control dial to select the item you wish to set. VOCAL1 UTILITIES Press the UP/DOWN button to select the item you wish to set. -
Page 17: Setting The Atw-Dr3120/Atw-Dr3120Dan
Setting the ATW-DR3120/ATW-DR3120DAN List of setting items Setting the operating frequency FREQUENCY MANUAL Set the operating frequency. Setting manually Gr/Ch From the menu screen, turn the control dial, select NAME Set the channel name. [FREQUENCY], and then press the control dial. AUDIO LINE/MIC Set the line/microphone level. -
Page 18: Setting The Audio Output
Setting the ATW-DR3120/ATW-DR3120DAN Turn the control dial to select the preferred threshold. After Setting the audio output selecting the threshold, press the control dial. • You can select [Normal], [High], or [Low] sensitivity. Setting the Line/Mic level High: Prioritize the number of channels. From the menu screen, turn the control dial, select [AUDIO], and then press the control dial. -
Page 19: Setting The Security-Related Functions
Setting the ATW-DR3120/ATW-DR3120DAN Setting the security-related functions Setting the system-related functions Setting the PIN code Setting RF mode • The default setting is [Normal]. Set the 4-digit code used when communicating with the transmitter. It is only possible to communicate between a receiver and transmitter on From the menu screen, turn the control dial, select [UTILITIES], which the same PIN code has been set. - Page 20 Setting the ATW-DR3120/ATW-DR3120DAN Setting group/channel editing Setting the backup frequency mode Editing the group/channel If you set the backup frequency in advance, you can switch the frequency of the transmitter and receiver with the transmitter. It is The channels that compose the editable user groups (U1 and U2) can convenient to set this function when you want to switch the frequency be edited.
- Page 21 Setting the ATW-DR3120/ATW-DR3120DAN Setting the AF level meter on the main screen Resetting Switch the AF level meter on the main screen between [Receiver (Rx)] This returns the receiver settings to their factory defaults. and [Transmitter (Tx)]. From the menu screen, turn the control dial, select [UTILITIES], •...
-
Page 22: Setting The Network
Setting the ATW-DR3120/ATW-DR3120DAN Setting the network Setting the log message Set whether to send the log message to the Syslog server. By connecting the receiver and PC, you can use the dedicated app for monitoring or controlling with the PC. From the menu screen, turn the control dial, select [NETWORK], and then press the control dial. -
Page 23: Setting The Dante
Setting the ATW-DR3120/ATW-DR3120DAN Setting the MAC address From the menu screen, turn the control dial, select [NETWORK], and then press the control dial. Turn the control dial to select [MAC ADDRESS]. Setting the DANTE This setting is used only for the ATW-DR3120DAN. Displaying the device name and channel label From the menu screen, turn the control dial, select [DANTE], and then press the control dial. -
Page 24: Setting The Atw-Dt3101/Atw-Dt3102
Setting the ATW-DT3101/ATW-DT3102 List of setting items Setting by group/channel From the menu screen, press the UP/DOWN button to select FREQUENCY Manual Set the transmission frequency. [FREQUENCY], and then press the SET button. Gr/Ch FREQUENCY NAME Set the channel name. GAIN Adjust the microphone input gain. -
Page 25: Adjusting The Microphone Input Gain
Setting the ATW-DT3101/ATW-DT3102 Adjusting the microphone input gain Setting the RF transmission output From the menu screen, press the UP/DOWN button to select From the menu screen, press the UP/DOWN button to select [GAIN], and then press the SET button. [RF POWER], and then press the SET button. -
Page 26: Setting The Function For The Function Button
Setting the ATW-DT3101/ATW-DT3102 Press the UP/DOWN button to select [PIN], and then press the Setting the function for the function button SET button. Select the function to be performed when the function button is Press the UP/DOWN button to select the number you want to pressed and held. - Page 27 Setting the ATW-DT3101/ATW-DT3102 Setting the battery type Setting the user access level Set the type of batteries used. Set the user access level. • The default setting is [Free]. • The default setting is [Alkaline]. From the menu screen, press the UP/DOWN button to select From the menu screen, press the UP/DOWN button to select [UTILITIES], and then press the SET button.
- Page 28 Setting the ATW-DT3101/ATW-DT3102 Checking the version of the transmitter This function displays the version of the transmitter. From the menu screen, press the UP/DOWN button to select [UTILITIES], and then press the SET button. UTILITIES Press the UP/DOWN button to select [VERSION] and press the SET button.
-
Page 29: How To Attach The Transmitter (Atw-Dt3101)
How to attach the transmitter (ATW-DT3101) The ATW-DT3101 is equipped with a clip that can be used to attach the transmitter to a belt, etc. You can reverse the direction of the input connector by Pull both sides of the clip firmly to the outside to remove attaching the clip in the opposite direction. -
Page 30: Making Connections (Cascade Connections)
Making connections (cascade connections) Using the antenna output jack makes it possible to connect an additional 4 receivers (for a total of 5) in a cascade connection without using an antenna divider. • When cascading receivers, connect either the included whip antennas or external antennas to the main receiver’s antenna input jacks, and then cascade each receiver via BNC coaxial cables. -
Page 31: Achieving Stable Reception
Achieving stable reception Low RF signal may result if there are obstructions between receiver antennas and transmitter(s). In such a case, reposition the antennas to get better reception. Use external antennas (sold separately) if the installation space is limited. Rack-mounting the receiver •... -
Page 32: Troubleshooting
Troubleshooting ATW-DR3120/ATW-DR3120DAN Symptoms Causes and countermeasures Reference page The power can’t be turned on. Confirm that the power cable is correctly connected. There is no voice output. The voice output level is low. Confirm that the transmitter/receiver channels are correct. p. -
Page 33: Dimensions
Dimensions ATW-DR3120/ATW-DR3120DAN (Unit: mm) -
Page 34: Atw-Dt3101
Dimensions ATW-DT3101 (Unit: mm) ATW-DT3102 (Unit: mm) -
Page 35: Specifications
Specifications Overall system specifications Band DE2: 470.125 to 529.975 MHz Operating frequencies Band EE1: 530.000 to 589.975 MHz Band FF1: 606.000 to 665.975 MHz Minimum frequency step 125 kHz π /4-shift DQPSK Modulation mode Occupied bandwidth 192 kHz or lower ATW-DT3101 (Mic input): 120 dB or higher, A-weighted, typical Dynamic range ATW-DT3101 (Inst input): 108 dB or higher, A-weighted, typical ATW-DT3102: 120 dB or higher, A-weighted, typical... -
Page 36: Atw-Dt3102
Specifications ATW-DT3102 RF output power High: 20 mW, Mid: 10 mW, Low: 2 mW High-pass filter (low-freq. roll-off) 80 Hz, 120 Hz, 160 Hz, 12 dB/octave Power supply Two alkaline or nickel-metal hydride 1.5 V AA batteries Operating temperature range −5°C to +40°C (23°F to 104°F) When using nickel-metal hydride 1.5 V AA batteries: Approx. 7 hours (1900 mAh; High), approx. 9 hours (2500 mAh; High) Battery life When using alkaline 1.5 V AA batteries: Approx. - Page 37 Audio-Technica Corporation 2-46-1 Nishi-naruse, Machida, Tokyo 194-8666, Japan www.audio-technica.com ©2020 Audio-Technica Corporation Global Support Contact: www.at-globalsupport.com 232417010-02-01 Ver. 1 2020.08.15...
