- Page 1 3000 Series User Manual UHF Wireless Systems ATW-R3210 Receiver ATW-T3201 Body-Pack Transmitter ATW-T3202 Handheld Transmitter...
-
Page 2: Table Of Contents
Setting HPF (High-Pass Filter) ............... 21 Setting lock ....................21 Setting the function for the function button ..........21 Setting the mute mode (only for ATW-T3201) ..........22 Setting the system-related functions ............22 How to attach the transmitter (ATW-T3201) ......24 Making connections (basic connections) ........24... -
Page 3: Introduction
Introduction Thank you for purchasing this Audio-Technica product. Before using the product, read through this user manual to ensure that you will use the product correctly. Please keep this manual for future reference. Important information Warning: For customers in the USA •... -
Page 4: Notes On Use
Notes on use • Be sure to read the user manual for any microphone or cable that you attach to the product. • Disconnect the AC adapter from the outlet when this product is not in use. • Turn off the power of this product before connecting or disconnecting cables. •... -
Page 5: Part Names And Functions
❺ ❶ Power button ( Use to turn the receiver on or off. ❷ IR sync window Use to IR SYNC with the transmitter (ATW-T3201, ATW-T3202). ❸ Display Displays the receiver state and setting menus. ❹ BACK button Press to take the display back one screen. - Page 6 Part names and functions Rear panel ❻ ❶ ❷ ❸ ❹ ❺ ❶ Antenna input jack Each jack supplies DC12 V to a connected antenna. Additionally other compatible accessories (sold separately) can be connected. ❷ Unbalanced output terminal (6.3 mm mono jack) ❸...
-
Page 7: Atw-T3201
Part names and functions ATW-T3201 ❶ ❺ ❷ ❶ ❹ ❸ ❻ ❽ ❾ ❿ ⓮ ❼ ⓫ ⓬ ⓯ ⓭ ❶ ❼ Transmission antenna SYNC button Use to IR SYNC with the receiver (ATW-R3210). ❷ ❽ MUTE switch UP button Switches audio mute on and off. -
Page 8: Atw-T3202
Part names and functions ATW-T3202 ❶ ❷ ❸ ❹ ❺ ❻ ❼ ❽ ❾ ❿ ⓫ ⓬ ⓭ ⓮ ❶ ❾ Interchangeable microphone capsule SYNC button ❷ Use to IR SYNC with the receiver (ATW-R3210). Display ❿ Power switch Shows the current status. If no buttons are pressed for a period of 30 seconds, the display Use to turn the power on or off. -
Page 9: How To Insert Batteries
How to insert batteries ATW-T3201 ATW-T3202 Slide the battery cover latches down. Rotate the grip case of the battery compartment. Open the battery cover. • Put your finger on the hook of the battery cover and pull it to open the battery cover. -
Page 10: How To Attach And Detach The Interchangeable Microphone Capsule (Only For Atw-T3202)
How to attach and detach the interchangeable microphone capsule (only for ATW-T3202) How to attach Attach the microphone capsule to the body of the transmitter. Rotate the microphone capsule clockwise to tighten it. How to remove Rotate the microphone capsule counterclockwise to loosen it. Detach the microphone capsule from the body of the transmitter. -
Page 11: How To Read The Display
How to read the display ATW-R3210 Main screen ❶ ❷ ❸ ❹ ❺ ❻ VOCAL1 000.000 G 06 C 12 ❼ ❽ ❾ ❿ ⓫ ❶ ❼ Transmitter information display area Group indicator Information on the connected transmitter is displayed. Refer to ❽... - Page 12 How to read the display Level meter screen ❶ ❷ -74 dBm TX - RF PWR -40 -30 -24 -18 -15 -12 -10 -8 -6 -4 -2 0 +2 +4 +6 dBu ❸ ❹ ❺ ❻ ❶ ❹ RF transmission output indicator (transmitter) Audio output indicator (receiver) ❷...
-
Page 13: Atw-T3201/Atw-T3202
How to read the display ATW-T3201/ATW-T3202 The main screen is displayed when the power is switched on. If you press the UP/Down button on the main screen, the screen display is switched. ❶ ❻ ❼ ❽ 000.000 VOCAL1 02 Ch ❷... -
Page 14: How To Operate
• Communication function is in standby. Refer to "Using IR SYNC" (p. 25) for subsequent steps. Set the operating frequency. Turn on the power switch of the transmitter (ATW-T3201/ATW- T3202). • The indicator lights and the display shows the main screen. -
Page 15: Settings
• To cancel partway through making a setting, press the BACK button. • While on the settings screen, the display will return to the main screen if approximately 60 seconds pass without a button or the control dial being used. ATW-T3201/ATW-T3202 Press the SET button. • The menu screen appears. ATW-T3201 ATW-T3202 Press the UP/DOWN button to select the item you wish to set. -
Page 16: Setting Atw-R3210
Setting ATW-R3210 List of setting items Setting by group/channel From the menu screen, turn the control dial, select FREQUENCY MANUAL Set the operating frequency. [FREQUENCY] and then press the control dial. Gr/Ch NAME Set the channel name. AUDIO Set the audio output level. Select [Gr/Ch] and press the control dial. -
Page 17: Setting The Audio Output Level
Setting ATW-R3210 Setting the audio output level Setting transmitters via IR SYNC From the menu screen, turn the control dial, select [AUDIO] and This function allows you to make transmitter settings on the receiver then press the control dial. and then automatically configure the transmitter via IR SYNC. The following are the available settings and setting values: Turn the control dial to set the audio output level. -
Page 18: Setting The Squelch Level
Setting ATW-R3210 Setting the squelch level Setting the system-related functions Setting automatically Setting the lock From the menu screen, turn the control dial, select [SQUELCH] Set this function to prevent the receiver settings from being changed. and then press the control dial. •... - Page 19 Setting ATW-R3210 Setting user-defined scan groups Setting the backup frequency mode Aside from the ten preset groups, there are two additional user-defined If you set the backup frequency in advance, you can switch the scan groups: U1 and U2. Both U1 and U2 can be edited with up to 32 frequency of the transmitter and receiver with the transmitter.
-
Page 20: Setting The Display Brightness
Setting ATW-R3210 Setting the AF level meter on the main screen Resetting Switch the AF level meter on the main screen between [Receiver (Rx)] This returns the receiver settings to their factory defaults. and [Transmitter (TX)]. From the menu screen, turn the control dial, select [UTILITIES] •... -
Page 21: Setting Atw-T3201/Atw-T3202
Set HPF (High-Pass Filter). LOCK Set a lock. Fn BUTTON Set the function allocation for function button. After selecting [Gr/Ch], press the SET button. MUTE MODE (ATW-T3201 Set the mute mode. only) FREQUENCY UTILITIES BATTERY Set the type of batteries used. -
Page 22: Setting The Gain
Setting ATW-T3201/ATW-T3202 Setting the gain Setting lock From the menu screen, press the UP/DOWN button to select From the menu screen, press the UP/DOWN button to select [GAIN], and then press the SET button. [LOCK], and then press the SET button. -
Page 23: Setting The Mute Mode (Only For Atw-T3201)
Setting ATW-T3201/ATW-T3202 Setting the mute mode (only for ATW-T3201) Setting the indicator The indicator LED can be turned [On] or [Off]. Set the function of the MUTE switch. • The default setting is [On]. From the menu screen, press the UP/DOWN button to select From the menu screen, press the UP/DOWN button to select [MUTE MODE], and then press the SET button. - Page 24 Setting ATW-T3201/ATW-T3202 Resetting This returns the transmitter settings to their factory defaults. From the menu screen, press the UP/DOWN button to select [UTILITIES], and then press the SET button. UTILITIES Press the UP/DOWN button to select [RESET] and press the SET button.
-
Page 25: How To Attach The Transmitter (Atw-T3201)
How to attach the transmitter (ATW-T3201) The ATW-T3201 transmitter is equipped with a clip that can be used to attach the transmitter to a belt, etc. You can reverse the direction of the input connector by Pull both sides of the clip firmly to the outside to remove attaching the clip in the opposite direction. -
Page 26: Using Ir Sync
Using IR SYNC This function allows you to make settings on the receiver that are specified for the transmitter. When IR SYNC is started as part of setting the receiver, the “Communication in standby” screen is displayed. Position the IR sync windows of the receiver and transmitter so they face each other. Press the SYNC button on the transmitter. -
Page 27: Troubleshooting
Confirm that the receiver isn't taking power from an electrical outlet that is also being used by another noisy component. Confirm that there isn't any other nearby wireless system using the same frequency p. 17 band. Adjust the squelch level. ATW-T3201/ATW-T3202 Symptoms Causes and countermeasures Reference page The power can't be turned on. -
Page 28: Dimensions
Dimensions ATW-R3210 210.0 (Unit: mm) -
Page 29: Atw-T3201
Dimensions ATW-T3201 (Unit: mm) ATW-T3202 (Unit: mm) -
Page 30: Specifications
*1 Please note that some frequency bands might not be available in your territory or could come with a limited tuning bandwidth/transmitting power due to local regulations. *2 Open range environment with no interfering signals. *3 Frequency response depends on attached microphone element. *4 For assistance with multi-band operation or other frequency coordination issues, Contact your local audio-technica dealer. *5 Region and band dependent ATW-R3210... -
Page 31: Atw-T3202
Specifications ATW-T3202 RF output power High: 30 mW, Low: 10 mW (switchable), at 50 ohms Spurious emissions Following federal and national regulations Microphone capsule Interchangable industry standard thread High-pass (low-freq. roll-off) 150 Hz, 6dB/octave Batteries Two 1.5V AA, not included High: 8.0 hours (alkaline) Low: 9.0 hours (alkaline) Battery life*... - Page 32 Audio-Technica Corporation 2-46-1 Nishi-naruse, Machida, Tokyo 194-8666, Japan www.audio-technica.com ©2018 Audio-Technica Corporation Global Support Contact: www.at-globalsupport.com 232416960-02-01 ver.1 2018.04.15...
