Opening and Closing the Movable
Monitor
Press .
The movable monitor will open.
To close the movable monitor, press
The movable monitor will close.
• Do not apply shock to the movable monitor when it is open as it may
result in malfunction of the unit.
• The monitor may be dim during low temperature and immediately
after turning on the power. The brightness will return to normal as
time elapses.
• The monitor will stop at the set tilt angle when closing.
CAUTION
Keep hands (or any other object) away from the monitor while it
is opening or closing to avoid damage or injury. The back of the
movable monitor will get very warm under normal operating
conditions. This is not a malfunction. Do not touch.

Adjusting the Monitor Viewing Angle

Adjust the monitor's angle for better visibility.
1
Touch [SETUP] for the selected source on the main
screen.
The setup selection screen is displayed.
2
Touch [MONITOR].
3
Touch [ ] or [ ] to adjust the desired monitor
angle.
4
Touch [RETURN] to return to the previous screen.
Pressing the buttons changes the screen angle by three
stages.
• If the monitor touches an obstacle while the angle is being adjusted
the unit stops the screen immediately.
• The screen color will vary when viewed at certain angles. Adjust the
screen angle for the best viewing position.
• If the voltage of the vehicle's battery power is low, the screen may
blink when the screen angle is changed. This is normal and not a
malfunction.
• Touching [CONTROL] will change to the main source screen.

Adjusting the Volume

Adjust the volume by pressing
Volume decreases/increases continuously by pressing and
holding or .
Volume: 0 - 35
10
-EN
again.
or .

Lowering Volume Quickly

Activating this function will instantly lower the volume level by 20 dB.
Press MUTE to activate the MUTE mode.
The audio level decreases by about 20 dB.
Pressing MUTE again brings the audio back to its previous level.

How to view the Display

Soft button operation

The display unit is equipped with tactile feedback (PULSETOUCH™).
What is the tactile feedback (PULSETOUCH™) ?
When you touch a button graphic in the display, you will feel a
mild vibration and click on the display panel surface. This
feedback enables you to easily identify action areas in the
display.
• Be sure to touch the button lightly with the pad of your finger on the
display to protect the display.
• If you touch a button and there is no reaction, remove your finger
from the display once, and try again.
About the button descriptions used in this Owner's Manual
• Soft buttons, ones found in the display, are shown in bold
enclosed in brackets, [ ] (e.g. [SOURCE]).
• Whenever a soft button and a head unit button have the same
function, the explanations in this Owner's Manual will describe
the function of the soft button.

Recalling the Source

Here is an example explanation for the Radio mode display on how to
recall a source.
1
Touch [SOURCE] on the main screen.
The source selection screen is displayed.
Display example for source selection screen
Changes to main source screen
Displays source modes that can be selected
(The kind of source modes that are displayed varies
depending on connection and setting)
