Endress+Hauser Hart Deltabar FMD71 Manual

Level measurement with electronic differential pressure electronic differential pressure transmitter with ceramic and metal sensors
Hide thumbs Also See for Hart Deltabar FMD71:
Table of Contents

Advertisement

Quick Links

Download this manual
GP01013P/00/EN/06.17
71376029
Valid as of version
01.00.00
Products
Description of Device Parameters
Deltabar FMD71, FMD72
Level measurement with electronic differential pressure
Electronic differential pressure transmitter with ceramic
and metal sensors
Solutions
Services

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser Hart Deltabar FMD71

Summary of Contents for Endress+Hauser Hart Deltabar FMD71

  • Page 1 Products Solutions Services GP01013P/00/EN/06.17 71376029 Valid as of version 01.00.00 Description of Device Parameters Deltabar FMD71, FMD72 Level measurement with electronic differential pressure Electronic differential pressure transmitter with ceramic and metal sensors...
  • Page 2 Deltabar FMD71, FMD72 Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...

  • Page 3: Table Of Contents

    (optional) ......10 Operation using Endress+Hauser operating program ......13 Direct access to parameters .

  • Page 4: Document Information

    • Outer ground terminal: Connects the device to the plant grounding system. 1.2.3 Symbols for certain types of information Symbol Meaning Permitted Procedures, processes or actions that are permitted. Preferred Procedures, processes or actions that are preferred. Forbidden Procedures, processes or actions that are forbidden. Endress+Hauser...

  • Page 5: Documentation

    Views A-A, B-B, C-C, ... Sections Documentation The document types listed are available: In the Download Area of the Endress+Hauser Internet site: www.endress.com → Download 1.3.1 Technical Information (TI): planning aid for your device TI01033P: The document contains all the technical data on the device and provides an overview of the accessories and other products that can be ordered for the device.
  • Page 6 FM C/US XP AIS Cl.I Div.1 Gr.A-D, Exd [ia] Zone 0,1,2 XA00625P FMD72 FM C/US NI Cl.I Div.2 Gr.A-D, Zone 2 XA00669P Product Configurator order code for "Approval" The nameplate provides information on the Safety Instructions (XA) that are relevant for the device. Endress+Hauser...

  • Page 7: Terms And Abbreviations

    Factory setting: 0 to URL Other calibrated spans can be ordered as customized spans. Pressure Lower range limit Upper range limit Lower range value Upper range value TD (Turn down) Turn down Example - see the following section. Endress+Hauser...

  • Page 8: Turn Down Calculation

    10 bar (150 psi) TD = |5 bar (75 psi) 0 bar (0 psi)| In this example, the TD is 2:1. This span is based on the zero point. Registered trademarks 1.6.1 HART® Registered trademark of the FieldComm Group, Austin, USA Endress+Hauser...

  • Page 9: Operation Options

    The "Extended setup" submenu contains additional parameters for more indepth configuration of the measurement operation to convert the measured value and to scale the output signal. This menu is split into additional submenus depending on the measuring mode selected. Endress+Hauser...

  • Page 10: Operating Options

    The display can be removed for easy operation. The device display can be turned in 90° steps. Depending on the installation position of the device, this makes it easy to operate the device and read the measured value. Endress+Hauser...
  • Page 11 The device is in service mode (e.g. during a simulation). A0012100 Error message "Maintenance required" Maintenance is required. The measured value remains valid. A0012101 Error message "Failure detected" An operating error has occurred. The measured value is no longer valid. A0012086 Endress+Hauser...
  • Page 12  Spanish 3  Spanish Confirm your selection with . A  in front of the menu text indicates the option that is currently active ("Spanish" is German the language selected). Use  to exit edit mode for the parameter. Endress+Hauser...

  • Page 13: Operation Using Endress+Hauser Operating Program

    Operation using Endress+Hauser operating program The FieldCare operating program is an Endress+Hauser asset management tool based on FDT technology. With FieldCare, you can configure all Endress+Hauser devices as well as devices from other manufacturers that support the FDT standard. Hardware and software requirements can be found on the Internet: www.de.endress.com →...

  • Page 14: Direct Access To Parameters

    The "Operator code" parameter is used to lock/unlock the device. The parameters can only be accessed directly via the "Expert" user role. Operator code (021) Navigation Setup → Extended setup → Operator code Read permission Operator/Service engineers/Expert Write permission Operator/Service engineers/Expert Endress+Hauser...

  • Page 15: Resetting To Factory Settings (Reset)

    Any customer-specific configuration carried out at the factory is not affected by a reset (customer-specific configuration remains). If you want to change the customer- specific configuration carried out at the factory, please contact Endress+Hauser Service. . The factory setting for the individual parameters is specified in the parameter description...

  • Page 16: Backing Up Or Duplicating The Device Data

    DIP switch set to "SW" and "Damping" set to "on". If you download using the factory setting "Configuration copy", all parameters required for a measurement will be downloaded. The functionality of the "Electronics replace" setting is reserved for Endress+Hauser Service and can be accessed only if the correct device access code is entered.
  • Page 17 • Device replacement: This option overwrites general configuration parameters with the exception of the serial number, order number, calibration and position adjustment. • Electronics replace: This option overwrites general configuration parameters. Factory setting Copy configuration Endress+Hauser...

  • Page 18: Overview Of The Operating Menu

    →  32 Sensor Temp. LP (read only) →  32 Electronics temp. (read only) →  33 Pressure High Press. Side →  33 Set LRV →  33 Set URV →  33 Meas.Diff.Press. (read only) →  34 Endress+Hauser...
  • Page 19 Sens. limit LP LRL sensor →  44 URL sensor →  44 Sensor trim HP Lo trim measured →  44 Hi trim measured →  44 Lo Trim Sensor →  44 Hi Trim Sensor →  45 Endress+Hauser...
  • Page 20 Secondary value is (read only) →  54 Secondary value is (read only) →  55 Third value is (read only) →  55 Third value is (read only) →  56 Fourth value is (read only) →  56 Endress+Hauser...
  • Page 21 Last Diag. 4 (read only) →  64 Last Diag. 5 (read only) →  64 Last Diag. 6 (read only) →  64 Last Diag. 7 (read only) →  64 Last Diag. 8 (read only) →  64 Endress+Hauser...
  • Page 22 Sim. diff.press. →  66 Sim. Press. HP →  66 Sim. Press. LP →  66 Sim. level →  66 Sim. tank cont. →  67 Sim. Current →  67 Sim. error no. →  67 Endress+Hauser...

  • Page 23: Description Of Device Parameters

    Displays the status of DIP switch 1 on the electronic insert. You can lock or unlock parameters relevant to the measured value with DIP switch 1. If operation is locked by means of the "Operator Code" (021) parameter, you can only unlock operation again by means of this parameter. Endress+Hauser...

  • Page 24: Expert → System → Instrument Info

    Device tag (022) Navigation Expert → System → Instrument info → Device tag (022) Write permission Operators/Service engineers/Expert Description Enter the device tag e.g. TAG number (max. 32 alphanumeric characters). Factory setting No entry or according to order specifications Endress+Hauser...
  • Page 25 Serial number (096) Navigation Expert → System → Instrument info → Serial number (096) Write permission Parameter is read only. Only Endress+Hauser Service has write permission. Description Displays the serial number of the device (11 alphanumeric characters). Firmware version (095) Navigation Expert →...

  • Page 26: Expert → System → Display

    Expert → System → Display → Language Write permission Operators/Service engineers/Expert Description Select the menu language for the local display. Options • English • Another language (as selected when ordering the device) • Possibly a third language (language of the manufacturing plant) Endress+Hauser...
  • Page 27 Factory setting No value 3rd disp. value (288) Navigation Expert → System → Display → 3rd disp. value (288) Write permission Operators/Service engineers/Expert Description Specify the contents for the third value in the alternating display mode in measuring mode. Endress+Hauser...
  • Page 28 HART input form. (157) Navigation Expert → System → Display → HART input form. (157) Write permission Operators/Service engineers/Expert Description Number of decimal places of the displayed input value. Options • x.x • x.xx • x.xxx • x.xxxx • x.xxxxx Factory setting Endress+Hauser...

  • Page 29: Expert → System → Management

    If the measuring mode is changed, the setting for the span (URV) must be checked in the "Setup" operating menu and readjusted if necessary. Navigation Expert → Measurement → Measuring mode (005/182) Write permission Operators/Service engineers/Expert Description Select the measuring mode. The operating menu is structured differently depending on the measuring mode selected. Endress+Hauser...

  • Page 30: Expert → Measurement → Basic Setup

    2.2 mbar (0.033 psi). D.h. This means that you are assigning the value 980.0 (14.7 psi) to the pressure present. • Measured value (after pos. zero adjust) = 980.0 mbar (14.7 psi) • The current value is also corrected. Factory setting Endress+Hauser...
  • Page 31 Expert → Measurement → Basic setup → Press. eng. unit (125) Write permission Operators/Service engineers/Expert Description Select the pressure engineering unit. If a new pressure engineering unit is selected, all pressure-specific parameters are converted and displayed with the new unit. Endress+Hauser...
  • Page 32 Sensor temp. LP (283) Navigation Expert → Measurement → Basic setup → Sensor temp. LP (283) Write permission No write permissions. Parameter is read only. Description Displays the temperature currently measured in the sensor module. This can deviate from the process temperature. Endress+Hauser...

  • Page 33: Expert → Measurement → Pressure

    Set URV (014, 057, 167, 169) Navigation Expert → Output → Current output → Set URV (014, 057, 167, 169) Write permission Operators/Service engineers/Expert Description Set the pressure value, level or content for the upper current value (20 mA). Endress+Hauser...
  • Page 34 No write permissions. Parameter is read only. Description Displays the measured pressure before the sensor trim. Sensor press. LP (280) Navigation Expert → Measurement → Pressure → Sensor press. LP (280) Write permission No write permissions. Parameter is read only. Endress+Hauser...

  • Page 35: Expert → Measurement → Level

    Description Displays the measured differential pressure after position adjustment. Expert → Measurement → Level Level selection (024) Navigation Expert → Measurement → Level → Level selection (024) Write permission Operators/Service engineers/Expert Description Select the method for calculating the level Endress+Hauser...
  • Page 36 Expert → Measurement → Level → Height unit (026) Write permission Operators/Service engineers/Expert Description Select the height unit. The measured pressure is converted to the selected height unit using the "Adjust Density" parameter. Prerequisite "Level selection" = "In height" Endress+Hauser...
  • Page 37 "In pressure" level selection, the associated pressure must be entered in the "Empty pressure (029)" parameter. The associated height has to be entered in the "Empty height" (030) parameter for the "In height" level selection. Factory setting Empty pressure (029)/(185) Endress+Hauser...
  • Page 38 "In pressure" level selection, the associated pressure must be entered in the "Full pressure" parameter. The associated height has to be entered in the "Full height" parameter for the "In height" level selection. Factory setting 100.0 Full pressure (032)/(187) Endress+Hauser...
  • Page 39 Displays the density unit. The measured pressure is converted to a height using the "Height unit", "Adjust density" and "Process density" parameters. Options • g/cm • kg/m • kg/dm • lb/in • lb/ft Factory setting g/cm Adjust density (034) Endress+Hauser...

  • Page 40: Expert → Measurement → Linearization

    No write permissions. Parameter is read only. Description Displays the level value prior to linearization. 5.10 Expert → Measurement → Linearization Lin. mode (037) Navigation Expert → Measurement → Linearization → Lin. mode (037) Write permission Operators/Service engineers/Expert Description Select the linearization mode. Endress+Hauser...
  • Page 41 Expert → Measurement → Linearization → Line number (039) Write permission Operators/Service engineers/Expert Description Enter the number of the current point in the table. The subsequent entries in "X-value" and "Y-value" refer to this point. Input range 1 to 32 Endress+Hauser...
  • Page 42 • Select point 5 via the "Line number" parameter. • Select the "Delete point" option via the "Edit table" parameter. • The 5th point is deleted. All of the following points are pushed up one number i.e. following deletion, the 6th point becomes Point 5. Endress+Hauser...

  • Page 43: Expert → Measurement → Sens. Limit Hp

    Displays the lower-range limit of the sensor module. URL sensor (102) Navigation Expert → Measurement → Sens. limit HP → LRL sensor (101) Write permission No write permissions. Parameter is read only. Description Displays the upper-range limit of the sensor module. Endress+Hauser...

  • Page 44: Expert → Measurement → Sens. Limit Lp

    Navigation Expert → Measurement → Sensor trim HP → Hi trim measured (130) Write permission No write permissions. Parameter is read only. Description Displays the serial number of the sensor module HP (11 alphanumeric characters). Lo trim sensor (131) Endress+Hauser...

  • Page 45: Expert →Measurement → Sensor Trim Lp

    Displays the reference pressure present to be accepted for the upper calibration point. Lo trim sensor (277) Navigation Expert → Measurement → Sensor trim LP → Lo trim sensor (277) Write permission No write permissions. Parameter is read only. Endress+Hauser...

  • Page 46: Expert → Measurement → Current Output

    – The upper sensor module limit is overshot (sensor module LP or HP or complete system): Current output assumes a value of 21 - 23 mA, depending on the setting of the "High alarm curr." (052) parameter. Factory setting Warning Endress+Hauser...
  • Page 47 Expert → Output → Current output → High alarm curr. (052) Write permission Operators/Service engineers/Expert Description Enter the current value for maximum alarm current. See also "Output fail mode". Input range 21 to 23 mA Factory setting 22 mA Set min. current (053) Endress+Hauser...
  • Page 48 Factory setting • 0.0 % in Level measuring mode • 0.0 mbar/bar or in accordance with ordering information in Pressure measuring mode Get URV (016) Navigation Expert → Output → Current output → Get URV (016) Write permission Operators/Service engineers/Expert Endress+Hauser...
  • Page 49 Write permission Service engineers/Expert Description Enter the pressure value for the lower point (4 mA) of the current partial regression lines. Using this parameter and "Curr. trim 20 mA", you can adapt the current output to the transmission conditions. Endress+Hauser...
  • Page 50 Description Display/enter the difference between 4 mA and the value entered for the parameter "Curr. trim 4mA". Factory setting Offset trim 20mA (138) Navigation Expert → Output → Current output → Offset trim 20mA (138) Write permission Service engineers/Expert Endress+Hauser...

  • Page 51: Expert → Communication → Hart Config

    Default output: Meas.Diff.Press. (020), Meas. press.HP (281), Sensor press. HP (109) and Sensor temp. HP (110) Factory setting 1 (HART command 1) Current mode (144) Navigation Expert → Communication → HART config → Current mode (144) Write permission Service engineers/Expert Endress+Hauser...

  • Page 52: Expert → Communication → Hart Info

    Input range 2 to 20 Factory setting 5.17 Expert → Communication → HART info Device type code (279) Navigation Expert → Communication → HART info → Device type code (279) Write permission No write permissions. Parameter is read only. Endress+Hauser...
  • Page 53 Description (139) Navigation Expert → Communication → HART info → Descriptor (139) Write permission Service engineers/Expert Description Enter measuring point description (max. 16 alphanumeric characters). HART message (140) Navigation Expert → Communication → HART info → HART message (140) Endress+Hauser...

  • Page 54: Expert → Communication → Hart Output

    • "Level" measuring mode, Lin. mode "Activate table": "Tank content" Primary value (148) Navigation Expert → Communication → HART output → Primary value (148) Write permission No write permissions. Parameter is read only. Description The primary value is displayed. Secondary value is (149) Endress+Hauser...
  • Page 55 Expert → Communication → HART output → Third value is (151) Write permission No write permissions. Parameter is read only. Description Indicates which measured value is transmitted via the HART protocol as the third process value. The process value is configured via HART command 51. Endress+Hauser...
  • Page 56 • "Pressure" measuring mode: "Sensor temperature HP" • "Level" measuring mode, Lin. mode "Linear": "Measured pressure LP" • "Level" measuring mode, Lin. mode "Activate table": "Measured pressure LP" Display Depending on the selected measuring mode, the following measured values can be displayed: Endress+Hauser...

  • Page 57: Expert → Communication → Hart Input

    Display of the HART input value HART input stat. (179) Navigation Expert → Communication → HART input → HART input stat. (179) Write permission No write permissions. Parameter is read only. Description Display of the HART input status Bad / Uncertain / Good Endress+Hauser...

  • Page 58: Expert → Diagnosis

    No write permissions. Parameter is read only. Description Displays the last diagnostic message that occurred and was rectified. Note • Digital communication: the last message is displayed. • Use the "Reset logbook" parameter to clear the messages listed in the parameter "Last diag. code". Endress+Hauser...
  • Page 59 Pmax process LP (289) Navigation Expert → Diagnosis → Pmax process LP (289) Write permission Operators/Service engineers/Expert Description Customer-specific process detection limit (upper) for sensor module LP. Factory setting Upper nominal operating range value LP Pmin process LP (290) Endress+Hauser...

  • Page 60: Expert → Diagnosis → Sensor Hp

    Displays the number of sensor module changes. 5.21 Expert → Diagnosis → Sensor HP Min. meas. press. (073) Navigation Expert → Diagnosis → Sensor HP → Min. meas. press. (073) Write permission No write permissions. Parameter is read only. Endress+Hauser...
  • Page 61 Expert → Diagnosis → Sensor HP → Min. meas.temp. (264) Write permission No write permissions. Parameter is read only. Description Displays the smallest temperature measured in the sensor module. You can reset this value using the "Reset peakhold (161)" parameter. Endress+Hauser...

  • Page 62: Expert → Diagnosis → Sensor Lp

    Expert → Diagnosis → Sensor LP → Max. meas. press.(268) Write permission No write permissions. Parameter is read only. Description Displays the highest pressure value measured (peakhold indicator). You can reset this peak indicator via the "Reset peakhold (161)" parameter. Endress+Hauser...

  • Page 63: Expert → Diagnosis → Diagnostic List

    5.23 Expert → Diagnosis → Diagnostic list Diagnostic list Diagnostic 1 (075) Diagnostic 2 (076) Diagnostic 3 (077) Diagnostic 4 (078) Diagnostic 5 (079) Diagnostic 6 (080) Diagnostic 7 (081) Diagnostic 8 (082) Diagnostic 9 (083) Diagnostic 10 (084) Endress+Hauser...

  • Page 64: Expert → Diagnosis → Event Logbook

    Expert → Diagnosis → Simulation → Simulation mode (112) Write permission Operators/Service engineers/Expert Description Switch on simulation and select the simulation mode. When changing the measuring mode or the level type (Lin. mode (037)) or when the device is restarted, any simulation running is switched off. Endress+Hauser...
  • Page 65 Simulation Error number ↓ Mode Diagnosis/ Simulation Linearization device status current mode Measured differential → ↓ ↓ ↓ ↓ pressure Level before → → → (Measured → Processing current output → Current output linearization value) Tank content → ↑ Endress+Hauser...
  • Page 66 Prerequisite "Simulation mode" = Pressure LP Value at switch-on Current pressure measured value Sim. level (115) Navigation Expert → Diagnosis → Simulation → Sim. level (115) Write permission Operators/Service engineers/Expert Description Enter the simulation value. See also "Simulation mode". Endress+Hauser...
  • Page 67 Sim. error no. (118) Navigation Expert → Diagnosis → Simulation → Sim. error no. (118) Write permission Operators/Service engineers/Expert Description Enter the diagnostic message number. See also "Simulation mode". Prerequisite "Simulation Mode" = Alarm/Warning Value at switch-on 484 (Simulation active) Endress+Hauser...
  • Page 68 Lock switch (120) ......23 Electr.serial no (121) ......26 Endress+Hauser...
  • Page 69 Ser.no. sensor LP (274) ..... . . 26 Serial number (096) ......25 Endress+Hauser...
  • Page 72 *71376029* 71376029 www.addresses.endress.com...
